Summary of Contents for Compaq iPAQ PCD-1
- Page 2 All other product names mentioned herein may be trademarks or registered trademarks of their respective companies. Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.
- Page 3 Thanks for buying a Compaq iPAQ Personal CD Player PCD-1, and welcome to the world of digital audio. Digital audio is a way of compressing recorded sound so that it takes up much less storage space. A song is reduced to about 1/10 its size, allowing you to store much more music on one CD. There are many types of digital audio formats, but MP3 and WMA are two of the most popular.
- Page 4 Headphones AC power adapter Your iPAQ Personal CD Player PCD-1 is equipped with rechargeable batteries. You can listen to your favorite music on battery power or you can plug the PCD-1 into a standard electrical outlet. To install the batteries, just follow these simple steps: 1.
- Page 5 Tip: To recharge the batteries that came with your PCD-1, just plug the PCD-1 into a standard electrical outlet while the batteries are in the battery compartment. The battery icon on the display screen shows the amount of charge held by the batteries (when the PCD-1 is not plugged into an AC electrical outlet).
- Page 6 WARNING: Permanent hearing loss may occur if headphones are used at high volume. Power button - Press to turn the PCD-1 on. Hold for two seconds to turn the PCD-1 off. Norm/Hold Switch - The Norm/Hold switch should be in the Norm position for typical usage.
- Page 7 Your PCD-1 has many outstanding features. Display Screen - Area where song and playback information is displayed along with icons and option button labels. Also displays FM radio stations. Option Buttons - Switch to modes of operation displayed above the buttons.
- Page 8 Power - Indicates that the AC power adapter is plugged in. Battery charge indicator - The number of bars visible indicates the amount of charge remaining in your PCD-1’s batteries (displays only if batteries are present and the PCD-1 is not plugged in).
- Page 9 The display area contains different types of information, depending on what mode of operation the PCD-1 is in. For example, it can display a list of playlists and tracks, information about the disc, default settings, and radio stations. While a disc is playing, the display area shows the track number, elapsed time, artist, and song title. The song title format reads ID3 information, which is set using the software included with your PCD-1.
- Page 10 PCD-1 on page 5 for details.) Tip: You must power on the PCD-1 by pressing the Power button on the side of the player. The remote control can turn the player off but will not turn it on.
- Page 11 The signal from the PCD-1 remote control will reach the player from a maximum distance of approximately 12 feet (3.8 meters) to 52 feet (16 meters), depending on the angle of the signal. To install the battery in the remote control, slide out the battery tray on the back of the remote control and place the battery in the tray as shown below.
- Page 12 Your PCD-1 has several modes of operation. Not only can you listen to your favorite music, you can also adjust many of the control and menu features. Press the option buttons below the display window to switch between modes. The following list is an overview of the various modes of operation.
- Page 13 CD. The following table shows the Navigation button functions in the Track Information directory. Button ® Play ´ Rewind PAQ PCD-1 OMPAQ I Function Begin playing first track in playlist (according to repeat mode) and switch to Playback mode...
- Page 14 Menu/LCD Control mode. Your custom bass and treble levels create the User equalizer setting.) Menu - Switches the player to Menu/LCD Control mode. See the Menu/LCD Control Mode section on page 16 for more information. PAQ PCD-1 OMPAQ I...
- Page 15 ® Play ´ Rewind ³ Stop ¨ Fast Forward PAQ PCD-1 OMPAQ I Function If a track is playing, switches the player to Pause mode. Skips to beginning of current track, or to the previously played track if at the beginning of a track.
- Page 16 Holding down the Fast Forward button causes the player to seek forward to find the next acceptable radio station signal based on strength. An “AUTO” icon is displayed as it scrolls through the frequencies. Scrolls up through presets. Scrolls down through presets. PAQ PCD-1 OMPAQ I...
- Page 17 Note: A disc must be loaded in the player to view the following information about that disc. > Volume label (if available) of the currently loaded CD > Number of tracks on the currently loaded disc > Total playing time on the currently loaded disc PAQ PCD-1 OMPAQ I...
- Page 18 Cancels all option changes and restores the previous settings. Scrolls forward through the options for the selected function. Scrolls up to select a function to be changed. Scrolls down to select a function to be changed. PAQ PCD-1 OMPAQ I...
- Page 19 LCD Scroll Rate Auto Shut Off Sort Multisession BASS TREBLE PAQ PCD-1 OMPAQ I Options Adjusts the backlight on the display screen. Choices are default, always on, and always off. Default is off after 10 seconds Sets the default Repeat mode.
- Page 20 Your iPAQ Personal CD Player PCD-1 comes with a CD that contains two of the leading software packages for managing your digital audio. > MusicMatch Jukebox 6.1 - Used for creating (“burning”) your data CDs as well as downloading and managing your music.
- Page 21 3. Click on Help at the top of the window. Select Getting Started from the drop-down menu. 4. Follow the easy instructions that guide you through finding music on the Internet. You will also learn how to copy and create CDs and playlists. PAQ PCD-1 OMPAQ I...
- Page 22 Windows Media Player 7.1 is included with your PCD-1 as an added feature. You may use Windows Media Player 7.1 to copy and manage music on your PC. Note: Windows Media Player 7.1 does not burn data CDs for the PCD-1.
- Page 23 > CD is badly scratched or dirty. Replace or clean the CD. Displays when attempting to turn on the PCD-1 when the Norm/Hold switch on the side of the player is in the Hold position. Slide this switch to the Norm position before turning on the PCD-1.
- Page 24 Use only a soft, dry cloth to clean your PCD-1 CD Player. Keep the inside free of any foreign material. > Do not remove the batteries while operating the unit. > Do not expose the unit to a significant amount of moisture.
- Page 25 Frequency Response: 20 Hz to 20 kHz Operation Temperature: –10 degrees C to 50 degrees C (15°F to 120°F) Harmonic Distortion: 0.1% Format Support: MP3, WMA, and CD-DA Software: MusicMatch Jukebox 6.1; Windows Media Player 7.1 Upgradeability: Software upgrades via the Internet PAQ PCD-1 OMPAQ I...
- Page 26 PAQ PCD-1 OMPAQ I...
