- Page 1 CASSETTATRITURATRICE MACERATOR PUMP KLEINHEBEANLAGE HOMAC 500-S1 HOMAC 500-S2 INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 2 In compliance with EN12050-3 Measures in millimeters...
- Page 3 It is strictly recommended to carefully read this warning and precautions guidelines, before any maintenance and service operation on the product. The HOMAC 500-S Series, consists of a water collection unit permanently fixed to the toilet, and / or to other utilities, containing the engine components.
- Page 4 EN 12056-4. Fix the water tank unit with two crew plugs (Ø 3,5 mm) or similar, using the fixing holes. HOMAC 500-S Series, can be connected to any type of toilet having a wall discharge in compliance with European standards.
- Page 5 Fig. 2.1 Fig. 2.2 Fig. 2.3 Fig. 2.4 Fig. 5.1 Fig. 5.2...
- Page 6 Fig. 5.3 Fig. 4 Fig. 3 Specifications Power supply 230 V ac Power 450 W Electrical absorption 2.0 A Frequency 50 Hz Protection class IP 44 Max pressure 0,7 bar (7m) 100 l/min Max capacity Intermittent Service <80°C Sewage water temperature 40 dB Sound power level...
