- Page 1 Installation Manual SYSTEM: Closure...
-
Page 3: Table Of Contents
TABLE OF CONTENTS PRE-INSTALLATION CHECKLIST BOXES CHECKLIST TOOLS CHECKLIST HOUSING UNIT: INSIDE THE BOX INSTALLATION LASER CHECK TUBE UNIT: INSIDE THE BOX INSTALLATION REMOTE CONNECTION WALL PANEL: INSIDE THE BOX INSTALLATION SIDE GUIDE: INSIDE THE BOX INSTALLATION BOTTOM HOUSING COVER MOTOR LIMITS... - Page 4 BOXES CHECKLIST Before getting started, A. make sure you received each of the following boxes. Housing Unit Tube and Bottom Bar Wall Panel Side Guide...
- Page 5 TOOLS CHECKLIST These are the tools you'll need to install your system. Revit Gun Flat screwdriver Drill Bits Tape measure Extension cord Ladder Stapler Leveler laser Material ifter Drill With Aluminum Blade...
- Page 6 HOUSING UNIT: INSIDE THE BOX Motor bracket Housing (amount of units depends on the legth of your specific system) Unit connector Housing cover Idler bracket...
- Page 7 HOUSING UNIT: INSTALLATION INSTRUCTIONS NOTE: start with the side closest to the room power Lift motor bracket and side up to Lift up one housing unit end of housing unit Insert screws to top of motor Repeat with second housing and bracket and tighten into ciling idler bracket Insert screws on either side of unit...
- Page 8 HOUSING UNIT: LASER CHECK NOTE: it is extremely importan that all housing units are the same exact height. Use the laser to ensure the housing units is leveled Double check both sides using a laser and a tape measurer Make sure there is no space between housing units...
- Page 9 TUBE UNIT: INSIDE THE BOX Motor End Kedar side Idler end...
- Page 10 TUBE: INSTALLATION INSTRUCTIONS Use material lift to raise tube housing system Insert pin to secure the tube Insert motor end of tube into the NOTE: make sure the wire is not motor bracket stuck in the pin Insert idler end of tube into the idler Insert pin to secure the tube bracket Secure the wire by sliding the...
-
Page 11: Remote Connection
REMOTE CONNECTION INSTRUCTIONS hold the remote facing housing units Turn remote around and use a screwdriver to press reset button for 6 seconds (motor will begin moving up and down) Use up and down buttons to bring keder side of tube to the bottom (facing the floor) -
Page 12: Wall Panel
WALL PANEL: INSIDE THE BOX large panel small panel... - Page 13 WALL PANEL: INSIDE THE BOX INSTRUCTION Slide small panel into keder side to Raise small panel to housing unit tube NOTE: zipper must be hanging down Put material (On brown paper) on roll out wall panel and place roller the floor and place large panel on on the keder side NOTE: before lifting panel you are going to insert bottom bar , (see next page)
- Page 14 WALL PANEL: INSTALLATION Bottom bar 4 end corners Screws INSTRUCTION Slide bottom bar into keder side of Push end covers onto either sides large panel of the bottom bar Insert screws to connect end cover make sure keder is in between to bottom bar end covers and screw end covers together...
- Page 15 WALL PANEL: INSTALLATION Roll large panel with bottom bar Roll large panel with bottom bar side facing in side facing in Use material lift to raise large panel Start zipping large panel to small to small panel (zipper facing up) panel Staple the beginning to secure Zip all the way and staple the end...
-
Page 16: Side Guide
SIDE GUIDE: INSIDE THE BOX Track holder Side Guide inside Screws... - Page 17 SIDE GUIDE: INSTALLATION INSTRUCTION Use tape measurer to measure exact height from floor to bracket (which is inside the end of the housing) Remove track holders from side Use metal on the side guide to guides detect where the magnets are NOTE: this is extremely important! Use saw to cut side guides to Use saw to cut track holders -...
-
Page 18: Bottom Housing Cover
SIDE GUIDE: INSTALLATION Lift side guides against either side Make sure side guides are leveled of wall and perfectly aligned with walls Insert screws into side guide and side track holder into side guides screw into wall horizontally Use screw driver to prop track Insert side of wall panels into track holders up holders... -
Page 19: Motor Limits
MOTOR LIMITS Use a screwdriver to press reset Use up button to raise wall panel button for 6 seconds until desired height limit Hold stop button for 5 seconds Use up button to Lower wall panel until desired height limit Hold stop button for 5 seconds... - Page 20 CONGRATULATIONS ON YOUR MASTERPIECE! View with partition raised View with partition lowered...
