Vicon VAX-D403R Quick Installation Manual

QUICK INSTALLATION GUIDE
VAX-D403R AND VAX-D405R
VANDAL-RESISTANT 13.56-MHz SMARTCARD READERS
This Quick Start Guide is intended for experienced installing
technicians. It is a basic reference to ensure all connections are
properly made. It is for models VAX-D403R and VAX-D405R. For
additional information please refer to Vicon's website
vicon-security.com.

1.0 Introduction

A key component of a physical security electronic access control
system, a contactless smartcard reader is based on RFID
technology. In operation it is capable of reading data stored
on a proximity credential via radio frequency and without
physical contact, and then passing the data obtained to the
physical access control system. Access control systems typically
manage and record the movement of individuals through a
protected area, such as a locked door.

2.0 Mounting Provisions

Each reader may be installed either indoors or outdoors.
Mounting options shown in the table below. Use supplied #6
mounting screws, or equivalent security screws, for installation.
Model Mullion Mount
•
VAX-D403R
VAX-D405R
*Plastic or metal

3.0 Reader Wiring

Wiegand
Conductor Function
Red DC (8-14 VDC)
Black Ground
Green Data 0
White Data 1
Brown Red LED
a
Orange Green LED
b
Yellow Card Present
Blue Beeper
Violet fleaPower
Drain Shield Ground

4.0 Cable Requirements

24 AWG minimum, multi-conductor stranded with an overall foil
shield, for example Belden 9535 or similar, supporting the five
conductors comprising the physical layer of the Wiegand inter-
face (power, ground, data 0, data 1, and/or beeper and LED).
Alternatively, Belden 9539 or similar, for all reader functions.
Contact your access control system manufacturer for their spe-
cific requirements. Per the SIA's Wiegand specification, maximum
cable length is 500 feet (152 m).
Single-Gang Wall Mount*
•
Magstripe
Conductor Function
Red DC (8-14 VDC)
Black Ground
Green Clock
White Data
Brown Red LED
Orange Green LED
Yellow Card Present
Blue Beeper
Violet fleaPower
Drain Shield Ground

5.0 Output Formats

• Wiegand (industry standard 26-bit Wiegand and
custom Wiegand formats).
• Magnetic Stripe (ABA Track II, clock and data, with card
present).

6.0 Grounding

Shield (drain) continuity must run from the reader to the access
panel. Shield (drain) and reader ground must be tied together at
the access panel and connect to an earth ground at one point.

7.0 Power

Reader may be powered by the access panel. A linear power
supply is recommended for best operation.

8.0 Voltage and Current

Voltage: 8 to 14 VDC.
Current Draw: 135 mA typical @12

9.0 Read Mode

For sector (access control) reads, pull the purple conductor low.

10.0 Connection

Connection must be done in accordance with NFPA 70. Do not
connect to a receptacle controlled by a switch. Connect to a
power limited DC voltage source.

11.0 Troubleshooting

1. When the reader is first powered on it will beep 4-times, and
the LED will shine red.
2. Presenting a supported access credential will result in the
reader beeping and the LED flashing once.
NOTE: The access panel controls LED functionality,
such as switching the LED to green.
WIRING NOTES: Single Line LED: This is the standard operating mode and
a
does not make use of the Orange conductor. The LED is Red when the reader is
idle and flashes when a card is presented. The LED turns Green when the
Brown conductor is pulled low by the access control panel.
Dual Line LED: This mode makes use of both the Brown and Orange
b
conductors. The Brown conductor controls the Red LED and the Orange
conductor controls the Green LED. LED states are determined by the access
control system option and capability.
Unused conductors should be trimmed, isolated and taped back to prevent
unintended current flows. Apply positive voltage only to the Red DC conductor.
XX274-45
VDC.
