Hyundai HSL121903 User Manual

Quality lighting from green energy
HSL121903
INTRODUCTION
You are now the proud owner of the Hyundai Solar Wall Lantern -
Rount Top - 3 pack! For best results study the manual
carefully before using the Hyundai Solar Wall Lantern - Rount Top - 3
pack. Please keep this manual handy for ready reference.
During the day, the solar panel converts solar power into energy
and stores it in the rechargeable battery. At night, the light turns on
automatically and uses energy stored in the battery. The duration of
the illumination will depend on your geographical location, weather
conditions and seasonal light availability.
PARTS LIST
A: Top Cover
B: Bulb
C: Housing
D: Wall mount
E: Screw set
BEFORE FIRST USE
Solar light has a solar panel that converts sunlight into electricity.
During the day, the electricity converted by the solar panel is stored
in the rechargeable battery. At night, the solar light is powered by
the battery using the electricity stored during the day. The operating
time depends on geographical location, daily weather conditions and
season.
CHOOSE THE RIGHT LOCATION
Select a location with full, direct sunlight. Do not install in shady areas
as these areas will not allow the battery to be fully charged and will
reduce nighttime working hours. Be sure that the selected location is
not close to other nighttime light sources such as street lights or porch
lights. These light sources may keep the solar lights from turning on
automatically.
ASSEMBLY AND INSTALLATION INSTRUCTIONS
Remove the pull tape between the top cover (A) and
housing (C). First screw the bulb into the top cover (A) and than insert
the housing (C) into the top cover (A) and twist to lock. Than use the
screwset (E) to fix the wall mount to the wall. Finally place the housing
(C) on the wall mount (E)
CHARGING THE BATTERY
KEEP THIS INSTRUCTION MANUAL FOR REFERENCE AS
IT CONTAINS IMPORTANT INFORMATION.
NL / EN - support@alleenonline.nl
BE / FR - support@alleenonline.be
Solar wall lantern - Round top
For optimum performance, it is best to install the solar lights in full
sunlight and charge for 10-12 hours. Allow the light to run at least
8-12 entire charging and discharging cycles to reach batteries
maximum capacity.
REPLACING BATTERY
For best performance, replace with rechargable 1.2V AA battery when
performance diminishes.
1. Twist and remove the housing (4) from top cover (1).
2. Remove the battery cover (3).Replace the old battery with a fresh
1.2V AA rechargeable battery.Replace the battery cover (3) and
housing (4).
TROUBLESHOOTING
Possible Cause
The nightly run time is 1. Battery is not fully charged.
shorter.
2. Battery is reaching the
end of its useful life.
Solar light does not turn Solar light is installed
on at night. close to other light sources
CAUTION
Battery must be recycled or disposed of properly battery must be far
away from fire.
TECHNICAL SPECIFICATIONS:
Color: Black
Dimensions: 13.9cm(L)*13.9cm(W)*20.5cm(H)
Product weight: 0.23KGS
Material: Plastic
Solar panel: Solar Panel 69x69mm
Battery: 1.2V 900MAH AA 1PC rechargeable battery
Voltage: 2V, 0.3W
Current: 70mA
Lumen: 10 Lumens
Color temperature: 3000 K
LED: 1 single LED light bulb
Water resistance: IP23
Charging time: 6-8 hours of sunlight averagely
Operating time: 8 hours on a full battery
Switch: Pull tag
© 2020 The Investment Company Europe B.V.
Hyundai is a trademark of Hyundai Corporation, Korea. Licensed to
The Investment Company Europe B.V. All rights reserved.
Licensed by Hyundai Corporation, Korea. Imported/Distributed by The
Investment Company Europe B.V. exclusively developed for sales in
the Netherlands, Belgium, Luxembourg and France.
The artwork and design of this package are protected by European
copyright law and may not be reproduced, distributed, displayed,
published or used for any purpose without prior written permission.
It is not permitted to alter, or reproduce any trademarks or copyright
User Manual
Corrective Action
1. Locate the solar light in an
area where it can receive the
maximum amount of full,
direct sunlight everyday.
2. Replace the old battery
with a fresh one.
1. Relocate the solar light
2.eliminate other light sources.
PATENT PENDING
notice from this package.
