- Page 2 The limited warranties for Compaq products are exclusively set forth in the documentation accompanying such products. Nothing herein should be construed as constituting a further or additional warranty. Compaq iPAQ Personal Mini-CD Player PM-1 First Edition (September 2001) Part Number 258650-001...
- Page 3 Thanks for buying a Compaq iPAQ Personal Mini-CD Player PM-1, and welcome to the world of digital audio. Digital audio is a way of compressing recorded sound so that it takes up much less storage space. A song is reduced to about 1/10 its size, allowing you to store much more music on one CD. There are many types of digital audio formats, but MP3 is the most popular.
- Page 4 Your iPAQ PM-1 package contains the following components. Personal Mini-CD Player Inline remote control Headphones AC power adapter Two AAA rechargeable batteries Three blank 8cm discs Installation CD Getting Started guide PAQ PM-1 OMPAQ I...
- Page 5 Your iPAQ Personal Mini-CD Player PM-1 is equipped with rechargeable batteries. You have the option of listening to your favorite music on battery power or plugging the PM-1 into a standard electrical outlet. Note: Before using the PM-1 for the first time, the Ni-MH batteries should be charged for 8 hours.
- Page 6 The battery icon on the display screen shows the amount of charge held by the batteries (when the PM-1 is not plugged into an AC electrical outlet). The battery icon is divided into three segments that indicate the approximate power capacity of the batteries. Replace or recharge the batteries when the battery icon goes blank.
- Page 7 Your PM-1 player has the following features on its left side, front, and right side. Indicator Control Mode Next Prev Volume + Volume – Stop Play/Pause Hold Open Headphone Line Out < DC 3V PAQ PM-1 OMPAQ I Function Program, Repeat, Equalizer, File/Album searching Skip forward to next track/directory Skip backward to previous track/directory Increase the volume level...
- Page 8 The function keys on the inline remote control are similar to those on the PM-1 player. The inline remote control is equipped with an LCD display so that you can conveniently check the playback status. Plug your inline remote control into the headphone jack on the PM-1. Your headphones then plug into the inline remote control.
- Page 9 Playing Discs: Your PM-1 plays 8cm CD-R, CD-RW, and CD-DA discs. ESP Control: Electronic Skip Protection for CD-DA and MP3 discs. No ESP - plays without the ESP function for CD-DA (CD-RW only) discs. CD-DA - ESP time is approximately 160 seconds. MP3 - ESP time is approximately 480 seconds (128 kbps).
- Page 10 – Volume Up/Down > Increase or decrease the volume level Hold > Slide the HOLD switch to the Hold position in order to lock the current function in place and prevent the buttons on the player from operating due to inadvertent contact. Open >...
- Page 11 4. Press MODE once with the track selected to confirm your choice. The Program Count will increase by one (P--002, P--003 and so on). 5. Repeat steps 3 and 4 until you have selected the desired number of tracks (up to 32). 6.
- Page 12 This feature controls the audio equalizer. You can set the equalizer to either Normal, Classic, Pop, Jazz, or Rock. When the audio equalizer is operating, “EQ” will be displayed on the remote control’s LCD. To select one of the equalizer settings, press the MODE button until the player is in Equalizer mode (EQ), then press NEXT 2 to toggle through the options.
- Page 13 While the disc is being read, “TOC Reading” is displayed on the remote control’s LCD. “TOC” refers to the “Table of Contents.” The TOC reading time depends on the type of disc loaded in the player. It takes the player one-half to one second to read a single directory on an MP3 disc.
- Page 14 While playing an MP3 disc or a CD-DA, hold down the NEXT or PREV button on the player to move forward or backward along the current track. The PM-1 supports two file search modes: 1. Search by file number 2. Search by directory/album To search for a file, perform the following steps: 1.
- Page 15 To adjust the volume level, press the VOLUME UP (+) or VOLUME DOWN (–) button. The volume control ranges from 0 to +32. Slide the HOLD switch into the Hold position to lock the buttons on the player, including power on and off.
- Page 16 Symptom Power cannot be turned on Playback stops No sound or poor sound quality Problem Are the batteries inserted correctly? Are the batteries run down? Loose connection? Is the power adapter connected properly? Is the disc cover closed properly? Is the player in the HOLD mode? Is the CD inserted properly? Is the CD scratched or damaged? Are connection plugs inserted properly?
- Page 17 Playable Disc Type: MP3 (8cm), CD-DA (8cm) Digital Volume Control: 32 levels Audio Frequency Range: 20 ~ 20 kHz Maximum Output: > 5mW (32 Ohms) Signal to Noise Ratio: > 85 dB Total Harmonic Distortion: < 0.1% Audio Output: One 3.5 mm headphone jack Line-out: One 3.5 mm Line-out socket Type of Battery: Two 1.5V AAA (Alkaline Type Recommended) Playing Time: 4 –...
- Page 18 Your iPAQ Personal Mini-CD Player PM-1 comes with an Installation CD that contains software for managing your digital audio. > MusicMatch Jukebox - Used for creating (“burning”) your data CDs as well as downloading and managing your music. > Microsoft Windows Media Player - Used for downloading and managing digital media.
- Page 19 Follow these simple steps to activate MusicMatch Jukebox. 1. Double-click the MusicMatch Jukebox icon on your desktop to activate the software. 2. The MusicMatch Jukebox window displays the following: 3. Click on Help at the top of the window. Select Getting Started from the drop-down menu. 4.
- Page 20 Windows Media Player is included with your PM-1 as an added feature. You may use Windows Media Player to copy and manage music on your PC. Note: Windows Media Player does not burn data CDs for the PM-1. Windows Media Player features an integrated Media Guide with content from www.windowsmedia.com, a radio tuner, CD copying, multiple skins (screen designs), and much more.
- Page 21 Use only a soft, dry cloth to clean your PM-1 Mini-CD Player. Keep the inside free of any foreign material. > Do not remove the batteries while operating the unit. > Do not expose the unit to a significant amount of moisture.
- Page 22 PAQ PM-1 OMPAQ I...
