  • Page 1 CLIMATE CONTROL ROOF TOP VENTILATION SYSTEM ACC3100D Ventilation system Operating manual.......... 3...
  • Page 2 Copyright © 2022 Dometic Group. The visual appearance of the contents of this manual is protected by copyright and design law. The underlying technical design and the products contained herein may be protected by design, patent or be patent pending. The trademarks mentioned in this manual belong to Dometic Sweden AB. All rights are reserved.

  • Page 3: Table Of Contents

    This product manual, including the instructions, guidelines, and warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit documents.dometic.com.

  • Page 4: Safety Instructions

      3 Safety instructions WARNING! Electrocution hazard • Do not touch exposed cables with bare hands. • Do not operate the appliance if it is visibly damaged. • If this appliance's power cable is damaged, it must be replaced by the manufacturer, a service agent or a similarly qualified person in order to prevent safety hazards.

  • Page 5: Accessories

    • Alterations to the product without express permission from the manufacturer • Use for purposes other than those described in this manual Dometic reserves the right to change product appearance and product specifications. 7 Technical description The ventilation system is used to ventilate the air inside a vehicle in which it is installed on a high rate without change of the internal temperature.
  • Page 6   The ventilation system can be connected to a smartphone, tablet or laptop via WLAN to control the appliance via the Dometic Interact App. The InVentilate has four different air and climate modes. • AUTO mode: The AUTO mode ensures that the ventilation system is automatically turned on when the air in the vehicle is poor and automatically turned off...

  • Page 7: Operation

      Symbol Description The current air quality. Low: The air quality is poor to worse. Medium: The air quality is worse to average. High: The air quality is average to good. Indicates the air purifier is active (optional). When the air purifier is turned off, the standby mode is activated. The fans and the motor do not run.
  • Page 8   Switching on/off Note The ventilation system can give off a slight smell when first used. The smell disappears after a short time. Press the button to switch the ventilation system on or off. Selecting the mode The AUTO mode is selected at turn on. 1.
  • Page 9   1. Dismantle the air distribution box (ADB) center cover. 2. Press the reset button.

  • Page 10: Cleaning And Maintenance

    Ensure that the ventilation system is within range of the WLAN to establish an internet connection. Download the Dometic Interact App. Google Play https://play.google.com/store/apps/details?id=com.dometicapp App Store https://apps.apple.com/de/app/dometic-interact/id1498200094 Follow the instructions in the Dometic Interact App. 9 Cleaning and maintenance WARNING! Electrocution hazard Always turn the ventilation system off during cleaning and maintenance.
  • Page 11   Cleaning NOTICE! Damage hazard • Do not clean the ventilation system with a high-pressure cleaner. • Do not use sharp or hard objects or cleaning agents for cleaning as these may damage the ventilation system. • To clean the roof ventilation system, use water with a gentle cleaning agent. Never use petrol, diesel or solvents.
  • Page 12   3. Dismantle the interior air filter. 4. Insert a new outside air filter. 5. Replace the ADB center cover.

  • Page 13: Troubleshooting

      6. Press the button to switch the ventilation system on. 10 Troubleshooting Problem Possible cause Suggested remedy The ventilation system does not switch No power supply connected. Check the power supply. The voltage is too low (<12 V). Contact an authorized service agent.
  • Page 14   Error codes Problem Possible cause Suggested remedy Communication error with the VOC sen- indicators flash. Press the button for a few sec- sor. onds to reset the error for the cur- rent power cycle. Contact an authorized service agent. Communication error with the perfor- Check that the performance boost- indicators flash.

  • Page 15: Disposal

      Problem Possible cause Suggested remedy The motor does not switch on. indicators Press the button for a few sec- flash. onds to reset the error for the cur- rent power cycle. Contact an authorized service agent. The filter are worn out. indicators flash.
  • Page 16 Ventilation 50 m³/h Heat recovery efficiency 72 … 87 % Weight 7 kg 7.14 kg Certifications ACC3100D LED Light Input voltage 12 V Input power 8.6 W Power consumption 0.21 kWh/24h 17.2 Ah –   20 °C (–   4 °F) … 40 °C (104 °F)
  • Page 17   ACC3100D Air Purification Module Input voltage 12 V Input power 0.36 W Energy consumption 0.01 kWh/24h 0.72 Ah –   20 °C (–   4 °F) … 70 °C (158 °F) Temperature range Weight 70 g...
