- Page 1 NATURAL GAS / LPG FIRED HEATER GENERATEUR D’AIR CHAUD AU GAS NATUREL/L.P.G. L-L 110.01-BM INSTRUCTION MANUAL MANUEL D’INSTRUCTIONS...
- Page 2 WARNING BEFORE USING THE HEATER, READ AND UNDERSTAND ALL INSTRUCTIONS AND FOLLOW THEM CAREFULLY. THE MANUFACTURER IS NOT RESPONSIBLE FOR DAMAGES TO GOODS OR PERSONS DUE TO IMPROPER USE OF THE UNITS. GENERAL HAZARD WARNING FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN RESULT IN DEATH, SERIOUS INJURY AND PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION, CARBON MONOXIDE POISONING, AND / OR ELECTRICAL SHOCK.
- Page 3 WARNING The heater is designed and approved for use as a construction heater in accordance with Standard ANSI Z83,7 CGA 2.14. CHECK WITH YOUR LOCAL FIRE SAFETY AUTHORITY IF YOU HAVE QUESTIONS ABOUT APPLICATIONS. Other standards govern the use of fuel gases and heat producing products in specific applications.Your local authority can advise you about these.
-
Page 4: Control Panel
CONTROL PANEL COMBUSTION CHAMBER BURNER DIFFUSION RING FLAME GUARD SHIELD COOLING FAN IONIZATION ELECTRODE IGNITION ELECTRODE CONTROL FLAME RESET BUTTON HEATING SWITCH ROOM THERMOSTAT PLUG POWER CONTROL LAMP SAFETY THERMOSTAT LAMP VENTILATION MODE SWITCH SAFETY THERMOSTAT RESET BUTTON CABLE FASTENER FOR POWER CORD MANIFOLD ASSEMBLY Fig. -
Page 5: Installation Instruction
IMPORTANT Before using the space heater, carefully read all of the instructions and follow them scrupulously. The manufacturer cannot be held responsible for damage to persons and/or property caused by improper use of the equipment. This instruction manual is an integral part of the equipment and must therefore be stored carefully and passed on with the unit in the event of a change of ownership. -
Page 6: Gas Line Connections
connecting the electrical cable to the thermostat plug (10): • Take the plug (c) out of the power switchboard, open it and remove the electrical jumper between terminals 2 and 3 of the plug; • Connect the thermostat electrical cable to terminals 2 and 3 of the thermostat plug (c);... - Page 7 I° STARTUP Warning The heater is supplied after a complete functional test and it’s THE CONVERSION SHALL BE CARRIED OUT BY A therefore prearranged for one of the gas (natural or L.P.G.) indicated MANUFACTURER’S AUTHORIZED REPRESENTATIVE, in Tab. I: an adhesive label applied close to the rating plate indicates IN ACCORDANCE WITH THE REQUIREMENTS OF THE MANUFACTURER.
-
Page 8: Transport And Handling
chamber (4) must be put back in place and secured TRANSPORT AND HANDLING with the relative screws before operate the heater. Warning Before moving the unit: Operating the heater without the flame guard panel of combustuion • Stop the machine as indicated in the “STOP” chamber (4) can cause the flame to work with risk to the health of paragraph;... - Page 9 FAULT CAUSE REMEDY • Check functioning and position of switch • The heater does not start: • Check the mains • No power supply lamp is off • Check power connections • Check the fuse • Switch (9) in wrong position •...
-
Page 10: Wiring Diagram
WIRING DIAGRAM CONTROL BOX AIR PRESSURE SWITCH ROOM THERMOSTAT PLUG IONISATION ELECTRODE ELECTRIC PILOT LAMP VENTILATION SWITCH FUSE OVERHEAT THERMOSTAT GAS TRAIN TÉMOIN BLOCAGE CONDENSER REMOTE BLOCK INDICATOR LIGHT FAN MOTOR LLI2 LAMPE TEMOIN SECURITE DE FUA FUSE SURCHAUFFE HEATING SWITCH TRANSFORMER H.V. - Page 11 WIRING DIAGRAM ACCESSORIES...
-
Page 12: Technical Specifications
Noise level at 1 m [dBA] Dimensions, L x W x H [in] 45,1 x 23,2 x 17,4 46,7 x 26,9 x 21,1 Heater Weight [lb] Biemmedue S.p.A. Via Industria 12 12062 Cherasco (CN) – ITALIA www.biemmedue.com – e-mail: info@biemmedue.com...
