- Page 1 Quick Start Guide TDTTP4000W066C_0v1 Evaluation Platform +1 805 456 1300 transphormusa.com 4kW bridgeless totem-pole PFC TDTTP4000W066C_0v1 For evaluation purposes only Design files and more at transphormusa.com/tp4kit 1/2020 © 2020 Transphorm Inc. All rights reserved. qs010.1...
- Page 2 Equipment Needed Typical Performance Curves g The TDTTP4000W066C_0v1 board g Microchip DSPIC33CK256MP506 (MA330048) 99.5 g High-voltage AC power supply for input g 12V auxiliary power adapter (included) g Electronic/resistive load 98.5 • Power range: 0W to 4400W 97.5 1000 2000 3000 4000 5000 Output Power (W) Cautions and Warnings This evaluation board is intended to demonstrate GaN FET technology and is for demonstration purposes only and no guarantees are made for standards compliance.
- Page 3 Probing Step 2: Power-up the Board There are two voltage probing sockets to measure V and V of the GaN FET shown g Insert the MicroChip Plug-In-Module (PIM) to the Conn1 slot. below. g Connect an electronic/resistive load to the corresponding marking (CN2). The requirements for the resistive load are: •...
- Page 4 Step 1: Connect the Board Important Operating Guidelines The TDTTP4000W066C is for evaluation purposes only and is not intended to be a finished product and does not include all protection features found in commercial power supplies. Additional warnings to keep in mind: Electronic/resistive load High-voltage g An isolated AC source should be used as input.
