Transphorm TDTTP4000W066C 0v2 Installation

Evaluation platform

+1 805 456 1300

transphormusa.com

TDTTP4000W066C_0v2

For evaluation purposes only

Design files and more at

transphormusa.com/en/evaluation-kit/

tdttp4000w066c-ki

Quick Start Guide

TDTTP4000W066C_0v2

Evaluation Platform

4kW Digital Bridgeless Totem-Pole PFC

qs010.3

2/2020

Table of Contents

Need help?

Do you have a question about the TDTTP4000W066C 0v2 and is the answer not in the manual?

Page 1 Quick Start Guide TDTTP4000W066C_0v2 Evaluation Platform +1 805 456 1300 transphormusa.com 4kW Digital Bridgeless Totem-Pole PFC TDTTP4000W066C_0v2 For evaluation purposes only Design files and more at transphormusa.com/en/evaluation-kit/ tdttp4000w066c-ki 2/2020 © 2020 Transphorm Inc. All rights reserved. qs010.3...
Page 2 Equipment Needed Typical Performance Curves g The TDTTP4000W066C_0v2 board g Microchip DSPIC33CK256MP506 (MA330048) 99.5 g High-voltage AC power supply for input g 12V auxiliary power adapter (included) g Electronic/Resistive load 98.5 • Power range: 0W to 4500W 97.5 1000 2000 3000 4000 5000 Output Power (W) Cautions and Warnings This evaluation board is intended to demonstrate GaN FET technology and is for demonstration purposes only and no guarantees are made for standards compliance.
Page 3 Probing Step 2: Power-up the Board There are two voltage probing sockets to measure V and V of the GaN FET shown g Insert the MicroChip Plug-In-Module (PIM) to the Conn1 slot. below. g Connect an electronic/resistive load to the corresponding marking (CN2). The requirements for the resistive load are: •...
Page 4 Step 1: Connect the Board Important Operating Guidelines The TDTTP4000W066C is for evaluation purposes only and is not intended to be a finished product and does not include all protection features found in commercial power supplies. Additional warnings to keep in mind: g An isolated AC source should be used as input.
