BE Power Screw Driver
Control Display User Manual
Model: KL–WSCBSN (BE)
Please scan the following QR code or download
the operation manual from KILEWS website
https://www.kilews.com.tw/tc/download-list.php
KILEWS INDUSTRIAL CO., LTD.
http://www.kilews.com.tw
Y2F216Q-1-002

Advertisement

loading
Need help?

Need help?

Do you have a question about the KL-WSCBSN and is the answer not in the manual?

Questions and answers

Related Manuals for Kilews KL-WSCBSN

Summary of Contents for Kilews KL-WSCBSN

  • Page 1 BE Power Screw Driver Control Display User Manual Model: KL–WSCBSN (BE) Please scan the following QR code or download the operation manual from KILEWS website https://www.kilews.com.tw/tc/download-list.php KILEWS INDUSTRIAL CO., LTD. http://www.kilews.com.tw Y2F216Q-1-002...
  • Page 2 1. Panel Function Display Screen: Boot Version: (Ver 2.xxx) 16X2 LCM Display Setting Function 199: Display Job Sequence  99: Display Program  SC: Display Count Value  C: Display Screw Driver Action Turns  T: Display Screw Driver Action Time ...
  • Page 3 1. OUTPU: External output control 2. INTPU: External input control. 3. PORT1 (RS232): Connect to DAS or wifi module 1. Switch element: turn on or turn off the module power 2. USB port: Connect to the barcode reader. 3. MicroSD Card port: Used to store data. 4.
  • Page 4 2. Set Function Options and Operating Instructions After switching on the power, to enter into the function menu, press the “Esc” key on the panel for 3 seconds, following which password input is required to enter the menu. CTRL Setting Set Up Time Factory Name...
  • Page 5 [6] Time Limit HT: 0.1-9.99 High Time(HT) H: 9.99 Screw lock High Time(HT) L: 0.01 Low Time(LT) LT: 0.0-9.98 Sec Screw lock Low Time(LT) While setting LT to 0.0 sec, it will activate the pre-lock function; the pre-lock time is the longest time of locking HT screws. [7] Stop Mode NS: N/Y NG Stop(NS)

  • Page 6: Confirm Mode

    1. INPUT contact, if using non-isolating (wet contact) control, it needs to connect a 10K resistor in series on the line. 2. When the automatic machine is installed, it is recommended to install the signal line on the machine and then connects to KL-WSCBSN. When working with automatic control, pay attention to the above items to prevent equipment damage.
  • Page 7 7. ERROR CODE Mode Status Description Code Description Remarks Voltage-drop protection When the voltage of the electric screw driver drops instantly, the action of the electric screw driver is stopped, and the LCM displays this symbol, representing that the screw driver is currently under low-voltage protection. Over-temperature protection When the internal temperature of the electric screw driver is too high, the action of the electric screw driver is stopped, and the LCM displays this...
  • Page 8 2.1 First, set the lock command on Program of WSCBSN Enable to switch the program used for workpiece lock through the Barcode Reader Use the KILEWS barcode to switch program among Group 1-9; there are 1-99 groups (CMD.P01-CMD.P99) of barcodes available in factory.
  • Page 9 Use KILEWS barcode format: CMD.C02 to release AS (okAll Stop) command Description: For the AS function already enabled on the WSCBSN. When AS occurs, the screw driver will be locked and unable to use; operator can use the Barcode Reader to scan the pre-prepared command barcode to release it to facilitate the operation.
