Multi-Bay Real-Time Fluorescence
Quantitative PCR System
（
MQ6 / MY6 / MQ8 / MY8 Series
Instruction Manual
The instruction manual must be properly placed in the product box during shipment.
The user is required to keep this manual in a safe place so that it can be consulted
when needed.
All rights reserved. All information contained in this manual is subject to change
without notice.
Manufacturer:
Anitoa Biotechnology (Hangzhou) Co., Ltd.
Address: China-Australia Biomedical Industry Science and Technology Park,
No.656 Binan Road, Binjiang District, Hangzhou, Zhejiang, China
Thank you for choosing our products. Please read this instruction manual carefully before
use.
Maverick qPCR
Version（V1.0）
）
Advertisement
Table of Contents
Related Manuals for anitoa MQ6 Series
Summary of Contents for anitoa MQ6 Series
- Page 1 All rights reserved. All information contained in this manual is subject to change without notice. Manufacturer: Anitoa Biotechnology (Hangzhou) Co., Ltd. Address: China-Australia Biomedical Industry Science and Technology Park, No.656 Binan Road, Binjiang District, Hangzhou, Zhejiang, China Thank you for choosing our products. Please read this instruction manual carefully before...
- Page 2 The responsibility of Anitoa is limited to the repair of the machine and the replacement of the parts, but not for the results of the experiments.
-
Page 3: Table Of Contents
Anitoa Biotechnology (Hangzhou) Co., Ltd. CONTENTS Chapter 1 Important Notes ............1 Instrument grounding ............1 Placement of the Instrument ..........1 Precautions .............. 2 After-sales service............2 Packaging, storage and transportation marking ........ 3 Instrument Identification Information ......... 4 Chapter 2 Product Overview ............ -
Page 4: Chapter 1 Important Notes
Anitoa Biotechnology (Hangzhou) Co., Ltd. Chapter 1 Important Notes The following safety measures must be observed during all phases of operation, maintenance, and servicing of this instrument. Failure to observe these measures or the warnings and precautions indicated in this manual will likely affect the basic protection provided by the instrument. -
Page 5: Precautions
Anitoa Biotechnology (Hangzhou) Co., Ltd. 3) The instrument should be placed in a place with low humidity, less dust, and far from water sources (such as pools, water pipes, etc.), with good ventilation, no corrosive gas or strong magnetic field interference, and avoiding direct sunlight and strong light sources. -
Page 6: Packaging, Storage And Transportation Marking
Anitoa Biotechnology (Hangzhou) Co., Ltd. 1.5 Packaging, storage and transportation marking Table 1-5-1 Package storage and transportation identification Description Symbol Title Position This symbol is used to indicate that Place the product is a precision instrument On the packing carefully... -
Page 7: Instrument Identification Information
Anitoa Biotechnology (Hangzhou) Co., Ltd. 1.6 Instrument Identification Information Table 1-6-1 Instrument identification information The location on the instrument Symbol Description where the symbol will appear Watch out for high On the equipment temperatures Production date On the equipment nameplate... -
Page 8: Chapter 2 Product Overview
Anitoa Biotechnology (Hangzhou) Co., Ltd. Chapter 2 Product Overview This chapter mainly describes the usage, characteristics, specifications and performance parameters of multi-bay real-time fluorescence quantitative PCR system. 2.1 Product usage Multi-bay real-time fluorescence qPCR system is a series of qPCR instruments consisting of multiple single chambers (16 wells) that can be freely combined according to demand. -
Page 9: Specification Model Description
Anitoa Biotechnology (Hangzhou) Co., Ltd. millisecond-level extremely fast shooting without row-by-row scanning, stable and reliable data. 9) Modularity: realize the modularity of single chamber, which can be integrated with other systems and has wider application scenarios. The physical picture of the single chamber is shown in Figure 2-2-1. -
Page 10: Main Technical Parameters
Anitoa Biotechnology (Hangzhou) Co., Ltd. 2 channels 48 wells 0.2ml standard PCR tubes MQ8482 4 channels 48 wells 0.2ml standard PCR tubes MQ8484 2 channels 48 wells Y-type PCR tubes MY8482 4 channels 48 wells Y-type PCR tubes MY8484 2.5 Main technical parameters... - Page 11 Anitoa Biotechnology (Hangzhou) Co., Ltd. Table 2-5-2 MQ8 / MY8 main technical parameters Basic Performance Dimension 483*286*252 mm Bare weight 11 kg 100~240VAC，50/60Hz Power ≤ 60dB Noise level PCR System Performance 10～60ul Sample volume Sample throughput 48-well (3×16-well, 3-bay module) Transparent 0.2ml single tube, 8*0.2ml row...
-
Page 12: Chapter 3 Instrument Installation
Anitoa Biotechnology (Hangzhou) Co., Ltd. Chapter 3 Instrument Installation This chapter describes the use and storage conditions of the multi-bay real-time fluorescence quantitative PCR instrument, its structural components, removal of the fixture, installation / uninstallation of the software, and preparation for power-up. This chapter takes MQ6964 as an example. -
Page 13: Power Cord Connection
Anitoa Biotechnology (Hangzhou) Co., Ltd. Power Cord Instruction Manual Factory Inspection Report Warranty Card Certificate of Conformity USB Flash Drive 3.4 Power cord connection Use the power cord supplied with the instrument. When connecting, the instrument power switch should be in the "off" state, and then turn on the instrument switch after connecting. - Page 14 Anitoa Biotechnology (Hangzhou) Co., Ltd. Power Jack Power Switch Figure 3-5-2 Back of the instrument 1) Insert the DC connector into the power jack of the instrument. 2) Turn on the instrument power switch, the power switch lights up red and the instrument power indicator (orange) lights up.
-
Page 15: Chapter 4 Software Operation Guide
PCR instrument software and the operation related to experimental data. The contents of this chapter take MQ6964 as an example. Anitoa qPCR software can be used to set up experiments, run experiments, and collect, analyze and manage experimental data. The software contains five main functional modules, namely "Home Page"... -
Page 16: System Introduction
Anitoa Biotechnology (Hangzhou) Co., Ltd. 4.1 System introduction 1) System settings mainly include user manage, customer service, and system application. Figure 4-1-1 System settings interface 第 13 页 共 19 页... - Page 17 Anitoa Biotechnology (Hangzhou) Co., Ltd. 2) Login: After clicking User Login, you can directly log in using the preset admin account. Figure 4-1-2 Login interface 第 14 页 共 19 页...
- Page 18 Anitoa Biotechnology (Hangzhou) Co., Ltd. 3) Customer service: You can scan the corresponding QR code to get the corresponding after-sales service. Figure 4-1-3 Customer service 第 15 页 共 19 页...
-
Page 19: Home Page
Anitoa Biotechnology (Hangzhou) Co., Ltd. 4.2 Home page 1) Homepage: click on the software to enter the home page, in the home page you can see 6 positions to choose from, each with 16 wells, multiple bays can be run simultaneously (Figure 4-2-1). - Page 20 Anitoa Biotechnology (Hangzhou) Co., Ltd. 2) Start-up tip: the first time to enter the program will prompt to synchronize the network and time. (Figure 4-2-2) Figure 4-2-2 Start-up tip 第 17 页 共 19 页...
- Page 21 Anitoa Biotechnology (Hangzhou) Co., Ltd. 3) Open the chamber lids: you can click to select any chamber, then open the bay lid, and click below the bays to select the amplification program for the experiment. You can also click the all-select function at the top right to open all bays at once. (The...
- Page 22 Anitoa Biotechnology (Hangzhou) Co., Ltd. 4) Set up the amplification program: Click "Select a program" at the bottom of the bays to create a new amplification program (parameters such as reaction temperature, reaction time, number of cycles, photo stage, etc.). You can also choose to use the saved amplification program template (Figure 4-2-4).
- Page 23 Anitoa Biotechnology (Hangzhou) Co., Ltd. 5) Confirm the amplification program: After selecting the program or creating a new program, enter the confirmation interface to see if you need to modify or save it, and click OK to carry out the experiment after confirming that there is no error. (Figure 4.2.5)
- Page 24 Anitoa Biotechnology (Hangzhou) Co., Ltd. 6) View experiment status: click on the chamber area in the home page to view the corresponding experiment status, you can also terminate the experiment at any time. You can view any running chambers within the experimental state, click the chamber number on the left side of the interface to view.
- Page 25 Anitoa Biotechnology (Hangzhou) Co., Ltd. 7) Click "Realtime Temp Curve" in the experiment status interface to view the temperature curve of the chamber. Figure 4-2-7 Real-time temperature curve 第 22 页 共 19 页...
-
Page 26: Amplification Programs
Anitoa Biotechnology (Hangzhou) Co., Ltd. 4.3 Amplification programs 1) Amplification program templates: the amplification program folder contains all the amplification program templates saved and downloaded by users. Figure 4-3-1 Amplification programs 第 23 页 共 19 页... - Page 27 Anitoa Biotechnology (Hangzhou) Co., Ltd. 2) Set common program: users can click the "Set as common" button above the amplification program to add it to the common program, and when the four common programs are full, you can also set another amplification program to replace it.
-
Page 28: Test Results
Anitoa Biotechnology (Hangzhou) Co., Ltd. 4.4 Test results 1) After all experiments are finished, the test results data will be saved in the results folder, which can be uploaded to the cloud, while the data will be copied out and the useless test data will be deleted. - Page 29 Anitoa Biotechnology (Hangzhou) Co., Ltd. 2) Experiment analysis: click on the experimental data box to view and analyze the data. Figure 4-4-2 Analysis page 第 26 页 共 19 页...
- Page 30 Anitoa Biotechnology (Hangzhou) Co., Ltd. 3) Melting curve analysis: click the Melting Analysis Curve button in the analysis interface. Figure 4-4-3 Melting curve page 第 27 页 共 19 页...
- Page 31 Anitoa Biotechnology (Hangzhou) Co., Ltd. 4) Standard Curve: Click the Standard Curve button in the analysis interface. Figure 4-4-4 Standard curve page 第 28 页 共 19 页...
- Page 32 Anitoa Biotechnology (Hangzhou) Co., Ltd. 5) Report export: click “Form a Report” (PDF format) in the analysis interface. Figure 4-4-5 Form a report 第 29 页 共 19 页...
-
Page 33: Chapter 5 Instrument Maintenance
Anitoa Biotechnology (Hangzhou) Co., Ltd. Chapter 5 Instrument Maintenance 5.1 Instrument cleaning (1) Instrument surface cleaning: the surface of the instrument should be scrubbed regularly with a soft cloth with a little water, and the instrument should be wiped dry after cleaning. -
Page 34: Operation Requirements
Anitoa Biotechnology (Hangzhou) Co., Ltd. the instrument, and promptly contact the manufacturer or distributor for maintenance. 5.5 Operation requirements (1) The operator may be exposed to or left with substances that are harmful or infectious to the organism during the use of the instrument. the operator needs to have relevant training and relevant qualifications. -
Page 35: Chapter 6 Faq
Anitoa Biotechnology (Hangzhou) Co., Ltd. Chapter 6 FAQ Failure Phenomenon Troubleshooting methods Checking that the power cord is connected properly. Whether the power outlet is Unable to turn on energized. Whether the instrument switch is turned on. Checking that the thermal cycle parameters are set correctly.
