Salto Node Installation Manual

Installation guide
Eng
Guía de instalación
E
Guide d'installation
F
The SALTO Node is part of SALTO wireless system. It works as a bridge, with the
SALTO Gateway, between SALTO's access control software and wireless locks.
El SALTO Node forma parte del sistema wireless de SALTO. Actúa como
puente, junto con el SALTO Gateway, entre el software de control de acceso
de SALTO y las cerraduras wireless.
Le SALTO Node fait partie du système radio-fréquence SALTO. Il joue
le rôle de pont, avec le SALTO Gateway, entre le logiciel de contrôle
d'accès et les serrures radio-fréquence de SALTO.
83
(3-1/4") (1-11/32")
Electrical characteristic
Eng
Operation conditions
Min Typ
Temperature
-20 25
Humidity 35
Cable requirements
RS485 Connection (AB) Generic twisted pair wire
Power Connection (Vdd)
Power Supply for SALTO RFnet
Min
Imput Voltage
7
Current consumption
Power Supply for BLUENET
Min
Imput Voltage
7
Current consumption
Note 1: 1x2x24AWG or UTP CAT5e recommended
Note 2: Power supply must be calculated taking into account SALTO Gateway
and Nodes current consumption
Mechanical installation
Eng
1 GANG ELECTRICAL STANDARD BOX
1 MÓDULO CAJA ELÉCTRICA ESTANDARD
1 BOÎTIER ÉLECTRIQUE À BRANCHEMENTS STANDARD
European view
All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any
item in this catalog, its design, construction, and/or materials.
Installation guide
SALTO Node
34
20
(25/32")
Características eléctricas
E
Max Unit
ºC
70
85
Note 1
24 AWG
Typ Max Unit
12 28 V
45 mA
Note 2
Typ Max Unit
12 28 V
75 mA
Note 2
Instalación mecánica
E
SALTO´s Software
SALTO
Gateway
Power
RS485 bus to Nodes
SALTO RFnet Characteristics
Frequency Range
Standard
Indoor Radio Range
Max output power
SALTO BLUEnet Characteristics
Frequency Range
RF Standard
Indoor Radio Range
Max output power
©
2021 SALTO Systems S.L.
*RS485 Bus *RS485 Bus
*Power Supply *Power Supply
UTP CAT5e UTP CAT5e
Up to 6 External RF Node
SALTO
per SALTO Gateway
Node
Up to 112 SALTO RFnet Lock per
SALTO Gateway (16 per SALTO Node)
Caractéristiques électriques
F
2400-2483.5 Mhz
IEEE 802.15.4
10/15m
5dBm
2400-2483.5Mhz
Bluetooth Low Energy
5m/10m
8dBm
Installation mécanique
F
1/2
SALTO
Node
221136-ED.2 - 19/12/2022
