Summary of Contents for Key Digital KD-FIX418A-2
- Page 1 KD-FIX418A-2 4K 18G HDMI Fixer with L/R & Optical Audio De-Embed, 4K to 1080p down-convert Operating Instructions...
-
Page 2: Table Of Contents
About KD-FIX418A-2 ........ -
Page 3: Usage Modes
Usage Modes Source Boost 4K/18 KD-FIX418A-2 Gbps Gbps 4K Source Short HDMI Long HDMI Signal Correction 4K/18 KD-FIX418A-2 Gbps Gbps 4K Source Short HDMI Long HDMI 4K to 1080p Down-Convert Mode 4K/18 4K/18 4K/18 4K AV System Long HDMI Short HDMI... -
Page 4: Quick Setup Guide
Quick Setup Guide Connections, LEDs, Slide Switches, and Rotaries CONNECT: 1. Begin with the KD-FIX418A-2 unit, input and output devices turned off with power removed 2. Connect your HDMI source to KD-FIX418A-2’s input port 3. Connect your HDMI display to KD-FIX418A-2’s output port VIDEO INPUTS AND OUTPUTS: 4. - Page 5 › Optical Audio Output: Optical audio output with de-embedded audio from the selected HDMI source EDID authentication is provided from the KD-FIX418A-2 to the connected input/source › SPDIF IEC 60958 format The EDID file (AKA “handshake”) is selected using the EDID rotary on the unit and ›...
- Page 6 4Kx2K@60, 18G, HDR, DOLBY/DTS 5.1 4Kx2K@60, 18G, HDR, HD AUDIO 4K to 1080p Down Convert Tool: 1280x720p@60 DVI When set to ON, KD-FIX418A-2 will down convert incoming 4K content to 1080p. › All non-4K incoming content passes through without resolution conversion. 1920x1080p@60 DVI When set to OFF, all incoming content passes through without resolution conversion.
-
Page 7: Specifications
Packaging: 7.4” x 5.35” x 3.14” (188 x 136 x 80 mm), Weight: 16 oz (453 g) › You MUST use the Power Supply PROVIDED with your unit or you VOID the Key Digital ® Warranty and risk damage to your unit and associated equipment. -
Page 8: How To Contact Key Digital
All Key Digital ® products are built to high manufacturing standards and should provide Customer Support years of trouble-free operation. They are backed by a Key Digital Limited 3 Year Product For customer support questions please contact us at: Warranty Policy. http://www.keydigital.com/warranty.htm... - Page 9 ® Custom Installers, System Integrators, Broadcasters, Manufacturers, and Consumers. Key Digital Systems 521 East 3rd Street Mount Vernon, NY 10553 ® Phone 914.667.9700 914.668.8666 www.keydigital.com © 2022 Key Digital, Inc. All rights reserved.
