- Page 1 Electric Induction Cooktop Live Smart, Better Life! IHTB774C / IHTB915C Instruction / Installation Manual 1 (844) 334-4203 www.thermomate.com support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418...
-
Page 3: Important Instructions
• Make Sure Reflector Pans or Drip Bowls Are in Place – Absence of these pans or bowls during cooking may subject wiring or components underneath to damage. support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418... - Page 4 • This appliance is to be properly installed and earthed only by a suitably qualified person. • This appliance should be connected to a circuit that incorporates an isolating switch providing full disconnection from the power supply. 1 (844) 334-4203 www.thermomate.com...
-
Page 5: Electrical Shock Hazard
• Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other cooking zones that are on. Keep handles out of reach of children. • Failure to follow this advice could result in burns and scalds. support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418... -
Page 6: Cut Hazard
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified persons in order to avoid a hazard. 1 (844) 334-4203 www.thermomate.com... - Page 7 • A steam cleaner is not to be used. • The appliance is not intended to be operated by means of an external timer or separate remote-control system. support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418...
-
Page 8: Product Overview
Product Overview Top view(IHTB774C) BOOST BOOST BOOST BOOST 1. Max. 1800/2100W zone 2. Max. 1200/1500W zone 3. Max. 2300/3000W zone 4. Max. 1200/1500W zone 5. Control panel Top view(IHTB915C) BOOST BOOST BOOST BOOST BOOST 1. Max. 1800/2100W zone 2. Max. 1200/1500W zone 3. - Page 9 Control panel(IHTB774C) Control panel(IHTB915C) 1. ON/ OFF switch 5. Select heating zone 2. Select power level 6. Boost control 3. Setting the timer 7. Keep warm 4. Child lock 8. Pause A Word On Induction Cooking Induction cooking is a safe, advanced, efficient, and economical cooking technology.
-
Page 10: Using The Touch Controls
• You can check whether your cookware is suitable by carrying out a magnet test. Move a magnet towards the base of the pan. If it is attracted, the pan is suitable for induction cooking. 1 (844) 334-4203 www.thermomate.com... - Page 11 /2 inch could be undetected by the cooktop. Always centre your pan on the cooking zone. Always lift pans off the Induction cooktop – do not slide, or they may scratch the glass. support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418...
-
Page 12: Using Your Induction Cooktop
1. Touching the heating zone selection that you wish to switch off. 2. Turn the cooking zone off by touching the “slider”, make sure the display shows “0”. 3.Turn the whole cooktop off by touching the ON/OFF control. 1 (844) 334-4203 www.thermomate.com... -
Page 13: Using The Keep Warm Function
9 automatically. Using the Keep Warm function Activate the Keep Warm function 1. Select the zone with the keep warm function. 2. Touching the keep warm control, the zone indication shows “ | ” support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418... - Page 14 • The function is available the one or more heating zones is working. • If you don`t cancel the stop working mode within 30 minutes, the induction cooktop will automatically switch off. 1 (844) 334-4203 www.thermomate.com...
-
Page 15: Locking The Controls
Auto shut down is a safety protection function for your induction cooktop. It shut down automatically if ever you forget to turn off your cooking. The default working times for various power levels are shown in the below table: Power level Default working timer (hour) support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418... -
Page 16: Using The Timer As A Minute Minder
6. When the time is set, it will begin to count down immediately. The display will show the remaining time. 7. Buzzer will beep for 30 seconds and the timer indicator shows “- - “ when the setting time finished. 1 (844) 334-4203 www.thermomate.com... - Page 17 7. When the cooking timer expires, the corresponding cooking zone will be switched off automatically. Note: Other cooking zones will keep operating if they are turned on previously. support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418...
- Page 18 1. Touching the heating zone selection control that you want to cancel the timer. 2. Touching the timer control, the indicator will flash. 3.Touch the slider control to set the timer to “00”, the timer is canceled. 1 (844) 334-4203 www.thermomate.com...
-
Page 19: Cooking Guidelines
‘well done’ it will be. 5. Leave the steak to rest on a warm plate for a few minutes to allow it to relax and become tender before serving. support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418... -
Page 20: Heat Settings
1 - 2 • Gentle simmering • Slow warming • Reheating • Rapid simmering • Cooking rice • Pancakes • Sauteing • Cooking pasta • Stir-frying • Searing • Bringing soup to the boil • Boiling water 1 (844) 334-4203 www.thermomate.com... -
Page 21: Care And Cleaning
Make sure you wipe the touch control touch controls 4. Wipe the area completely dry area dry before turning the cooktop back with a paper towel. 5. Switch the power to the cooktop back on. support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418... -
Page 22: Hints And Tips
Technical fault. numbers, switch the power to the induction displayed(typically cooktop off at the wall, and contact a qualified alternating with one or technician. two digits in the cooking timer display). 1 (844) 334-4203 www.thermomate.com... -
Page 23: Failure Display And Inspection
The above are the judgment and inspection of common failures. Please do not disassemble the unit by yourself to avoid any dangers and damages to the induction cooktop. Technical Specification Model IHTB774C IHTB915C Item UI72358 UI93359 Cooking Zones 4 Zones... -
Page 24: Installation
A = 24 inches minimum when bottom of wood or metal cabinet is protected by not less than 1/4-inch-thick flame-retardant millboard covered with not less than No. 28 MSG sheet steel, 0.015-inch-thick stainless steel, 0.024-inch-thick aluminum, or 0.020-inch-thick copper. 1 (844) 334-4203 www.thermomate.com... -
Page 25: Selection Of Installation Equipment
• Ensure the table supporting the surface unit on the metal frame edge, see below right drawing. Model ″ ″ ″ ″ ″ ″ ″ IHTB774C 29.9 20.5 28.8 19.3 ″ ″ ″ ″ ″ ″... - Page 26 • The isolating switch must be of an approved type and provide a 0.12in air gap contact separation in all poles (or in all active [phase] conductors if the local wiring rules allow for this variation of the requirements). 1 (844) 334-4203 www.thermomate.com...
-
Page 27: Before Locating The Fixing Brackets
• Fix the cooktop on the work surface by screw four brackets on the bottom of the cooktop (see picture) after installation. • Adjust the bracket position to suit for different work surface’s thickness. support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418... - Page 28 7. The induction cooktop can be connected only to a supply with system impedance no more than 0.427 ohms. In case necessary, please consult your supply authority for system impedance information. Table Table Cooktop Cooktop Bracket Bracket 1 (844) 334-4203 www.thermomate.com...
-
Page 29: Connecting The Cooktop To The Mains Power Supply
For 4-wire cable from home power supply Cable from home power supply Black wires Red wires White wires Red wires (No need to connect) Green ground wires Black wires Yellow/Green ground wires 3-wire cable from cooktop support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418... - Page 30 For more detailed information about treatment, necessary. recovery and recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. 1 (844) 334-4203 www.thermomate.com...
- Page 32 1 (844) 334-4203 www.thermomate.com support@thermomate.com 3330-A Marathon Ct Charleston, SC 29418...
