Operator's Manual
Articulated Tractor
MT955E
AGCC0955.F...1001-
MT965E
AGCC0965.F...1001-
MT975E
AGCC0975.F...1001-
North America
4205 River Green Parkway, Duluth GA 30096 USA
March 2015
Challenger is a registered trademark of Caterpillar
Inc. and is used under license by AGCO.
556263D1C
© AGCO 2015
NA
Original Operator's Manual
English

Advertisement

Table of Contents
loading

Related Manuals for Challenger MT955E

Summary of Contents for Challenger MT955E

  • Page 1 AGCC0955.F...1001- MT965E AGCC0965.F...1001- MT975E AGCC0975.F...1001- North America 4205 River Green Parkway, Duluth GA 30096 USA March 2015 Challenger is a registered trademark of Caterpillar Inc. and is used under license by AGCO. 556263D1C © AGCO 2015 Original Operator's Manual English...
  • Page 2 CALIFORNIA Proposition 65 Warning WARNING: Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, or other reproductive harm. WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
  • Page 3 Table of contents Articulated Tractor 1 Safety ..............11 .
  • Page 4 Table of contents 1.5 Informational signs ..........34 1.5.1 Informational signs .
  • Page 5 Table of contents 3.8 Steering wheel ........... . . 76 3.8.1 Horn .
  • Page 6 Table of contents 3.18 Air system operation ..........131 3.18.1 Air system operation .
  • Page 7 Table of contents 3.23.9 ISO 11783 connector ..........160 3.24 Machine performance .
  • Page 8 Table of contents 3.30.1 Special applications drawbars and hitches ......202 3.30.2 Ballasting for towed scrapers ........202 3.30.3 Hydraulic connections for the towed scraper .
  • Page 9 Table of contents 4.8 Cooling system ........... . 234 4.8.1 Cleaning the cooling cores .
  • Page 10 Table of contents 5.1 Heating and air conditioning troubleshooting ..... . . 287 ........288 5.2 Electrical system troubleshooting 5.3 Brake troubleshooting .
  • Page 11 Table of contents 1. Safety 1.1 Safety information ............13 1.1.1 Operator Manual .
  • Page 12 Table of contents 1.4.3 Danger hazard - Starter bypass ..........33 .

  • Page 13: Important Safety Information

    1. Safety 1.1 Safety information 1.1.1 Operator Manual This operator manual uses the latest information available at the time of publication. Read the operator manual carefully before operating the machine. Right-hand and left-hand, as used in the operator manual, is determined by facing the direction that the machine travels when in use.

  • Page 14: Safety Alert Symbol

    1. Safety 1.1.3 Safety alert symbol The safety alert symbol means Attention! Become Alert! Your Safety Is Involved! Look for the safety alert symbol both in this manual and on safety signs on this machine. The safety alert symbol will direct your attention to information that involves your safety and the safety of others.

  • Page 15: General Hazard Information

    1. Safety If parts have been replaced or a used machine has been purchased, make sure all safety signs are present and in the correct location and can be read. Illustrations of safety sign locations are located at the rear of this section.

  • Page 16: Asbestos Information

    1. Safety Inhaling gas from air conditioner refrigerant through a lighted cigarette can cause bodily harm or death. Unless being instructed differently, complete the maintenance under the following conditions: • Turn the battery disconnect switch to "off" position. • The machine is parked on level ground. •...

  • Page 17: Before Starting The Engine

    1. Safety 1.1.12 Before starting the engine Start the engine only from the operator compartment. Never short across the starter terminals or batteries. Shorting can damage electrical system or cause unexpected machine movement. Adjust the seat so full pedal travel can be achieved with operator's back against seat back.

  • Page 18: Operator Station

    1. Safety Only operate the machine while in the operator's seat. Securely fasten the seat belt while operating the machine. Only operate the controls while the engine is operating. Check for the correct operation of all the controls and the protective devices. As a warning honk the horn twice to alert others in the area to prevent personal injury because of machine movement.

  • Page 19: Rollover Protective Structure

    1. Safety Any item brought into the cab must not extend into defined operator space. Secure loose items. Objects must not pose an impact hazard in rough terrain or if there is a rollover. 1.1.18 Cut and crushing prevention Support the equipment correctly when performing work below the equipment. Do not rely on the hydraulic cylinders to hold up the equipment.
  • Page 20 1. Safety 1.1.20 Batteries A lead acid battery generates flammable and explosive gases. Keep sparks and flames away from the battery. WARNING: WARNING: Sulfuric acid in battery electrolyte is poisonous. The acid is strong enough to burn skin, eat holes in clothing and cause blindness if got into eyes.

  • Page 21: Burn Prevention

    1. Safety 1.1.21 Burn prevention Do not touch any part of an operating engine. Other components such as the transmission, the axles and the oil reservoir can also be hot. Let the engine cool before performing any maintenance on the engine. Release all pressure in air, oil, lubrication, fuel and cooling systems before disconnecting any line fittings or related items.

  • Page 22: Fluid Penetration

    1. Safety 1.1.25 Fluid penetration Always use a board or cardboard when checking for a leak. Leaking fluid under pressure can penetrate the body tissue. Fluid penetration can cause serious injury and possible death. A pin hole leak can cause severe injury. If fluid is injected into the skin, get treatment immediately.

  • Page 23: Noise Prevention

    1. Safety 1.1.27 Noise prevention Wear proper hearing protective devices such as earmuffs or earplugs to prevent loss of hearing due to high noise levels. Fig. 14 1.1.28 Fire and explosion prevention Use caution when refueling a machine. Do not smoke while refueling and do not refuel near open flames or sparks.

  • Page 24: Fire Extinguisher

    1. Safety explosive. Repair such components in a well ventilated area away from open flames or sparks. Inspect all lines and hoses for wear or for deterioration and replace if necessary. Route hoses correctly. Lines and hoses must have sufficient support and secure clamps. Tighten all connections to recommended torque.

  • Page 25: Safety Signs And Labels

    1. Safety 1.2 Safety signs and labels 1.2.1 Safety signs and labels There are several specific safety signs on this machine. The exact location of the hazards and the description of the hazards are reviewed in this section. Become familiarized with all of the safety signs. Make sure all of the safety signs are legible. Clean the safety signs or replace the safety signs if you cannot read the words.

  • Page 26: Warning Signs

    1. Safety 1.3 Warning signs Fig. 17 Articulated Tractor 556263D1C...
  • Page 27 1. Safety 1.3.1 Warning - Battery explosion Warning sign - Battery explosion Improper jumper cable connections can cause an explosion resulting in personal injury. When using jumper cables, always connect the positive cable, from the external power source, to the positive jump start post and the negative cable, from the external source, to the engine block or frame.
  • Page 28 1. Safety 1.3.4 Warning - Fall off hazard Warning sign - Fall off hazard To avoid personal injury or death, do not allow anyone to ride on any part of the machine or any attached equipment 1.3.5 Warning - High pressurized fluid Warning sign - High pressurized fluid Avoid contact with high pressure fluids.

  • Page 29: Warning - Hot Surface

    1. Safety 1.3.6 Warning - Hot pressurized coolant Warning sign - Hot pressurized coolant Hot coolant can cause serious burns. To open the cooling system filler cap, stop the engine and wait until the cooling system components are cool. Loosen the cooling system pressure cap slowly to relieve pressure.
  • Page 30 1. Safety 1.3.9 Warning - Operators Manual Warning sign - Operators manual Read and understand the operator and safety instructions in the operator's manual and on the machine. Locate and understand the control operations. Failure to follow the safety and operational instructions can result in serious operator or bystander injury.
