8.6.8 GPS primary
output
8.6.9 Remote
POWER ON
control
8.6.10 DC power
input

8.6.11 Time mark

05/01/97 REV H
The primary input port supports communications via the NMEA-1083
V2.0 and CMC Binary protocols. The port characteristics are listed below.
Signal type: RS-232 or RS-422
•
Data format: NMEA 0183 or binary control commands
•
Baud rate: 300 to 38,400, default of 4800 (8 bits, no parity, 1 stop bit),
•
jumper-selectable
5 to 40 VDC
10 to 40 VDC
1 Hz timing pulse with 1 Hz duty cycle.
Section 8 - Input/output configurations
PAGE 35
