- Page 1 OY1210 LoRaWAN® CO2 meter Product manual version 1.0 January 24, 2023 support@propeye.se Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com...
-
Page 2: Table Of Contents
OY1210 LoRaWAN® CO2 meter Table of contents Disclaimer ........................3 Technical support ....................3 EU Declaration of conformity ................. 3 Warnings ........................4 Environmental ....................... 5 Product Description ...................... 6 Installation and activation ..................... 7 The sensor consists of a bottom piece, the electronic board and the top cover. Remove the top cover by pressing it upwards and outwards. -
Page 3: Disclaimer
Propeye makes no warranties based on the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. Nordic Propeye reserves all rights to this document and the information contained herein. -
Page 4: Warnings
OY1210 LoRaWAN® CO2 meter 2 Warnings The following safety precautions must be observed during all phases of the operation, usage, service or repair of this Nordic Propeye product. • Read the product manual. • Do not modify the product. • The product should not be exposed to extreme heat or open flame. -
Page 5: Environmental
OY1210 LoRaWAN® CO2 meter 3 Environmental This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste by taking it to a collection point designated for the recycling of electrical and electronic appliances. -
Page 6: Product Description
OY1210 LoRaWAN® CO2 meter 4 Product Description The OY1210 LoRaWAN CO2 meter is designed to measure carbon dioxide, temperature and humidity in indoor environments. The sensor is intended for indoor climate control, air quality monitoring and energy optimizations. It is optimized for reliable and secure measurements with more than 5 years life length on batteries. -
Page 7: Installation And Activation
OY1210 LoRaWAN® CO2 meter 5 Installation and activation The sensor consists of a bottom piece, the electronic board and the top cover. Remove the top cover by pressing it upwards and outwards. The electronics are removed by releasing the plastic latch on the top. The bottom piece is mounted on the wall with the “UP”... -
Page 8: Lorawan Configuration
Nordic Propeye OUI range. The device is configured with device unique DevEUI and AppKey The device is default configured for OTA provisioning. Contact the Nordic Propeye team for ABP configuration. The device follows the LoRaWAN standard related Join configuration parameters, such as RX1 and RX2 windows, RX2 downlink frequency etc. -
Page 9: Sensor States And State Check
OY1210 LoRaWAN® CO2 meter 6.2 Sensor states and state check The sensor has five states: Booting, Initial, Joining, Configure and Operational state. Figure 1: Device states When the unit is initially powered, it flashes 2 times with the LED, after a few seconds the unit enters initial state automatically. - Page 10 OY1210 LoRaWAN® CO2 meter State Description LED response Initial Low power state during transport. Radio not active. 1 short flash (0.5 sec) Trying to join a LoRaWAN network. The device will Joining remain in this state until successfully joined a LoRaWAN 2 short flash (0.5 sec) network Enables quick over-the-air configuration, by polling...
-
Page 11: Specification
OY1210 LoRaWAN® CO2 meter 7 Specification Operating principle Non-dispersive infrared (NDIR) Sample method Diffusion Accuracy and range Temperature accuracy ± 0,2 °C (conditions 0 °C to +50 °C) Temperature range -20 °C to +60 °C Humidity accuracy ± 2% (conditions 10-90% RH) Humidity range 0% to 100% non-condensing Measurement range CO... - Page 12 OY1210 LoRaWAN® CO2 meter Enclosure IP30 Certifications RoHS compliant LoRaWAN Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com...
-
Page 13: Product Life Length
OY1210 LoRaWAN® CO2 meter 8 Product life length Storage More than one year without limiting the product life length Operational Battery life length >5 years (at 20-minute intervals, SF12) + 1 year storage 9 Security The device has the following security features: •... -
Page 14: Periodic Measurement Reports
OY1210 LoRaWAN® CO2 meter Port: Port 1 Payload 0x01 20 00 0x01: Data type 0x20: Status command 0x00: Normal startup The expected behavior is 0x01 20 00. If not contact support. 10.3 Periodic measurement reports The sensors transmit periodic unsolicited measurement reports or adaptive reports due to changes in CO2 level. -
Page 15: Downlink Commands And Queries
OY1210 LoRaWAN® CO2 meter 10.3.2.3 Carbon dioxide (CO2) conversion The carbon dioxide (CO ) measurement in parts-per-million (ppm – 1 x 10 ). The CO2 data is averaged over a measurement period. The data is transmitted using an un-signed 16-bit integer. The value 0xFFFF indicates an error in the CO2 reading, and should be displayed as an alarm or error code in the application, not as a measurement value. -
Page 16: Commands
10.5 Commands Port Index Description Uplink Encoding Valid range Access Unsolicited Description Note Datatype response 0x03 FW build hash 6 x Uint8 Query Unique number that identifies the firmware version 0x05 Device reset Action Reset of device 0x06 CPU voltage Uint8 25mV/ 0-3.6V... - Page 17 OY1110 LoRaWAN® Temperature and humidity sensor 10.5.1 Measurement reporting interval Both the measurement interval and reporting interval can be set with downlink commands. The default setting is a measurement interval of 60 sec. The default reporting interval is every 20 measurement interval.
-
Page 18: Uplink Query Response
OY1110 LoRaWAN® Temperature and humidity sensor 10.6 Uplink query response Uplink messages are sent on port 1 with the following heading: Uplink command device => network Field Bytes Value Description Note Type 0x01: Data 0x02: Command NACK Index Command Index Data As defined for Command Index (only for Type: Data) Example:...
