- Page 1 ORIGINAL INSTRUCTIONS OPERATOR’S MANUAL 200LC Loader Part number 51421058 edition English December 2017...
-
Page 2: Table Of Contents
Contents 1 GENERAL INFORMATION Note to the Owner ................1-1 Directives . - Page 3 Consumables ................6-3 Daily maintenance Front loader and bucket - Check .
-
Page 4: General Information
Your NEW HOLLAND dealer will instruct you in the general operation of your new equipment. (Refer to the 'Delivery Report' at the back of this manual.) Your dealer's staff of factory-trained service technicians will be glad to answer any questions that may arise regarding the operation of your machine. -
Page 5: Directives
• The loader was designed to mount on NEW HOLLAND approved tractors. The loader is designed to load and move materials with a variety of buckets and approved NEW HOLLAND attachments. - Page 6 1 - GENERAL INFORMATION • The machine must only be used, serviced, or repaired by personnel trained in the relevant working methods and safety regulations and who have been authorized to work on the machine. • The user must also observe the rules concerning general safety and accident prevention, including the Highway Code when driving on public highways.
-
Page 7: Product Identification Number (Pin)
1 - GENERAL INFORMATION Product Identification Number (PIN) Product identification plate A product identification plate (1) is located on the inside of the left-hand loader arm. NHIL17CT01800AA The identification numbers on this plate are important in the event that your loader should require future service. NHIL13CT00932AA... -
Page 8: Operator's Manual Storage On The Machine
1 - GENERAL INFORMATION Operator's manual storage on the machine There is no operator’s manual storage on the machine. Keep the operator’s manual in a safe place and have it available for use by all operators. -
Page 9: Machine Orientation
1 - GENERAL INFORMATION Machine orientation NOTE: On this equipment, left–hand and right-hand are determined by standing behind the unit, looking in the di- rection of travel. Left-hand view Right-hand view NHIL17CT01796FA NHIL17CT01797FA Rear view Front view NHIL17CT01798FA NHIL17CT01799FA... -
Page 10: Machine Components
1 - GENERAL INFORMATION Machine components NHIL17CT01807AA Machine components (1) Control valve (6) Quick attach operating lever (11) Parking stand lock arm (2) Hydraulic hoses (7) Bucket (12) Loader arm cylinder (3) Loader arm (8) Cutting edge (13) Loader tower (4) Bucket level indicator (9) Quick attach plate (14) Loader mount... - Page 11 1 - GENERAL INFORMATION...
-
Page 12: Safety Information
2 - SAFETY INFORMATION 2 - SAFETY INFORMATION###_2_### Safety rules and signal word definitions Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions. -
Page 13: Safety Rules
2 - SAFETY INFORMATION Safety rules General safety rules Use caution when you operate the machine on slopes. Dirty or slippery steps, ladders, walkways, and platforms Raised equipment, full tanks and other loads will change can cause falls. Make sure these surfaces remain clean the center of gravity of the machine. - Page 14 2 - SAFETY INFORMATION General maintenance safety Keep the area used for servicing the machine clean and pressure to escape before you completely remove the dry. Clean up spilled fluids. cap. Service the machine on a firm, level surface. Replace damaged or worn tubes, hoses, electrical wiring, etc.
