Shike Kam Wah Electronic SBT-186 Instructions

Thank you very much for choosing SBT-186 Bluetooth.Headphones
produced by JBUNION and Kakabomi!
Your new JBU Over Ear Wireless Headphones are designed to link with your
Bluetooth enabled device to allow you to wirelessly listen to music and answer
phone calls within the normal 10 meter Bluetooth operating range. SBT-186 is
compatible with Apple iPhone, iPad, iPod, Android phones or any tablets and
notebooks with Bluetooth audio support.
SBT-186 has a small size structure, fit, soft, adjustable headband cushion and
earmuff, which is specially tailored for children aged 3-8 years. The product has
built-in sound pressure control technology. No matter how you adjust it, the
volume is always controlled within the safe range of 85dB. The materials are
high-grade environmental protection materials certified by European and
American safety certification. They meet the European Union EN71 and American
ASTM, CPSIA international certification standards for children's products.
Please feel free to use them.

Specifications

BT Specification Bluetooth V5.3
A2DP, AVRCP, HFP, HSP.
BT Profiles Supported
Effective range Appox. 10 m
Speaker diameter 40mm
Impedance 32Ohm
Sensitivity 82±3dB at 1KHz
Frequency Range 20Hz – 20KHz
Rechargeable Battery 300mAh
Working Voltage: 3.7V
Standby Current ＜8uA
Max working electric current 17mA
Charging socket Type-c
Talk time 12hours
Music Play time 11hours at 80% volume
Standby Time (un-paired) 90 days or more
Charging Time 2 hours
Product outline
1 Bluetooth & SD/ TF Card mode
2 Volume Up / Skip Button
3 Volume Down / Previous Button
4 Charging indicator
5
Multi-funcation Button (MFB)
6 Type-c Port
SD/ TF Card Slot
7
Microphone
8
AUX Jack IN/OUT
9

Using Your Earphone

Very happy you own this Kids headphones stereo Bluetooth wireless
headphones, We are here showing you how to use it, you will easy to use this
headphones after reading this instructions. The headphones have voice prompt
function，real-time reporting of the current state, it is easy to use and
convenient.
MODEL: SBT-186
Type-C
Auxiliary Input Cable
to working

Power On/Off, First Time Pairing

While the headphones are switched off, press and hold the
seconds until you hear the voice 'Power on' and 'Pairing'.
The white Indicator will flash alternately to enter pairing mode. Go to the
Bluetooth settings on your phone and select 'SBT-186' from
the list. Once paired, you will hear 'Connected', That meant pairing is completed.
While the headphones are switched on, press and hold the
seconds until hear the voice 'Power off' to switch off the headphone.
Power on
Press and hold Button 2 seconds
Power off Press and hold Button 5 seconds
Volume + Single press Button
Volume -
Single press Button
Previous song Press and hold Button
Next song Press and hold Button
Pause/Play Single press Button
Pick up/Hang up Single press Button
Refuse phone call Long press Button
TF version Slide switch according to the icons
BT version
Slide switch according to the icons
Set up siri Double clic Switch on button
MICRO-SD/TF CARO MODE
1.In no-card state, insert the Micro -SD/TF card， the LED indicator flashes quickly，the voice prompts "SD
card", automatically enter the Micro-SD/TF Card play mode，the LED indicator flashes once every seconds.
2. When the card is inserted, slide switch to start the play mode.
Note: Some of the functions described above may not be supported on your
specific Bluetooth device. Please check the manual of your device to ensure the
features supported by your device.

Charging

Before charge，turn off the headphone，The headphones charging cable connect
to the computer/Adaptor Type-c port，the LED light Indicator will turn on in Red, it
means connect with the Type-c successfully and the headphone is charging. When
the charging is completed, the headphones charging indicator will turn off. When
the headphones broadcasts a voice prompt: "low battery, please charge", it
indicates that the power of the headphones is too low. Please charge your
headphones in time.
Computer
connected
USB Adaptor
(not included)
outlet
Note:
1. Do not turn on the headphone when charge，Or will damage headphone
hardware and battery life.
2. This headphones haven't waterproof function，Please pay attention to water
and moisture，so that to confirm the headphone can working perfectly.
3. The headphones can not be long-term placement, please charge and discharge
once a week, thereby extending battery life.
KINDLY REMINDER
Continuous use high volume might damage hearing

WARNING

Adjust headset to the proper volume. Too Loud sound may damage your ears.
for traffic safety, never use the headset while riding a bicycle,
motor bike, or while driving a car, it is dangerous to increase
the volume too much because you can not hear external sounds.
Take great care about traffic around you.
please don't pull the cord too hard in case of breakage.
The "JBU" & "JBUNION" logo and other products,service names and logos are the
intellectual property of its owner.other third-party trademarks belong to their respective
owners are used for reference only and if third -party owners wished to removed their
reference in association with this packaging. please contact the owner of "JBU" &
"JBUNION" logo, Any use of the "JBU" & "JBUNION" Mark is prohibited without express
written permission.
Proprietor of a mark: Shenzhen Shike Kam Wah Electronic Co.,Ltd.
Manufacturer: Shenzhen Shike Kam Wah Electronic Co.,Ltd.
Address: 1st Floor NO.#36,LangKou Industrial Park,LangKou Community, Dalang,Longhua
District,ShenZhen,Guangdong,P.R.China
Website: www.china-headphone.com
E-mail: info@china-headphone.com
Service hotline: 0086-755-29538997
