SMD2499FS
1
2
3
4
1 Easy Wave Open indicator
2 Wi-Fi indicator
3 Hidden control panel door
4 Easy Wave Open sensor
5 Nameplate: Open the Convection Microwave Drawer fully.
The label is located at the bottom left side of the oven face
plate.
6 Drawer sealing surfaces
7 Drawer lights
NOTE:
The "START/+30 SEC" feature is disabled after 3 minutes when the oven is not in use. This feature is automatically
enabled when the door is opened and closed.
OVEN DIAGRAM
12
13
14
15
KEY SHEET
5
6
7
8
9
10
11
8 Convection Microwave Drawer guides
9 Hand holes
10 Vent
11 Menu labels
12 Glass touch control
13 Easy Wave Open button
14 Wi-Fi Connect button
