Winterwarm WinLed Skyline Installation Manual

Installation manual WinLed Skyline
60
60
1
3061
1530
750

Mounting clip type 1

For chain assembly.
Art. Number:
2
LL600OH
.
Type 1
Not included
3
First attach the clips to a chain, then attach the profile
.
Only for mounting clip Type 4 (LL600OHKGK)
4
.
1530
750 750
First mount the clips to a ceiling, then mount the profile
B
B
A
A
Feed the wire trough
the connector,
Lock the profiles by
determine the
tightening the two
desired high ten then
screws that are
tighten the two bolds.
included. Then snap
the connectors
together.
5
.
3136
3061
4668
4592

Connector placing

4592
1530 750

Mounting clip type 2

For surface mounting
or threaded rod.
Art. Number:
LL600PB
Type 2
1
0
OFF
SECTION B-B
Mounting clip type 3 & 4
For chain assembly
Only for:
LL600PR302, LL600PR303,
LL600PR452 & LL600PR453
Art. Number type 3:
LL600OHKG
Art. Number type 4:
LL600OHKGK
Type 3&4
CLICK!
Click the clip on the profile, then pull the bolt down
and tighten it.

Linking profiles

CLICK
!
Art. Number:
LL600PR300
LL600PR301
LL600PR302
LL600PR303
Art. Number:
LL600PR450
LL600PR451
LL600PR452
LL600PR453
Type 3 Type 4
SECTION A-A
