DynaMetric
The TRI-807 Telephone Recorder Interface provides clear analog audio of both sides of the
conversation to loggers from almost all digital, electronic or analog telephones that have modular
connected handsets. It injects beeps on the conversation and on the recorder. The TRI-807
detects handset ON/OFF-HOOK with any desk top telephone set that cradles the handset in
cavities in the telephone housing. It can be used on wall mounted telephones of this type as well
as those resting on the desk.
The unit has the following features:
•
Picks up and isolates the full duplex audio from the handset circuits and outputs it to the
recorder on the center pair of the RJ-11 output jack.
•
Mutes handset when ON-HOOK to avoid inadvertent recording of room conversations
between calls. Cut Off Modules not needed for either the "hot handset" or for security
reasons.
It injects a beep on the conversation and recording at 15 second intervals. The beep is OFF
between calls. The beep volume is adjustable.
An LED on the TRI-807 is lit whenever the handset is OFF-HOOK indicating that both it and
the output to the recorder with beeps are activiated.
•
Powered by a 6 VDC plug-in AC Adapter (P/N 39184) furnished with each unit.
Installation:
Mount the TRI-807 on the side of the telephone base adjacent to the earphone end of the handset
when it is ON-HOOK. Press it lightly in place on the adhesive pad so it can easily be moved if
necessary.
Remove the handset coil cord from base of phone and plug in pigtail from TRI-807 in its place.
Plug cord from power cube into TRI-807 and plug power cube into adjacent 115 VAC outlet. Plug
handset coil cord into TRI-807. Connect recorder to RJ-11 output jack.
Patent # 5,835,585
FOR LEGAL USE ONLY
www.DynaMetric.com
717 SOUTH MYRTLE AVENUE • MONROVIA, CALIFORNIA 91016-3422
TRI-807* Telephone Recorder Interface with Beeps
Audio, Beeps and Handset OFF when ON-HOOK
P/N 43430 B Series
626-358-2559 • FAX 626-359-5701 • 800-525-6925
Instructions
Page 1 of 2
9-17-01
©DynaMetric 2001 Doc 43431
Advertisement
Table of Contents
Related Manuals for DynaMetric TRI-807
Summary of Contents for DynaMetric TRI-807
- Page 1 Powered by a 6 VDC plug-in AC Adapter (P/N 39184) furnished with each unit. Installation: Mount the TRI-807 on the side of the telephone base adjacent to the earphone end of the handset when it is ON-HOOK. Press it lightly in place on the adhesive pad so it can easily be moved if necessary.
- Page 2 Temporarily install, with light pressure, the silver target on the side of the handset earphone adjacent to the TRI-807. Adjust the position of the TRI-807 housing (raise, lower or slide) so the apertures in the housing are aligned with the target on the handset so that when ON-HOOK the LED is out and OFF-HOOK the LED is ON.
