- Page 1 Optical Lens Adapter Installation Manual For TLD and CineVERSUM Cinema lenses R9832650 R5976641/01 29/03/2004...
- Page 2 Barco nv Events Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70 Fax: +32 56.36.88.24 E-mail: events@barco.com Visit us at the web: www.barco.com Printed in Belgium...
- Page 3 Changes Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war- ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.
-
Page 5: Table Of Contents
Table of contents TABLE OF CONTENTS 1. Optical Lens Adapter ....................3 Kit Contents . - Page 6 Table of contents R5976641 OPTICAL LENS ADAPTER 29/03/2004...
-
Page 7: Optical Lens Adapter
1. OPTICAL LENS ADAPTER 1.1 Kit Contents Contents of the Optical Lens Adapter Kit The Kit contains the following parts: • Optical Lens adapter R9832650 • Allen Hex key 0.9mm (W382114) • Installation manual R5976641 1.2 Use of the Optical Lens Adapter On which lens the optical adapter can be fitted. - Page 8 1. Optical Lens Adapter R5976641 OPTICAL LENS ADAPTER 29/03/2004...
-
Page 9: Mounting The Optical Lens Adapter
2. Mounting the Optical Lens Adapter 2. MOUNTING THE OPTICAL LENS ADAPTER Overview • TLD (0.8:1) Lens and TLD HB(0.8:1) Lens • TLD Zoom Lenses and CineVERSUM Cinema zoom Lenses 2.1 TLD (0.8:1) Lens and TLD HB(0.8:1) Lens Necessary tools Allen hex key 0.9mm (added to the kit) How to Mount The Optical Lens Adapter 1. -
Page 10: Tld Zoom Lenses And Cineversum Cinema Zoom Lenses
2. Mounting the Optical Lens Adapter Image 2-3 Lens adapter securing 2.2 TLD Zoom Lenses and CineVERSUM Cinema zoom Lenses Necessary tools Small flat (0.5 mm) screwdriver How to Mount The Optical Lens Adapter 1. Carefully unpack the optical lens adapter. Avoid touching the lens itself (fingerprints). 2. - Page 11 2. Mounting the Optical Lens Adapter Image 2-6 Lens adapter securing R5976641 OPTICAL LENS ADAPTER 29/03/2004...
- Page 12 2. Mounting the Optical Lens Adapter R5976641 OPTICAL LENS ADAPTER 29/03/2004...
-
Page 13: Lens Removal And Installation
3. Lens Removal and Installation 3. LENS REMOVAL AND INSTALLATION Overview • Lens Removal • Lens Installation 3.1 Lens Removal Necessary tools No tools. AUTION Risk of personal injury and lens damage. Pay attention to lens support while removing or installing the lens. - Page 14 3. Lens Removal and Installation Image 3-2 Lens installation AUTION For a table mounted projector, block the projector while inserting the lens unit to avoid the pro- jector from sliding off from the table. R5976641 OPTICAL LENS ADAPTER 29/03/2004...
-
Page 15: Lens Formulas
4. Lens Formulas 4. LENS FORMULAS 4.1 Projector Distance Calculation Diagram The following diagrams explains the position of the projector with respect to the screen and how to determine the projector distance Image 4-1 PD calculation Front/Ceiling configuration R5976641 OPTICAL LENS ADAPTER 29/03/2004... -
Page 16: Lens Formulas
4. Lens Formulas Image 4-2 PD calculation Front/Table configuration 4.2 Lens Formulas Lens Formulas for the different lenses with optical adapter Lens formulas in the decimal system (PD and SW in meters) TLD (0.8:1) PD=1.06 x SW + 0.09 TLD HB(0.8:1) PD=1.06 x SW + 0.09 TLD (1.6-2.0):1 TLD (1.6-2.0):1 Wide... - Page 17 4. Lens Formulas TLD (2.0-2.8):1 TLD (2.0-2.8):1 Wide PD=2.52 x SW - 0.13 TLD (2.0-2.8):1 Tele PD=3.58 x SW - 0.20 TLD HB(2.0-2.8):1 TLD (2.0-2.8):1 Wide PD=2.52 x SW - 0.13 TLD (2.0-2.8):1 Tele PD=3.58 x SW - 0.20 TLD (2.8-5.0):1 TLD (2.8-5.0):1 Wide PD=3.53 x SW - 0.12 TLD (2.8-5.0):1 Tele...
- Page 18 4. Lens Formulas TLD (0.8:1) PD=1.06 x SW + 3.54 TLD HB(0.8:1) PD=1.06 x SW + 3.54 TLD (1.6-2.0):1 TLD (1.6-2.0):1 Wide PD=2.01 x SW - 1.97 TLD (1.6-2.0):1 Tele PD=2.53 x SW - 3.54 TLD HB(1.6-2.0):1 TLD (1.6-2.0):1 Wide PD=2.01 x SW - 1.97 TLD (1.6-2.0):1 Tele PD=2.53 x SW - 3.54...
- Page 19 4. Lens Formulas CineVERSUM Cinema (2.0-2.8):1 CineVERSUM Cinema (2.0-2.8):1 Wide PD=2.03 x SW - 6.06 CineVERSUM Cinema (2.0-2.8):1 Tele PD=2.88 x SW - 8.82 CineVERSUM Cinema (2.8-5.0):1 CineVERSUM Cinema (2.8-5.0):1 Wide PD=2.84 x SW - 5.57 CineVERSUM Cinema (2.8-5.0):1 Tele PD=5.18 x SW - 14.33 CineVERSUM Cinema (5.0-8.0):1 CineVERSUM Cinema (5.0-8.0):1 Wide...
- Page 20 4. Lens Formulas R5976641 OPTICAL LENS ADAPTER 29/03/2004...
