- Page 1 ODYSSEY dive computer Simplified user manual Updated on 04/01/2023...
-
Page 2: Support-Contact
DANGER The Odyssey dive computer has been designed to monitor your dive profile and to calculate decompression stop(s) requirements based on its internal model and the parameters you provide. These calculations are, at best, an estimate of actual physiological desaturation requirements and do not guarantee a safe ascent profile. Decompression sickness (DCS) is intrinsically linked to the gas load dissolved in the diver's body as a result of diving and to be off-gassed by the body during the ascent and after surfacing. -
Page 3: Technical Specifications
TECHNICAL SPECIFICATIONS Weight < 200 g Dimensions 90mm x 76mm x 36mm TFT 2.4" Display 240 x 320 px Endurance 20 hours in dive mode Battery User-replaceable AA battery Wireless connectivity Bluetooth Low Energy Maximal depth 225 m Operation temperature range 0 °C –... -
Page 4: Battery Replacement
BATTERY REPLACEMENT • Your Odyssey operates on a standard user-replaceable AA battery. Any AA battery with a voltage rating between 1.2V and 4.5V is compatible. • The battery compartment is sealed with a cap on the right side of the unit. This cap can be unscrewed (counterclockwise) with a coin. - Page 5 STARTING YOUR ODYSSEY • Your Odyssey will automatically start when submerged. This feature may not function correctly. We recommend that you always start your computer manually and check the settings carefully before diving. • Your Odyssey starts with a simultaneous press of the two piezo buttons located on the right and left side of the computer.
- Page 6 PRESENTATION OF THE BUTTONS • Your Odyssey is equipped with three piezoelectric buttons. • The side buttons allow you to navigate through the elements of a page: o Left button: navigation to the left / up o Right button: navigation to the right / down •...
- Page 7 SURFACE HOMEPAGE • The homepage shows: o Surface interval since last dive o Dive mode and current o Current conservatism o Battery power level • Four pages are accessible from the homepage: surface interval o System o Settings dive mode & gaz o Transfer conservatism o Dive...
-
Page 8: System Page
“SYSTEM” PAGE back to homepage • The “System” page contains three tabs: System, Personal Logs “SYSTEM” TAB • The “System” tab allows you to: o Check and update the clock and date o Check and update the battery type o Display the installed firmware o Access to the “Bootloader”... -
Page 9: Personal Tab
“SYSTEM” PAGE “PERSONAL” TAB back to homepage • The “Personal” tab allows you to: o Set the language and the unit system o Set the colours o Check and modify the pP, Gas, Ascent Rate and Gas Density alerts Move up / down with the left and right buttons Select / open with the central button ODYSSEY - v 1.0.20G 04/01/2023... - Page 10 “SYSTEM” PAGE “LOGS” TAB back to homepage • The “Logs” tab contains the list of dives recorded in the logbook • To view the details of a dive, select and activate the item from the list: o This opens a new page with two tabs “OVERVIEW”...
-
Page 11: Settings Page
“SETTINGS” PAGE back to homepage • The “Settings” page contains four tabs: Dive, Deco Gases Plan “DIVE” TAB • The “Dive” tab allows you to: o Set the dive mode (open-circuit or closed-circuit CC) o Select the type of water (Salt, Fresh or ISO) o Adjust the brightness of the display... - Page 12 “SETTINGS” PAGE “DECO” TAB back to homepage • The “Deco” tab allows you to: o Modify the conservatism by adjusting the GF (Gradient Factors) o Set the depth of the last stop o Adjust the duration of the additional stop o Monitor the sixteen current Bühlmann ZHL-16C tissue statuses Move up / down with the left and right buttons Select / open with the central button...
- Page 13 “SETTINGS” PAGE “GASES” TAB back to homepage • The “Gases” tab allows you to: o Modify and select the gases (up to 8) that will be used for the dive (in OC or CC mode) : “ ” WARNING Only activate the gases that are actually available and intended for the dive. Move up / down with the left and right buttons Example: for a dive with Air, deactivate all other gases.
- Page 14 “SETTINGS” PAGE “PLAN” TAB back to homepage • The “Plan” tab allows you to: o Simulate square dive plans using the current settings, displaying the ascent profile with stops, gas switches and time to surface Examples of dive plans Move up / down with the left and right buttons Select / open with the central button ODYSSEY - v 1.0.20G 04/01/2023...
- Page 15 “DIVE” PAGE • To change the information displayed in the “Dive” page, you must : o Highlight the desired field using the side buttons o Cycle through the different options by pressing the central button Ascent rate (AR) indicator « Dive status »...
- Page 16 “DIVE” PAGE • The TTS is calculated predictively according to the gases available (see p. 13) for optimized decompression. It is also possible to display the BG/TTS (Back Gas), which calculates the ascent time without changing gas. • The ascent rate indicator contains several zones. The target ascent rate can be set in the “System”...
- Page 17 “DIVE” PAGE • Example: Ascent with gas change and O'Dive additional stop O'Dive additional stop Maximum depth reached (deco stop outside the Available and recommended Gas switch performed and instantaneous PPO Bühlmann calculation) decompression gas Additional stop indicator TTS 6’ (with switch to OXY) TTS = BG TTS BG TTS 9’...
- Page 18 “DIVE” PAGE ACCESS TO THE “SETTINGS” PAGE DURING A DIVE • It is possible to access the “Settings” page during a dive in order to modify parameters (GF, gas, ...). To do this, press the central button without having selected a field (if necessary, navigate with the side buttons so that no field is highlighted). •...
- Page 19 “DIVE” PAGE CCR DIVE MODE • It is possible to switch from the (open-circuit) mode to the (closed-circuit) mode in the “Settings” page / “Dive” tab. In this case you must : o Define the 3 PPO Set Points o Choose the diluent gas from the gases selected in the “Gases” tab •...
- Page 20 “DIVE” PAGE DIVING IN CONSECUTIVE MODE • For surface intervals of less than 3' the computer remains in the “Dive” mode, recording any new dive in the same profile. • After 3', a new dive in repetitive mode will be recorded. 0’...
- Page 21 “TRANSFER” PAGE UPLOADING THE DIVE PROFILE TO THE O'DIVE APPLICATION • Once the dive is recorded in the logbook, it is possible to import the profile into the O'Dive application via the Bluetooth connection. O’Dive app ODYSSEY - v 1.0.20G 04/01/2023...
- Page 22 “TRANSFER” PAGE IMPORTING O'DIVE SETTINGS INTO THE ODYSSEY • After having performed a simulation in the O'Dive app, it is possible to automatically set up your Odyssey : o Set the Odyssey to “Transfer” mode o Press “Send to Odyssey” in the O’Dive app to modify the settings (GF, Gas, PPO and O’Dive additional stop).
-
Page 23: Installing Firmware Upgrades
INSTALLING FIRMWARE UPGRADES (1/2) • Firmware is upgraded via the built-in wireless Bluetooth connection to a PC or Android telephone WARNING Before starting the firmware upgrade process, you should ensure that your Odyssey has a fully charged battery and that you have enabled Bluetooth and internet access on PC or telephone. - Page 24 INSTALLING FIRMWARE UPGRADES (2/2) • Start the firmware manager on your PC or telephone (available for download on our website https://o-dive.com) • The firmware manager will scan for your Odyssey and then automatically connect and download a list of available firmware. You can select any of the available firmware, including previous versions, for installation by double clicking or tapping one of them •...
- Page 25 EU - SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, Azoth Systems SAS, declares that the radio equipment Odyssey is in conformity with the EN 13319 standard. The full text of the EU declaration of conformity is available at the following internet address: https://o- dive.com/en/declaration-of-conformity/...
