- Page 1 BG-SMB-5M USB/2.4Ghz Wireless Desktop Conference Speakerphone with 360° Audio Pickup up to 5m User Manual...
- Page 2 BZBGEAR BG-SMB-5M PRODUCT MANUAL · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com...
-
Page 3: Table Of Contents
BZBGEAR BG-SMB-5M PRODUCT MANUAL TABLE OF CONTENTS Statement Safety Precaution Introduction Features Packing List Technical Specifications Operation Controls and Functions Tech Support Warranty Mission Statement Copyright · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com... -
Page 4: Statement
● This product does not contain parts that can be maintained or repaired by users. Damage caused by dismantling the product without authorization from BZBGEAR is not covered under the warranty policy. ● Installation and use of this product must strictly comply with local electrical safety standards. -
Page 5: Introduction
PRODUCT MANUAL Introduction The BG-SMB-5M is a full duplex 16kHz echo canceling speaker-phone. The voice pickup radius is 5m, which is ideal for one-on-one and small to medium group conference calls. It uses wireless and USB connections to replace PC and smartphone speakers and microphones with outstanding audio quality. -
Page 6: Technical Specifications
BZBGEAR BG-SMB-5M PRODUCT MANUAL Technical Specifications General Voice technical Acoustic Echo cancellation (AEC): >65dB parameters Echo length cancellation: ≥500ms Bidirectional noise compression (NC): <25dB Automatic Direction finding Technology of Intelligent microphone (EMI) Automatic gain control (AGC) Audio parameters Microphone frequency response: 100Hz-22KHz... -
Page 7: Operation Controls And Functions
BZBGEAR BG-SMB-5M PRODUCT MANUAL Operation Controls and Functions 1. Ext1 and Ext2: RJ11 connectors for extension mic BG-EXM-SM5 (optional). 2. In/Out: 3.5mm stereo mini line in/out. 3. USB interface (rechargeable). 4. Din6: Not used. 5. LED status bar indicates volume level. - Page 8 BZBGEAR BG-SMB-5M PRODUCT MANUAL Button Button Function Description ON Power on/off Long press 3 seconds to turn on/off the device Volume up/down Increase/decrease the volume Speaker mute Turn on/off speaker mute function Answer/hang up Answer/Hang up call Microphone mute Turn on/off microphone mute function...
- Page 9 BZBGEAR BG-SMB-5M PRODUCT MANUAL 1. Supports Windows, IOS, Android, etc. with a USB port. 2. PC and other devices will automatically recognize and install the device. It will take approximately 1 minute to show successfully installed for first use on a new connected device..
- Page 10 BZBGEAR BG-SMB-5M PRODUCT MANUAL Note: When the terminal device is PC, please set it as PC mode. When the terminal device is the mobile phone, please set speakerphone to “mobile mode.” · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com...
- Page 11 BZBGEAR BG-SMB-5M PRODUCT MANUAL Pick up range 5m radius pick up range, fit for small to medium meeting rooms. Function Diagram · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com...
-
Page 12: Tech Support
Copyright All the contents in this manual and its copyright are owned by BZBGEAR. No one is allowed to imitate, copy, or translate this manual without BZBGEAR’s permission. This manual contains no guarantee, standpoint expression or other implies in any form. Product specification and information in this manual is for reference only and subject to change...
