R e f e r e n c e Ma n u a l
F 3 4 L C I
T e c h n i c a l T r a i n i n g
T h e i n f o r ma t i o n c o n t a i n e d i n t h i s ma n u a l i s n o t t o b e r e s o l d , b a r t e r e d , c o p i e d o r t r a n s f e r r e d
w i t h o u t t h e e x p r e s s w r i t t e n c o n s e n t o f B MW o f N o r t h A me r i c a , L L C ( " B MW N A " ) .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F34 LCI 2016 and is the answer not in the manual?

Questions and answers

Related Manuals for BMW F34 LCI 2016

Summary of Contents for BMW F34 LCI 2016

  • Page 1 R e f e r e n c e Ma n u a l F 3 4 L C I T e c h n i c a l T r a i n i n g T h e i n f o r ma t i o n c o n t a i n e d i n t h i s ma n u a l i s n o t t o b e r e s o l d , b a r t e r e d , c o p i e d o r t r a n s f e r r e d w i t h o u t t h e e x p r e s s w r i t t e n c o n s e n t o f B MW o f N o r t h A me r i c a , L L C ( "...
  • Page 2 Technical￿Training Product￿information. F34￿LCI BMW￿Service...
  • Page 3 General￿information Symbols￿used The￿following￿symbol￿is￿used￿in￿this￿document￿to￿facilitate￿better￿comprehension￿or￿to￿draw￿attention to￿very￿important￿information: Contains￿important￿safety￿information￿and￿information￿that￿needs￿to￿be￿observed￿strictly￿in￿order￿to guarantee￿the￿smooth￿operation￿of￿the￿system. Information￿status￿and￿national-market￿versions BMW￿Group￿vehicles￿meet￿the￿requirements￿of￿the￿highest￿safety￿and￿quality￿standards.￿Changes in￿requirements￿for￿environmental￿protection,￿customer￿benefits￿and￿design￿render￿necessary continuous￿development￿of￿systems￿and￿components.￿Consequently,￿there￿may￿be￿discrepancies between￿the￿contents￿of￿this￿document￿and￿the￿vehicles￿available￿in￿the￿training￿course. This￿document￿basically￿relates￿to￿the￿European￿version￿of￿left￿hand￿drive￿vehicles.￿Some￿operating elements￿or￿components￿are￿arranged￿differently￿in￿right-hand￿drive￿vehicles￿than￿shown￿in￿the graphics￿in￿this￿document.￿Further￿differences￿may￿arise￿as￿the￿result￿of￿the￿equipment￿specification￿in specific￿markets￿or￿countries. Additional￿sources￿of￿information Further￿information￿on￿the￿individual￿topics￿can￿be￿found￿in￿the￿following: • Owner's￿Handbook • Integrated￿Service￿Technical￿Application. Contact:￿conceptinfo@bmw.de ©2016￿BMW￿AG,￿Munich Reprints￿of￿this￿publication￿or￿its￿parts￿require￿the￿written￿approval￿of￿BMW￿AG,￿Munich. The￿information￿contained￿in￿this￿document￿forms￿an￿integral￿part￿of￿the￿BMW￿Group￿Technical Qualification￿and￿is￿intended￿for￿the￿trainer￿and￿participants￿in￿the￿seminar.￿Refer￿to￿the￿latest￿relevant information￿systems￿of￿the￿BMW￿Group￿for￿any￿changes/additions￿to￿the￿technical￿data. Information￿status:￿March￿2016 Technical￿Training...

  • Page 4: Table Of Contents

    F34￿LCI Content Introduction ................................................1.1. New￿features ..........................................1.1.1. TPMS ........................................1.1.2. Air￿conditioning ..................................1.1.3. Air￿conditioning￿control￿panel .......................... 1.2. Identifying￿features ......................................1.2.1. Front .......................................... 1.2.2. Rear ..........................................1.2.3. Passenger￿compartment ............................Drivetrain ..................................................2.1. Engine￿overview ........................................2.1.1. Engine ........................................2.1.2. Further￿information ................................2.2. Overview￿of￿the￿transmission ................................
  • Page 5 F34￿LCI Content 5.4. USB￿port ............................................5.4.1. Connection ....................................5.5. Telephone ............................................5.5.1. Variants ......................................5.5.2. Telephone￿with￿wireless￿charging ......................5.6. Further￿information ......................................

  • Page 6: Introduction

    F34￿LCI 1.￿Introduction In￿July￿2016￿the￿model￿revision￿or￿the￿Life￿Cycle￿Impulse￿(LCI)￿of￿the￿BMW￿3￿Series￿GT￿enters￿the market.￿The￿model￿revision￿of￿the￿BMW￿3￿Series￿GT￿also￿underscores￿the￿BMW-specific￿proportions, such￿as￿the￿short￿overhang￿in￿front,￿the￿long￿wheelbase￿and￿the￿BMW￿kidney￿grill. Infotainment￿in￿the￿F34￿LCI￿also￿contains￿some￿new￿features.￿For￿example,￿the￿F34￿LCI￿is￿the￿first vehicle￿at￿BMW￿to￿offer￿Apple®￿CarPlay. F34￿LCI￿complete￿vehicle This￿document￿refers￿to￿the￿BMW 3￿Series GT￿model￿revision￿as￿the￿"F34 LCI". The￿most￿important￿changes￿in￿the￿F34￿LCI￿include: • Modified￿bumpers • Upgraded￿vehicle￿interior￿with￿chrome￿applications • LED￿headlights • Newly￿designed￿rear￿lights • Expanded￿assistance￿systems • New￿infotainment￿applications In￿addition￿to￿the￿comprehensive￿offering￿of￿optional￿equipment,￿the￿F34￿LCI￿can￿also￿be￿individualized with￿the￿following￿equipment￿packages: • Luxury￿Line • M￿Sport￿Package...

  • Page 7: Tpms

    F34￿LCI 1.￿Introduction 1.1.￿New￿features 1.1.1.￿TPMS The￿F34￿LCI￿receives￿the￿tire￿pressure￿control￿system￿TPMS￿as￿standard￿equipment. When￿servicing,￿the￿different￿types￿of￿wheel￿electronics￿must￿be￿kept￿in￿mind.￿The￿wheel￿electronics of￿the￿two￿different￿systems￿must￿not￿be￿confused￿with￿one￿another. Further￿information￿on￿the￿TPMS￿system￿can￿be￿found￿in￿the￿Technical￿Training￿manual￿"ST1403a￿I01 Complete￿Vehicle”￿Chassis￿&￿Suspension￿section. F34￿LCI￿aluminium￿screw￿valves￿RDCi 1.1.2.￿Air￿conditioning The￿F34￿LCI￿uses￿the￿new￿refrigerant￿R1234yf. The￿design￿of￿the￿filling￿valves￿of￿a￿R1234yf￿heating￿and￿air￿conditioning￿system,￿which￿are￿installed in￿the￿refrigerant￿circuit,￿are￿different￿from￿those￿of￿a￿R134a￿heating￿and￿air￿conditioning￿system.￿The R1234yf￿A/C￿service￿station￿has￿different￿service￿connections￿than￿the￿R134a￿service￿station. R1234yf￿refrigerant￿is￿identified￿with￿grey￿screw￿caps￿on￿the￿filling￿valves￿along￿with￿the￿identification of￿the￿fill￿label￿under￿the￿hood￿specifying￿the￿R1234yf￿refrigerant.
  • Page 8 F34￿LCI 1.￿Introduction F34￿LCI￿air￿conditioning￿screw￿caps A￿mixture￿of￿the￿two￿gases￿(R134a￿and￿R1234yf)￿must￿always￿be￿avoided￿and￿is￿not￿permitted￿by￿law. If￿a￿mixture￿of￿R134a￿and￿R1234yf￿occurs,￿the￿refrigerant￿mixture￿must￿be￿removed￿from￿the￿heating and￿air-conditioning￿system￿and￿A/C￿service￿station￿and￿disposed￿of￿properly. 1.1.3.￿Air￿conditioning￿control￿panel The￿liquid￿crystal￿display￿of￿the￿air￿conditioning￿control￿panel￿integrated￿automatic￿heating/air conditioning￿system￿comes￿with￿automatic￿day/night￿changeover.￿The￿liquid￿crystal￿display￿is￿white, during￿daytime￿driving￿and￿turns￿orange￿at￿night￿time￿once￿the￿headlights￿are￿illuminated. F34￿LCI￿air￿conditioning￿control￿panel...

  • Page 9: Front

    F34￿LCI 1.￿Introduction 1.2.￿Identifying￿features 1.2.1.￿Front The￿following￿changes￿have￿been￿implemented￿in￿the￿F34￿LCI: • New￿front￿bumper￿design • Headlights￿with￿LED￿technology F34￿LCI￿front￿view Index Explanation LED￿headlights￿are￿standard Modified￿bumper LED￿fog￿lights￿are￿standard...

  • Page 10: Rear

    F34￿LCI 1.￿Introduction 1.2.2.￿Rear The￿following￿changes￿have￿been￿implemented￿in￿the￿F34￿LCI: • New￿rear￿bumper￿design • New￿rear￿light￿design • Exhaust￿tailpipes￿with￿larger￿diameter F34￿LCI￿rear Index Explanation LED￿rear￿light Modified￿bumper Exhaust￿tailpipe...
  • Page 11 F34￿LCI 1.￿Introduction Rear￿spoiler The￿rear￿spoiler￿design￿is￿identical￿to￿the￿F34.￿Further￿information￿on￿the￿active￿rear￿spoiler￿can￿be found￿in￿ST1304￿"F34￿Complete￿Vehicle"￿Training￿material. F34￿LCI￿active￿rear￿spoiler 1.2.3.￿Passenger￿compartment The￿selective￿use￿of￿chrome￿elements￿are￿used￿to￿upgrade￿the￿look￿of￿the￿vehicle￿interior.￿The￿storage compartment￿cover￿in￿the￿center￿console￿no￿longer￿folds￿out,￿but￿is￿a￿sliding￿cover.￿In￿combination￿with the￿standard￿ambient￿light￿package,￿indirect￿lighting￿at￿selected￿places￿creates￿an￿impression￿of￿high quality. F34￿LCI￿vehicle￿interior...

  • Page 12: Drivetrain

    F34￿LCI 2.￿Drivetrain 2.1.￿Engine￿overview 2.1.1.￿Engine F34￿LCI￿engines￿are￿exclusively￿engines￿from￿the￿modular￿engine￿strategy￿(Bxx).￿In￿adopting￿the￿new engine￿generation,￿certain￿model￿designations￿have￿also￿been￿changed: • The￿BMW￿328i￿GT￿becomes￿the￿BMW￿330i￿GT • The￿BMW￿335i￿GT￿becomes￿the￿BMW￿340i￿GT The￿following￿table￿shows￿the￿gasoline￿engine￿models￿available￿in￿the￿F34￿LCI￿together￿with￿their most￿important￿data: Model Engine Power Torque BMW￿330i￿GT￿xDrive B46B20O0 185￿kW￿(252￿hp) 350￿Nm￿(258￿lb-ft) BMW￿340i￿GT￿xDrive B58B30M0 240￿kW￿(326￿hp) 450￿Nm￿(332￿lb-ft) 2.1.2.￿Further￿information The￿following￿technical￿training￿reference￿manuals￿feature￿further￿information￿about￿each of￿the￿engines: • ST1512￿B46￿Engine • ST1505￿B58￿Engine 2.2.￿Overview￿of￿the￿transmission The￿F34￿LCI￿comes￿with￿a￿8-speed￿sport￿automatic￿transmission. Model Sport￿Automatic￿Transmission BMW￿330i￿GT￿xDrive Standard￿equipment BMW￿340i￿GT￿xDrive Standard￿equipment 2.3.￿xDrive￿overview BMW￿xDrive￿is￿standard￿on￿all￿F34￿LCI￿models:...
  • Page 13 F34￿LCI 3.￿General￿Vehicle￿Electrical￿System 3.1.￿Bus￿overview F34￿LCI￿bus￿overview...
  • Page 14 F34￿LCI 3.￿General￿Vehicle￿Electrical￿System Index Explanation Start-up￿nodes;￿control￿units￿for￿starting￿and￿synchronizing the￿FlexRay￿bus￿system Control￿units￿with￿wake-up￿authorisation ACSM Crash￿Safety￿Module AMPT Amplifier￿Top Active￿Sound￿Design Controller Digital￿Motor￿Electronics Dynamic￿Stability￿Control Electronic￿transmission￿control EKPS Electronic￿fuel￿pump￿control Electronic￿Power￿Steering Front￿Electronic￿Module High-beam￿assistant FLEL Frontal￿Light￿Electronics￿Left FLER Frontal￿Light￿Electronics￿Right Roof￿function￿center Gear￿selector HEADUNIT Head￿unit Automatic￿operation￿of￿tailgate Integrated￿Chassis￿Management IHKA Integrated￿automatic￿heating￿/￿air￿conditioning KAFAS Camera-based￿driver￿support￿systems KOMBI Instrument￿panel Diagnostic￿socket Parking￿Manoeuvring￿Assistant Rear￿Electronic￿Module REMAFA Reversible￿electric-driven￿reel,￿left REMABF...

  • Page 15: Lighting

    F34￿LCI 3.￿General￿Vehicle￿Electrical￿System Index Explanation Vertical￿Dynamics￿Management Transfer￿box Central￿gateway￿Module New￿control￿units￿in￿the￿F34￿LCI FLEL Frontal￿Light￿Electronics￿Left FLER Frontal￿Light￿Electronics￿Right TCB2 Telematic￿Communication￿Box￿2 3.2.￿Lighting The￿F34￿LCI￿comes￿with￿LED￿headlights￿as￿standard￿equipment.￿Halogen￿headlights￿or￿xenon headlights￿are￿no￿longer￿offered￿for￿the￿F34￿LCI.￿LED￿fog￿lights￿are￿also￿standard.￿The￿rear￿lights￿have a￿new￿light￿design￿including￿LED￿technology. 3.2.1.￿Headlight Adaptive￿Full￿LED￿headlights￿(OE￿552)￿may￿be￿ordered￿as￿optional￿equipment.
  • Page 16 F34￿LCI 3.￿General￿Vehicle￿Electrical￿System Adaptive￿LED￿headlight￿system￿wiring￿diagram F34￿LCI￿adaptive￿LED￿headlight￿system￿wiring￿diagram...
  • Page 17 F34￿LCI 3.￿General￿Vehicle￿Electrical￿System Index Explanation Frontal￿Light￿Electronics￿Left￿(FLEL) LED￿fog￿light,￿left LED￿fog￿light,￿right Frontal￿Light￿Electronics￿Right￿(FLER) Front￿passenger￿power￿distribution￿box￿fuse Front￿Electronic￿Module￿(FEM) FEM￿fuse Luggage￿compartment￿power￿distribution￿box￿fuse Ride-height￿sensor,￿rear￿left Integrated￿Chassis￿Management￿(ICM) Central￿locking￿button/hazard￿warning￿switch Steering￿column￿switch￿cluster￿(SZL) Light￿operating￿unit Rain-light-solar-condensation￿sensor￿(RLSBS) Ride￿height￿sensor,￿front￿left Dynamic￿Stability￿Control￿(DSC) 3.2.2.￿Rear￿lights All￿rear￿lighting￿functions￿are￿done￿by￿LEDs￿with￿the￿exception￿of￿the￿reversing￿light￿which￿is￿a conventional￿bulb.￿The￿turn￿indicator￿extends￿across￿the￿entire￿widths￿of￿the￿rear￿lights￿for￿better visibility. F34￿LCI￿rear￿light...
  • Page 18 F34￿LCI 3.￿General￿Vehicle￿Electrical￿System System￿wiring￿diagram F34￿LCI￿rear￿light￿system￿wiring￿diagram...
  • Page 19 F34￿LCI 3.￿General￿Vehicle￿Electrical￿System Index Explanation Dynamic￿Stability￿Control￿(DSC) Electronic￿transmission￿control￿(EGS) Reversing￿light￿switch￿(manual￿gearbox)￿(not￿for￿US) Front￿Electronic￿Module￿(FEM) Fuse￿in￿the￿FEM￿power￿distribution￿box Trailer￿module￿AHM￿(not￿for￿US) Luggage￿compartment￿power￿distribution￿box￿fuse Rear￿Electronic￿Module￿(REM) Battery￿power￿distribution￿box￿fuses Rear￿light,￿outside￿right Rear￿light,￿outside￿left Rear￿light,￿inside￿left License-plate￿light,￿left License-plate￿light,￿right Rear￿light,￿inside￿right Interference￿suppression￿filter Interference￿suppression￿filter Interference￿suppression￿filter Additional￿brake￿light Integrated￿Chassis￿Management￿(ICM) Light￿operating￿unit Brake￿light￿switch Central￿locking￿button/hazard￿warning￿switch Steering￿column￿switch￿cluster￿(SZL) Rain-light-solar-condensation￿sensor￿(RLSBS) 3.3.￿Contactless￿tailgate￿opening In￿combination￿with￿the￿Comfort￿Access￿(OE￿322)￿optional￿equipment,￿the￿F34￿LCI￿has￿contactless tailgate￿opening.￿This￿includes￿not￿only￿opening￿but￿also￿closing￿of￿the￿tailgate￿by￿a￿specific￿foot motion￿under￿the￿rear￿bumper.
  • Page 20 F34￿LCI 3.￿General￿Vehicle￿Electrical￿System F34￿LCI￿system￿wiring￿diagram￿for￿contactless￿tailgate￿opening...

  • Page 21: Overview

    F34￿LCI 3.￿General￿Vehicle￿Electrical￿System Index Explanation Front￿Electronic￿Module￿(FEM) Luggage￿compartment￿power￿distribution￿box￿fuse Rear￿Electronic￿Module￿(REM) Automatic￿operation￿of￿tailgate￿(HKL) Control￿electronics￿for￿non-contact￿tailgate￿opening Sensor￿at￿top￿for￿non-contact￿tailgate￿opening Sensor￿at￿bottom￿for￿non-contact￿tailgate￿opening Exterior￿Antenna,￿rear￿bumper Acoustic￿warning￿device Tailgate￿lock￿switch Contactless￿tailgate￿opening￿operates￿unchanged￿compared￿with￿the￿F34.￿New￿in￿the￿F34￿LCI compared￿with￿F34￿is￿contactless￿tailgate￿closing.￿The￿same￿foot￿motion￿as￿for￿opening￿also￿closes the￿tailgate.￿When￿closing￿the￿tailgate￿by￿the￿contactless￿tailgate￿activation,￿a￿beeping￿sound￿is emitted￿by￿an￿acoustic￿warning￿device,￿which￿is￿installed￿in￿the￿tailgate. 3.4.￿Assistance￿systems 3.4.1.￿Overview The￿following￿optional￿assistance￿systems￿are￿available￿for￿the￿F34￿LCI: • Active￿Driving￿Assistant￿(OE￿5AS) • Parking￿Assistant￿(OE￿5DP) • Park￿Distance￿Control￿(OE￿508) • Rear￿view￿camera￿(OE￿3AG) • Side￿and￿top￿view￿cameras￿(OE￿5DL) • Automatic￿high-beams￿(OE￿5AC) • Active￿cruse￿control￿Stop&Go￿(OE￿5DF) • Active￿blind￿spot￿detection￿(OE￿5AG) • Speed￿limit￿info￿(OE￿8TH) The￿optional￿"Driving￿Assistant"￿(OE￿5AS)￿contains￿the￿following￿systems: •...
  • Page 22 F34￿LCI 3.￿General￿Vehicle￿Electrical￿System If￿the￿vehicle￿comes￿with￿the￿combined￿optional￿equipment￿"Driving￿Assistant"￿(OE￿5AS)￿and "ACC Stop & Go"￿(OE 5DF),￿the￿collision￿warning￿with￿City￿brake￿activation￿is￿expanded￿to￿collision warning￿with￿brake￿activation.￿That￿is,￿initial￿braking￿occurs￿over￿the￿entire￿speed￿range. 3.4.2.￿New￿features￿in￿the￿F34￿LCI￿compared￿with￿the￿F34 Lane￿change￿warning Thanks￿to￿new￿radar￿sensors,￿vehicles￿can￿now￿be￿detected￿at￿speeds￿of￿20￿km/h￿/￿12￿mph￿and￿above. Side￿protection In￿combination￿with￿the￿optional￿Parking￿Assistant,￿(OE￿5DP),￿the￿rear￿bumper￿comes￿with￿2￿additional PDC￿ultrasonic￿sensors￿on￿each￿side. F34￿LCI￿ultrasonic￿sensors￿for￿side￿protection Besides￿the￿front￿and￿rear￿sides￿of￿the￿vehicle,￿the￿side￿area￿of￿the￿vehicle￿is￿now￿also￿monitored. The￿side￿protection￿is￿active￿at￿the￿same￿time￿as￿the￿Park￿Distance￿Control. The￿measuring￿range￿around￿the￿B-pillar￿and￿parts￿of￿the￿doors￿is￿not￿monitored￿by￿the￿ultrasonic sensors.￿Instead￿this￿area￿is￿imaged￿using￿a￿computer￿model￿while￿the￿vehicle￿drives￿past. Side￿protection￿is￿not￿active￿during￿an￿automatic￿parking￿manoeuvre￿by￿the￿Parking￿Assistant￿(PMA).
  • Page 23 F34￿LCI 3.￿General￿Vehicle￿Electrical￿System Side￿protection￿indication￿in￿the￿central￿information￿display￿(CID) Parking￿assistant The￿Parking￿Assistant￿(PMA)￿of￿the￿F34￿LCI￿now￿also￿allows￿parking￿in￿spaces￿transverse￿to￿the roadway.￿You￿can￿find￿more￿information￿on￿this￿in￿the￿Technical￿Reference￿Manual￿for￿the￿"ST1502 F23￿Complete￿Vehicle".

  • Page 24: Overview

    F34￿LCI 4.￿Displays￿and￿Controls Numerous￿changes￿have￿occurred￿to￿the￿display￿and￿operating￿elements￿because￿of￿a￿new￿generation of￿head￿unit.￿The￿user￿interface￿in￿the￿F34￿LCI￿has￿a￿new￿design.￿A￿new￿controller￿is￿also￿installed. 4.1.￿Overview The￿following￿table￿features￿an￿overview￿of￿the￿CIDs￿and￿controllers￿(CON)￿used￿in￿the￿F34￿LCI: Equipment Central￿information Controller￿CON display￿CID Professional￿radio 6.5"￿(800￿x￿480￿pixels) 5-button (standard￿equipment) Navigation￿system 8.8"￿(1280￿x￿480￿pixels) 7-button￿with￿touch (OE 609) control￿box￿(new) 4.2.￿Central￿information￿display In￿conjunction￿with￿the￿navigation￿system￿(OE￿609),￿the￿user￿interface￿of￿the￿F34￿LCI￿has￿a￿new design.￿The￿individual￿menus￿are￿no￿longer￿arranged￿in￿a￿list￿but￿appear￿as￿graphic￿tiles. F34￿LCI￿main￿menu...

  • Page 25: Controller

    F34￿LCI 4.￿Displays￿and￿Controls 4.3.￿Controller In￿conjunction￿with￿the￿navigation￿system￿(OE￿609),￿a￿new￿controller￿(touch￿control￿box)￿with￿modified direct￿access￿keys￿is￿used.￿Operation￿itself￿(turning,￿pressing,￿sliding)￿remains￿unchanged.￿The following￿graphic￿shows￿the￿differences￿between￿a￿controller￿from￿an￿F34￿and￿one￿from￿an￿F34 LCI: Controller￿comparison Index Explanation Controller￿with￿touch￿control￿panel￿F34 Controller￿with￿touch￿control￿panel￿in￿F34￿LCI The￿following￿table￿shows￿the￿changes￿in￿the￿direct￿access￿keys: Controller￿F34 Controller￿in￿F34￿LCI RADIO￿and￿MEDIA MEDIA TEL￿(telephone) COM￿(communication) NAV￿(navigation) NAV￿and￿MAP￿(navigation￿and￿navigation￿map) The￿Touchbox￿(TBX)￿control￿unit￿is￿installed￿near￿the￿A-pillar￿on￿the￿right￿side￿above￿the￿front electronic￿module￿(FEM).

  • Page 26: Apps

    Special￿features Professional￿radio￿(standard • Controller￿with￿5￿buttons equipment) • CID￿with￿6.5" Headunit￿Basis￿(HU-B) • CD￿player Navigation￿system￿(OE 609) • Navigation￿(3￿years'￿map￿updating￿with￿no￿licence Head￿Unit￿High￿2￿(HU-H2) charges) • Automatic￿map￿updating￿(up￿to￿4￿times￿a￿year) • Voice￿input • Controller￿with￿7￿buttons￿and￿touch￿control￿box • CID￿with￿8.8" • 20￿GB￿memory￿for￿audio￿files • DVD￿drive • Hands-free￿system￿with￿USB￿interface • Extended￿and￿enhanced￿instrument￿cluster • ConnectedShift • Proactive￿driving￿assistant￿(in￿ECO￿PRO￿mode) 5.1.1.￿Apps BMW￿Apps Selected￿apps￿from￿third-party￿providers￿(e.g.￿Spotify®,￿Audible®￿etc.)￿can￿be￿transmitted￿to￿vehicles with￿an￿HU-H2￿by￿means￿of￿Bluetooth.￿A￿prerequisite￿is￿the￿optional￿BMW￿Online￿and￿BMW￿Apps￿(OE 6AK).

  • Page 27: Functions

    F34￿LCI 5.￿Information￿and￿Communication 5.2.￿Apple®￿CarPlay The￿F34￿LCI￿is￿the￿first￿vehicle￿at￿BMW￿to￿offer￿Apple®￿CarPlay.￿Optional￿Apple®￿CarPlay￿preparation (OE￿6CP)￿is￿available￿only￿in￿combination￿with￿the￿optional￿Professional￿navigation￿system￿(OE￿609) and￿ConnectedDrive￿Services￿(OE 6AK)￿(Apple®￿CarPlay￿is￿already￿included￿with￿ConnectedDrive Services).￿Countries￿without￿ConnectedDrive￿Services￿must￿instead￿order￿Apps￿(OE￿6NR)￿as￿optional equipment. Apple®￿CarPlay 5.2.1.￿Functions Apple®￿CarPlay￿allows￿wireless,￿convenient￿use￿of￿an￿iPhone®￿in￿the￿vehicle.￿iPhone®￿content￿like music,￿messages,￿telephone,￿navigation￿and￿selected￿apps￿appear￿on￿the￿Central￿Information￿Display (CID)￿and￿are￿operated￿via￿the￿controller.

  • Page 28: Connection

    F34￿LCI 5.￿Information￿and￿Communication Apple®￿CarPlay￿functions 5.2.2.￿Connection The￿iPhone®￿is￿connected￿to￿the￿vehicle￿via￿Bluetooth.￿After￿successful￿pairing,￿"Apple®￿CarPlay"￿is activated￿in￿the￿vehicle. Apple®￿CarPlay￿selection￿in￿main￿menu The￿design￿and￿operation￿of￿Apple®￿CarPlay￿are￿adjusted￿to￿the￿iPhone®. An￿iPhone®￿connected￿to￿Apple®￿CarPlay￿is￿subject￿to￿the￿following￿restrictions: • Phoning￿is￿possible￿only￿through￿Apple®￿CarPlay. • The￿iPhone®￿cannot￿be￿registered￿as￿a￿second￿phone. • The￿phone￿book￿entries￿are￿not￿transmitted￿to￿the￿vehicle.￿ • Only￿one￿additional￿phone￿can￿be￿connected￿to￿the￿vehicle. ￿The￿phone￿book￿of￿the￿iPhone®￿can￿be￿accessed￿via￿Apple®￿CarPlay.

  • Page 29: Telematics

    F34￿LCI 5.￿Information￿and￿Communication 5.3.￿Telematics The￿F34￿LCI￿comes￿with￿2￿different￿telematics￿control￿units,￿depending￿on￿the￿equipment￿level: • Telematic￿Communication￿Box￿(TCB) • Telematic￿Communication￿Box￿2￿(TCB2) 5.3.1.￿Telematic￿Communication￿Box In￿combination￿with￿a￿Professional￿radio￿(standard￿equipment)￿the￿Telematic￿Communication￿Box (TCB)￿telematics￿control￿unit￿familiar￿from￿other￿vehicles￿is￿installed. 5.3.2.￿Telematic￿Communication￿Box￿2 The￿Telematic￿Communication￿Box￿2￿is￿installed￿in￿combination￿with￿the￿optional￿Navigation￿system (OE￿609). The￿special￿features￿of￿the￿TCB2￿are: • The￿GPS￿antenna￿is￿connected￿to￿the￿TCB2.￿The￿navigation￿data￿are￿sent￿to￿the￿Head￿Unit High￿2￿via￿an￿OABR￿Ethernet￿connection. • The￿TCB2￿uses￿LTE￿for￿data￿transfer. • A￿WLAN￿antenna￿for￿the￿WLAN￿hotspot￿is￿integrated￿in￿the￿TCB2.
  • Page 30 F34￿LCI 5.￿Information￿and￿Communication F34￿LCI￿EBO￿for￿TCB2 WiFi￿Hotspot WLAN The￿optional￿WLAN￿hotspot￿(OE￿6WD)￿is￿part￿of￿the￿optional￿Wireless￿Charging￿option￿code￿(OE 6WN),￿this￿allows￿the￿connection￿of￿mobile￿devices￿to￿the￿internet￿via￿the￿SIM￿card￿(P-SIM)￿integrated in￿the￿vehicle. Up￿to￿10￿devices￿can￿be￿connected￿to￿the￿hotspot￿by￿WLAN.￿The￿maximum￿download￿rate￿is￿100 Mbit/s.
  • Page 31 F34￿LCI 5.￿Information￿and￿Communication F34￿LCI￿WLAN￿hotspot￿reception Index Explanation LTE￿transmitter LTE￿antenna￿1 LTE￿antenna￿2 Emergency￿GSM￿antenna Roof￿antenna Telematic￿Communication￿Box￿2￿(TCB2) WLAN Passenger￿compartment The￿corresponding￿WLAN￿Antenna￿is￿installed￿in￿the￿TCB2. F34￿LCI￿WLAN￿Antenna...

  • Page 32: Connection

    F34￿LCI 5.￿Information￿and￿Communication Index Explanation WLAN￿antenna￿for￿WLAN￿hotspot Use￿of￿the￿WLAN￿hotspot￿is￿subject￿to￿a￿charge￿for￿the￿customer.￿After￿a￿test￿phase,￿the￿customer must￿independently￿renew￿the￿data￿plan￿with￿the￿provider.￿To￿this￿end,￿after￿the￿connection￿is established,￿a￿screen￿from￿the￿provider￿appears￿in￿which￿the￿customer￿can￿renew￿the￿agreement￿on his￿own. 5.4.￿USB￿port The￿USB￿port￿in￿the￿center￿console￿is￿standard￿equipment￿in￿the￿F34￿LCI.￿In￿combination￿with￿the optional￿telephone￿with￿Wireless￿Charging￿(OE 6NW),￿a￿second￿USB￿port￿is￿located￿below￿the￿AC control￿panel. Second￿USB￿port￿in￿F34￿LCI 5.4.1.￿Connection If￿only￿the￿USB￿port￿in￿the￿center￿console￿is￿present,￿it￿is￿directly￿connected￿to￿the￿head￿unit￿as￿before. The￿optional￿telephone￿with￿Wireless￿Charging￿(OE￿6NW)￿comes￿with￿a￿USB￿hub.￿In￿combination￿with the￿USB￿hub,￿both￿USB￿ports￿take￿a￿charge￿current￿of￿2￿amps￿(usually￿a￿USB￿port￿in￿the￿vehicle￿has￿a charge￿current￿of￿500￿mA).
  • Page 33 F34￿LCI 5.￿Information￿and￿Communication F34￿LCI￿USB￿interface￿connection...

  • Page 34: Telephone

    F34￿LCI 5.￿Information￿and￿Communication Index Explanation Head￿unit Bluetooth￿Antenna USB￿hub Center￿stack￿USB￿port USB￿audio￿interface AUX-IN￿port Luggage￿compartment￿power￿distribution￿box￿fuse 5.5.￿Telephone The￿F34￿LCI￿is￿the￿first￿in￿the￿BMW￿3￿Series￿to￿offer￿optional￿telephone￿equipment￿in￿which￿the￿mobile phone￿battery￿is￿charged￿inductively. 5.5.1.￿Variants The￿following￿hands-free￿system￿versions￿are￿available￿for￿the￿F34￿LCI: • Hands-free￿Bluetooth￿and￿USB￿audio￿connection￿(Standard￿equipment) • Wireless￿Charging￿(OE￿6NW) 5.5.2.￿Telephone￿with￿wireless￿charging For￿the￿F34￿LCI,￿telephone￿with￿wireless￿charging￿is￿available￿as￿optional￿equipment￿(OE 6NW). Charging￿of￿the￿mobile￿phone￿battery￿and￿transmission￿of￿the￿antenna￿signals￿occur￿wirelessly￿via￿the wireless￿charging￿technology.￿This￿function￿is￿possible￿only￿for￿mobile￿phones￿that￿are￿compliant￿with the￿Qi®￿standard.￿The￿standard￿is￿identifiable￿by￿the￿icon.￿This￿standard￿ensures￿that￿the￿chargers￿are compatible￿with￿the￿devices. For￿information￿on￿compatibility,￿go￿to:￿www.bmw.com/bluetooth...
  • Page 35 F34￿LCI 5.￿Information￿and￿Communication Qi￿identification The￿F34￿LCI￿implements￿wireless￿charging￿via￿a￿special￿wireless￿charging￿tray. F34￿LCI￿wireless￿charging...
  • Page 36 F34￿LCI 5.￿Information￿and￿Communication F34￿LCI￿base￿plate￿for￿wireless￿charging Operation Wireless￿charging￿is￿based￿on￿induction.￿A￿transmitter￿coil￿and￿a￿receiver￿coil￿contactlessly￿transmit the￿charging￿voltage￿for￿the￿mobile￿phone. Basic￿principle￿of￿wireless￿charging...
  • Page 37 F34￿LCI 5.￿Information￿and￿Communication Index Explanation Mobile￿phone￿with￿coupling￿antenna￿for￿mobile￿reception Induction￿coil￿of￿mobile￿phone Outer￿cover￿of￿the￿mobile￿phone￿with￿receiver￿coil Charging/transmitting￿coil￿in￿the￿wireless￿charging￿tray Telephone￿antenna￿in￿the￿wireless￿charging￿tray￿(inductive) Ferrite￿in￿the￿wireless￿charging￿tray Electronics￿with￿connections￿for￿the￿vehicle￿electrical￿system of￿the￿wireless￿charging￿tray Outer￿cover￿of￿the￿wireless￿charging￿tray Connection￿to￿the￿vehicle￿electrical￿system The￿following￿diagram￿is￿a￿simplified￿depiction￿of￿how￿wireless￿charging￿telephone￿is￿integrated￿in￿the vehicle￿electrical￿system. F34￿LCI￿wireless￿charging￿connection...
  • Page 38 F34￿LCI 5.￿Information￿and￿Communication Index Explanation Antenna￿lines Voltage￿supply Activation￿line Roof￿antenna Line￿compensator Wireless￿charging￿tray Battery Line￿compensator A￿LTE-capable￿line￿compensator￿compensates￿for￿the￿loss￿in￿wireless￿transmission.￿With￿this￿line compensator,￿the￿reception￿quality￿of￿the￿wireless￿charging￿transmit/receive￿system￿reaches￿the￿level of￿conventional￿telephone￿with￿a￿snap-in￿adapter.￿The￿line￿compensator￿is￿integrated￿in￿the￿luggage compartment￿on￿the￿left. F34￿LCI￿line￿compensator Index Explanation Telephone￿Antenna￿–￿roof-mounted￿antenna￿connection Voltage￿supply￿and￿activation￿line Antenna￿–￿wireless￿charging￿tray￿connection...
  • Page 39 F34￿LCI 5.￿Information￿and￿Communication Status￿LED The￿status￿of￿the￿wireless￿charging￿tray￿is￿signalled￿by￿an￿LED. The￿LED￿lights￿up￿blue￿once￿a￿metallic￿object￿is￿inserted￿in￿the￿wireless￿charging￿tray.￿During￿this time￿the￿electronics￿check￿whether￿the￿metallic￿object￿complies￿with￿the￿Qi®￿standard.￿If￿so,￿the￿LED continues￿to￿be￿blue,￿otherwise￿the￿LED￿goes￿out. Because￿of￿self-diagnosis￿during￿activation￿of￿the￿wireless￿charging￿tray￿(actuate￿slide,￿hold￿briefly￿and release),￿the￿LED￿remains￿blue￿for￿10￿seconds.￿No￿mobile￿phone￿need￿be￿inserted￿for￿this￿purpose. This￿can￿cause￿misunderstandings￿on￿the￿part￿of￿customers.￿The￿LED￿always￿remains￿blue￿for￿10 seconds￿during￿the￿activation,￿even￿if￿an￿incompatible￿mobile￿phone￿is￿inserted. If￿a￿Qi®-compatible￿device￿and￿a￿further￿metallic￿object￿(e.g.￿a￿coin)￿are￿located￿on￿the￿wireless charging￿tray,￿the￿charging￿procedure￿will￿be￿cancelled￿after￿a￿short￿while. Status￿LED Explanation Blue Self-diagnosis;￿charging￿procedure Orange Shutdown￿because￿of￿excess￿temperature￿(60°C￿/￿140°F) Detected￿foreign￿body￿(e.g.￿coin) Internal￿fault￿(Antenna￿diagnosis) The￿Qi®￿standard￿is￿not￿fully￿identical￿in￿all￿devices.￿In￿certain￿mobile￿phones￿problems￿during￿the charging￿procedure￿can￿therefore￿occur. 5.6.￿Further￿information The￿following￿table￿gives￿an￿overview￿of￿the￿product￿information￿sheets￿for￿further￿details￿on￿selected topics: Topic Product￿information Head￿Unit￿High￿2￿(HU-H2) Information￿&￿Communication System￿News￿I/15 Headunit￿Basis￿(HU-B) Information￿&￿Communication System￿News￿I/14 Apple®￿CarPlay Infotainment￿News￿2016 WiFi￿Hotspot Infotainment￿News￿2016...
