REVEAL
®
Operating Instructions for REC02U
HD 4-CH Dual SD Card Hybrid HD MDVR
Please read this manual completely before operating the SYSTEM
Product Note:
SET THE TIME ZONE
Properly install (2) Class 10 256GB SD cards (Not included)
(1) 128GB Class 10 SD Card currently factory installed
Become familiar with retrieving video
1
2023 Verity Rear Vision Systems / All rights reserved / Subject to Change
Advertisement
Table of Contents
Related Manuals for Verity Audio Reveal REC02U
Summary of Contents for Verity Audio Reveal REC02U
- Page 1 REVEAL ® Operating Instructions for REC02U HD 4-CH Dual SD Card Hybrid HD MDVR Please read this manual completely before operating the SYSTEM Product Note: SET THE TIME ZONE Properly install (2) Class 10 256GB SD cards (Not included) (1) 128GB Class 10 SD Card currently factory installed Become familiar with retrieving video 2023 Verity Rear Vision Systems / All rights reserved / Subject to Change...
-
Page 2: Table Of Contents
Contents ABOUT US .................3 THINK SAFETY FIRST ...............4 SYSTEM FEATURES ..............6 SYSTEM OVERVIEW ..............8 SYSTEM OVERVIEW ..............9 REMOTE OVERVIEW............... 10 USER LOGIN ................13 PASSWORD SETUP ..............14 MODIFY / ADD USER............... 15 DELETE USER ................. 16 DATE AND TIME ..............17 VEHICLE SETUP .............. -
Page 3: About Us
ABOUT US Verity does not just buy systems off the shelf overseas, put our logo on them, and ship them out. We work with engineers, some at our location in Mishawaka, Indiana to design camera systems to meet the safety needs of several industries. -
Page 4: Think Safety First
THINK Read our manual before operating SAFETY or installing the REC02U. FIRST Verity products are intended to be installed as a supplement, and our observation systems and/or products are not intended to be a substitute for mirrors or other standard motor vehicle equipment which may be required by law. - Page 5 WARNING Do not pull cables tightly and add tension to them. A drip loop is required where applicable. Do not place cables where they can be crushed in any manner. CAUTION To avoid damage to the electronic circuit, stop using this product while doing welding work to the vehicle and/or trailers.
-
Page 6: System Features
SYSTEM FEATURES Features: H.265/H.264 image compression encoding 4 channels of D1/960H/AHD 720P simultaneous audio and video recording/replaying 4- channel of 960H + 1- channel IPC 1080P HD camera full- framed recording Air video interface is used to provide high reliability and strong anti-seismic property Records 8 seconds after power failure Two SD cards supported 256 GB for each. - Page 7 Audio Audio Input: 4 Channels Audio Output: 2 Channels - Front Panel 3.5mm Jack, Rear Panel on 24pin I/O Port Recording & Storage Image Resolution: CIF / HD1 / D1 / 960H / 720P Video Coding: ISO14496-10 Industry Standard Video Bit Rate: CIF (Common Intermediate Format): 1536Kbps ~ 128Kbps HD1/D1: 2048Kbps ~ 400Kbps 960H: 2048Kbps ~ 400Kbps...
-
Page 8: System Overview
SYSTEM OVERVIEW SIM A slot does not apply to the REC02U Metal Connector Tamper-resistant Cover Security cover helps prevent tampering or damage to the cable connection on the back of the MDVR. -
Page 9: System Overview
SYSTEM OVERVIEW REMOTE CABLE FRONT A V CABLE CONNECTION COVER AV OUT / SENSORS POWER CABLES KEYS & ACCESSORIES MANUAL... -
Page 10: Remote Overview
REMOTE OVERVIEW LOGIN: When the recorder is set with a password, press the Login key to input your Password. KEY POINT: Because of security reasons, the DVR does not provide password recovery and reset features. Always keep a copy of your password written down. - Page 11 INFO: Check information Quad 4 Image Format: Number keys 1, 2, 3, 4 on the monitoring interface, are used to switch between quad view and single view; press the Quad View key to display 4 screens. You can press number 1/2/3/4 to display channel 1, channel 2, channel 3 and channel 4, respectively.
- Page 12 For these applications, our IR extender will allow you to place the DVR hidden behind a wall and use our ADD02CP. This IR/LED panel has a 16 foot extended cable. This panel provides feedback on the operation of the DVR. Never miss another recording due to issues that may occur over the years.
-
Page 13: User Login
USER LOGIN Click the login button on the remote; the login interface will appear. Please input your User Name, Password, and the menu will show up. The default UserName is admin, with a default password of 888888 If you have not set these values, you can use the right arrow button to pass through these. -
Page 14: Password Setup
PASSWORD SETUP Then Click USER in the Basic Setup Screen Password Set Up # 1 Password on/off # 2 ADD a user # 3 MODIFY a user # 4 DELETE a user # 5 SAVE a user IMPORTANT NOTE for security reasons, there is NO retrieval option for passwords. -
Page 15: Modify / Add User
MODIFY / ADD USER When you add/modify a user, write down the password and keep in a safe place (it cannot be retrieved). Enter NAME, set LEVEL, add PASSWORD, and CONFIRM it. Click SAVE. There are two levels of users: System user: Grants unlimited access and change... -
Page 16: Delete User
privileges, including creating User Accounts, Passwords, and restricted access Rights General user: Provides Password, limited rights Password: 6 digits (numbers only) *Confirm the new settings are correct and save the file. Note: When working with users in the opening screen, you need to select a user if you wish to modify or delete that user. -
Page 17: Date And Time
DATE AND TIME Click on Click on BASIC TIME DATE TIME: THIS IS IMPORTANT for timestamping when recording. This is also necessary to allow for file searching by date and time. Date Format: Selectable DST Switch: used to sets the parameters for the daylight saving time option. - Page 18 1. It is advised to enable the auto-maintenance feature when the device is operating for a prolonged time, allowing the device automatically restarts within the set maintenance time. NOTE: The DVR will reboot during this time. It will stop recording during the quick reboot.
-
Page 19: Vehicle Setup
VEHICLE SETUP To access, use the following: Click on Click on BASICS VEHICLE Enter information related to the driver and company. The DEVICE NUMBER is the only field required to have data entered. SERIAL NUMBER: predetermined, no input needed BRANCH NAME: Company name (up to 20 characters) OFFICER NAME: Driver name or ID (Up to 20 characters) SIM NUMBER: phone number for a MDVR contained SIM Card if installed... -
Page 20: Install Sd Card
INSTALL SD CARD Install SD Card 1: label side facing up Install SD Card 2: Label side facing down FORMAT SD CARD To access, use the following:... - Page 21 Click on Click on TOOLS FORMAT NOTE: SD card must be formatted in the DVR. FORMAT allows for the formatting of the SD card. This screen also supplies information about space available and space used. IMPORTANT NOTE: when formatting SD card, the data on the SD card will be erased.
-
Page 22: Record Setup
Channel recording status: If the channel icon is not in a red box “CH1”, that channel is not recording. If the channel icon is in red box, that channel is recording. Not recording Recording RECORD SETUP To access, use the following: Click on Click on RECORD... -
Page 23: Recording Schedule
Packet Time: Playback file sizes. Select from 5, 15, 30, 45, and 60-minute files. The factory Default is 30 mins. Overwrite: allows the MDVR to continue recording over the oldest file. This starts when only 2GB is available. RECORDING SCHEDULE The Recording Schedule may be determined by the vehicle OEM To access, use the following:... -
Page 24: Main Stream (Recording) Setup
MAIN STREAM (RECORDING) SETUP To access, use the following: Click on Click on RECORD STREAM RES: Must Be 960H FPS: Frames per second: 25 fps is recommended PIC QUALITY: Quality level of video 1= Best to 8=Lowest Quality... -
Page 25: Search
SEARCH Click on Click on SEARCH VIDEO There are two types of searches. LOG SEARCH: covers events such as: on–off, menu adjustments, etc., and Video searches. VIDEO SEARCH: Helps find the desired date/ time range. Dates with recordings will be highlighted... - Page 26 When a time frame is selected, it will open the Video Search List...
-
Page 27: Warranty
WARRANTY LIMITED ONE (1) YEAR WARRANTY 1. CSS products’ warranties are not transferable. The warranties apply to the retail consumer for one (1) year and covers against defects in material and workmanship on Verity systems. We do not warranty our cables which are QC tested at three different stations before shipping. All components must be installed in compliance with all Federal, State, and Local government requirements. -
Page 28: Technical Support
Technical Support A service ticket can be filled out online to supply the quickest service. The service ticket can be easily found on our web site: www.verityrvs.com or use the code to the right. Please have the serial number, which is found on the top of the DVR, when contacting the service department.
