AGM APACHE A-9 AVIATOR User Manual

Night vision aviation goggle system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
APACHE A-9 AVIATOR
Night Vision Aviation Goggle System
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APACHE A-9 AVIATOR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AGM APACHE A-9 AVIATOR

Summary of Contents for AGM APACHE A-9 AVIATOR

  • Page 1 APACHE A-9 AVIATOR Night Vision Aviation Goggle System USER MANUAL...
  • Page 2 AGM Global Vision. If you have questions that are not covered in this manual, or need service, contact AGM Global Vision customer support for additional information prior to returning a product.

  • Page 3: Table Of Contents

    LIST OF CONTENTS TITLE PAGE Safety Summary SECTION 1. GENERAL INFORMATION 1.1 System Description 1.2 Key Features 1.3 Standard Components SECTION 2. OPERATING INSTRUCTIONS 2.1 Installation and mounting 2.2 Controls and Indicators 2.3 Operating Procedures SECTION 3. MAINTENANCE INSTRUCTIONS 3.1 Cleaning Procedures 3.2 Troubleshooting 3.3 Preparation for Extended Storage SECTION 4.

  • Page 4: Safety Summary

    It is, however, a precision instrument, and should be handled and transported with care to ensure long life and trouble-free operation. Do not drop, throw, strike, or otherwise carelessly mishandle the Apache A-9. AGM Global Vision...

  • Page 5: Section 1. General Information

    1 GENERAL INFORMATION SYSTEM DESCRIPTION This manual provides instructions for the operator to use and maintain the Aviator’s Night Vision Imaging System (ANVIS) Model Apache A-9 (see Figures 1-1). The Apache A-9 is a self-contained night vision device that enables improved night vision using ambient light from the night sky (moon, stars, sky glow, etc.).

  • Page 6: Standard Components

    The ITEM column indicates the number used to identify items in Figure 1-2. FIGURE 1-2. STANDARD COMPONENTS TABLE 1-2. STANDARD COMPONENTS ITEM DESCRIPTION QUANTITY Apache A9 Binocular Mount Assembly AA Battery Cartridges Screwdriver Low-Profile Battery Pack Neck Cord Lens Tissue User Manual Carrying Case AGM Global Vision...

  • Page 7: Section 2. Operating Instructions

    2 OPERATING INSTRUCTIONS 2.1. INSTALLATION AND MOUNTING CAUTION: To protect the intensifier tube when the sight is not in use or when it is being operated in daylight, keep the protective lens cap securely fitted over the lens. 2.1.1 BATTERY AND POWER PACK INSTALLATION WARNING: Inspect the batteries for damage or defects before using them.
  • Page 8 6. If the low-battery indicator does not come on, replace the batteries with fresh ones and try again. Make sure the power cable is properly connected. If the indicator still does not function, return the Apache A-9 (with this power pack) and mount to Customer Support center. AGM Global Vision...
  • Page 9 2.1.3 ATTACHING THE BINOCULAR TO THE MOUNT 1. Make sure the power switch is turned OFF. FIGURE 2-4. ATTACHING THE BINOCULAR TO THE MOUNT 2. Hold the binocular with both hands with the eyepieces facing you, and slide the spring-loaded ball bearings into the channels of the mount until they lock in place (see Figure 2-4).

  • Page 10: Controls And Indicators

    Press the lock release button to rotate the binocular up or down. Lock Release Button When illuminated, indicates a low battery condition with less than Low-Battery Indicator 30 minutes of battery life remaining. AGM Global Vision...

  • Page 11: Operating Procedures

    2.3 OPERATING PROCEDURES 2.3.1 SETTING THE CONTROLS AND ADJUSTMENTS: The Apache A-9 is designed to adjust for differences in head shape and correct for most differences in eyesight. NOTE Although the Apache A-9 is designed to be used without eyeglasses, if eyeglasses are needed to read the aircraft instruments and the eyeglass lenses will fit within the eye relief distance of the binocular’s eyepiece, eyeglasses can and should be worn.
  • Page 12 Do not attempt to adjust the eye-span distance by pulling the monoculars away from each other or pushing them together. Using force on the monoculars to make this adjustment will damage the adjusting mechanism inside the adjustment shelf. Use only the eye-span knob(s) to adjust the eye-span distance. AGM Global Vision...
  • Page 13 6. If your eye-span distance has been measured prior to mounting the binocular, turn the inter- pupillary knobs(s) (see Figure 2-10) to set this value on the scale. If not, move the binoculars closer together or further apart to adjust the eye-span distance for the proper spacing between your eyes.

  • Page 14: Section 3. Maintenance Instructions

    If the equipment malfunction is not corrected by the suggested actions, or a problem occurs that is not listed in this table, please contact AGM Global Vision’s Customer Support center or your retailer. AGM Global Vision...
  • Page 15 TABLE 3-1. TROUBLESHOOTING PROBLEM PROBABLE CAUSE CORRECTIVE ACTION Binocular will not Batteries are defective. Replace batteries. come on. Batteries are missing or Insert batteries or install batteries improperly installed. correctly. Electrical contacts are dirty or Use a dry cloth or pencil eraser to corroded.

  • Page 16: Preparation For Extended Storage

    • If batteries are installed, remove the batteries from the battery pack. Batteries may be stored in the case. • Store all Goggle components in its protective case. • While not in use, do not stack heavy items on top of the protective case. AGM Global Vision...

  • Page 17: Section 4. Warranty Information

    Customer. AGM Global Vision’s liability hereunder for damages, regardless of the form or action, shall not exceed the fees or other charges paid to AGM Global Vision by the customer or customer’s dealer. AGM Global Vision shall not, in any event, be liable for special,...
  • Page 18 4.1.3 PRODUCT REGISTRATION In order to validate the warranty on your product, the customer must complete and submit AGM Global Vision PRODUCT REGISTRATION FORM on our website (www.agmglobalvision.com/ customer-support). 4.1.4...

  • Page 19: Section 5. Specifications

    5 SPECIFICATIONS 5.1 SPECIFICATIONS TABLE 5-1. APACHE A-9 SPECIFICATIONS ITEM DATA Field of View 40° Magnification 1.0x System Resolution 1.3 cy/mR minimum Diopter Adjustment -6 to +2 51–72 mm Vertical Adjustment 25 mm Fore/Aft Adjustment 27 mm Collimation: - Convergence 1.0°...
  • Page 20 AGM Global Vision MAIN OFFICE 173 West Main Street PO Box 962 Springerville, AZ 85938 Tel. +1.928.333.4300 Fax +1.480.393.4882 info@agmglobalvision.com www.agmglobalvision.com EUROPEAN OFFICE Andrey Lyapchev #7 Sofia, P.C. 1756 Bulgaria Tel. +44.292.255.0509 info@agmglobalvision.eu www.agmglobalvision.eu AGMglobalvision.com...
