The TMP-636S Telephone Transmit & Receive Patch allows you to record and play back to
your telephone from your PC sound card or tape recorder. Compatible with carbon and
electret mics. It allows you to switch sound card operation between the phone and speakers
or headphones.
• Record telephone conversations
• Record just your voice through your sound card (i.e. memos, repetitive, canned
announcements...)
• Playback from your sound card over the phone (announcements, music, phone
conversations, etc.) or on your PC speakers or headphones
Installation is easy, and operation is simple. The TMP-636S is compatible with analog and
digital phones, and standard sound cards and tape recorders. You can leave it connected to
your phone since it does not interfere with normal telephone operation. Will not record
speakerphone.
Install the TMP-636S according to the instructions below and operate your sound card
controls as usual. Note: Make sure the "Monitor" switch on your sound card software (if any)
is set to OFF to avoid feedback. Playback can be heard in your earphone and on the other
end of the call with the switch in the 'PHONE' position, or on your PC speakers or
headphones in the 'SPEAKER' position.
To Install: (See diagram)
1
Unplug handset (or headset) coil cord from the base of the telephone, and plug the short
modular cord from TMP-636S in its place.
2
Plug the handset coil cord into the modular jack on the TMP-636S.
3
Unplug the PC speaker or headphones from the sound card, and plug in the 3.5mm
stereo plug on long GREEN cord from the TMP-636S in its place in the speaker or
headphone jack on the sound card or tape recorder.
4
Plug the 3.5mm mono plug on the long PINK cord from the TMP-636S into the MIC jack
on the sound card or tape recorder.
5
Plug the PC speakers or headphones into the jack on the TMP-636S.
FOR LEGAL USE ONLY
www.DynaMetric.com
INSTRUCTIONS
TMP-636S Telephone Transmit & Receive Patch
For Use with Sound Card with PC Speakers
P/N 44201
Page 1 of 4
6-10-05
©DynaMetric 2002 Doc 44202
Advertisement
Table of Contents
Related Manuals for DynaMetric TMP-636S
Summary of Contents for DynaMetric TMP-636S
- Page 1 GREEN cord from the TMP-636S in its place in the speaker or headphone jack on the sound card or tape recorder. Plug the 3.5mm mono plug on the long PINK cord from the TMP-636S into the MIC jack on the sound card or tape recorder.
- Page 2 INSTRUCTIONS TMP-636S Telephone Transmit & Receive Patch For Use with Sound Card with PC Speakers FOR LEGAL USE ONLY 6-10-05 www.DynaMetric.com Page 2 of 4 ©DynaMetric 2002 Doc 44202...
- Page 3 For Use with Sound Card with PC Speakers Record & Playback Software You may use DynaMetric Call Saver Pro™ recording software, the recording feature in your web conferencing application, Windows Sound Recorder, or other audio recording software. Below are instructions for Windows Sound Recorder. Be sure to read the Feedback section no matter what software you use.
- Page 4 TMP-636S to your phone mic, the phone transfers the signal to the handset earphone, which is picked up by the TMP-636S and sent back to the sound card Mic input. If the Mic is not Muted in the Playback Volume Control, then the signal goes around and around the loop. Feedback may be audible (a loud tone or squeal), or inaudible and just cause noise, distortion and/or very low record levels.
