- Page 1 FREESTANDING, ADJUSTABLE BIKE STORAGE RACK Sku: RGFSBR1 User Guide 833-722-0121 raxgo.com support@raxgo.com...
- Page 2 FREESTANDING, ADJUSTABLE BIKE STORAGE RACK Sku: RGFSBR1 User Guide Thank you for purchasing the Freestanding, Adjustable Bike Storage Rack. This User Guide is intended to provide you with guidelines to ensure that operation of this product is safe and does not pose risk to the user.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS WARNING: CHOKING HAZARD – Small parts: This product contains small parts and is not suitable for children under 3 years old. Remove all packaging materials before using this device. Please keep all packaging materials out of reach of children and pets. - Page 4 SAFETY PRECAUTIONS Do not step, climb, or hang on the rack. Do not attempt to modify the rack or perform repairs on your own. If the rack is faulty or becomes damaged, you should take it to an authorized serviceperson for repairs. This rack is intended for use with a bike only.
-
Page 5: Parts List
PARTS LIST PARTS LIST... - Page 6 PARTS LIST Hooks with hand knob Bike rack 1 PC Hanger 1 PC 2 PCS screws Screws, cylinder nuts, Hooks with hand knob 6 PCS Included tool : Allen wrench 2 PCS and washers screws PARTS LIST...
- Page 7 ASSEMBLY INSTRUCTIONS 1. Remove the two (2) screws and cylinder nuts from the bike rack (a). 2. Place the hanger (b) against the bike rack (a). Then, fasten it to the rack (a) using two (2) screws, cylinder nuts, and washers (d), use the included allen wrench if needed.
- Page 8 3. Remove the hand knob screws from the hooks (c). Then, insert the two (2) hand knob screws through the elongated holes on both ends of the hanger (b). 4. Place the hooks (c) onto the hand knob screws from the other side of the hanger (b).
- Page 9 OPERATING INSTRUCTIONS • Pull out the lever on the bottom locking mechanism to adjust the feet of the rack. Push the lever back in place to lock the rack’s feet in its current position. • Pull out the lever on the top locking mechanism to adjust the extendable pole of the rack.
- Page 10 • Tilt the hanger left or right to adjust the position of the hooks. Loosen the screws on the hanger with the allen wrench (if needed) to adjust the hanger. • Loosen the hand knobs on the hooks to move them left or right along the elongated holes to adjust the distance between the hooks.
-
Page 11: Specifications
• When hanging a bike on the rack, mount the bike onto the rack from the top tube (or crossbar) of the bike. SPECIFICATIONS Product type: Bike rack Color/finish: Silver Extended dimensions: 24.4" x 24.91" Material: Steel Folded dimensions: 4.44" x 3.93" Team lift needed: No Minimum height: 26.7"... - Page 12 Company’s property. Refunds can only be given if the original Product is returned. This Warranty does not apply to: (a) Any non-RaxGo Freestanding, Adjustable Bike Storage Rack product, hardware or software, even WARRANTY...
- Page 13 Product; (b) Damage caused by use with non-RaxGo Freestanding, Adjustable Bike Storage Rack products; (c) Damage caused by accident, abuse, misuse, flood, fire, earthquake, or other external causes; (d) Damage caused by operating the Product outside the permitted or intended uses described by the Company;...
- Page 14 1-833-722-0121 RAXGO is a trademark of C&A IP Holdings LLC in the US. All other products, brand names, company names, and logos are trademarks of their respective owners, used merely to identify their respective products, and are not meant to connote any sponsorship, endorsement, or approval.
