QUICK INSTALLATION GUIDE
VAX-PCR-35L AND VAX-PCR-640L
MOBILE-READY PROXIMITY READERS
WITH OSDP SUPPORT
This Quick Start Guide is intended for experienced installing
technicians. It is a basic reference to ensure all connections
are properly made. It is for models VAX-PCR-35L-OSDP and
VAX-PCR-640L-OSDP. For additional information please refer to
Vicon's website vicon-security.com.
1.0 Introduction
A key component of a physical security electronic access control
system, a mobile-ready reader combining BLE and proximity
technologies is based on RFID technology. In operation it is capable
of reading data stored on a proximity credential via radio frequency—
or reading data from mobile credential stored in a smartphone's
wallet app via BLE technology—and without physical contact, and
then passing the data obtained to the physical access control system.
Access control systems typically manage and record the movement of
individuals through a protected area, such as a locked door.
2.0 Mounting Provisions
Each reader may be installed either indoors or outdoors. Mounting
options shown in the table below. Use supplied #6 mounting screws,
or equivalent security screws, for installation.
Model Mullion Mount
VAX-CR-35L-OSDP
VAX-CSR-6.4-OSDP
*Plastic or metal.
3.0 Cable Requirements
Cable, 4 conductor, 22 or 24 AWG [65 mm or 51 mm] twisted pair,
over-all shield and UL approved (Belden 8273, or equivalent).
Maximum bus length: 4,000 ft – 24 AWG (1,219 m)
Maximum distance between: 1,640 ft – 24 AWG (500 m).
4.0 Reader Wiring
OSDP
Twisted Pair Conductor
Red
Pair 1
Black
Green
Pair 2
White
Single-Gang Wall Mount*
• •
•
Function
DC (5-16 VDC)
Ground
RS-485 Tx+
RS-485 Tx-
5.0 Output Formats
The SIA standard OSDP protocol is supported for clear and secure
channel communication.
Default Address: 0
Default Baud rate: 9600bps (bits per second)
Default Secure Channel Key:
SCBK_D = 0x303132333435363738393A3B3C3D3E3F.
OSDP Protocol Technical Support:
SIA OSDP Application Profile: Basic Reader (OSDP v2.2 and higher)
6.0 Grounding
Shield (drain) continuity must run from the reader to the access
panel. Shield (drain) and reader ground must be tied together at
the access panel and connect to an earth ground at one point.
7.0 Power
Reader may be powered by the access panel. A linear power
supply is recommended for best operation.
8.0 Voltage and Current
Voltage: 8 to 14 VDC
Current Draw: 60mA typical, 90mA peak
9.0 Connection
Connection must be done in accordance with NFPA 70. Do
not connect to a receptacle controlled by a switch. Connect
to a power limited DC voltage source.
10.0 Troubleshooting
1. When the reader is first powered on it will beep 4-times,
and the LED will shine red.
2. Presenting a supported access credential will result in the
reader beeping and the LED flashing once.
3. Mobile operation is optimized for smartphones supporting
BLE (Bluetooth LE) version 4.2 or newer. Further, for
the downloading of mobile access credentials, a stable,
high-quality internet connection is recommended.
4. OSDP communications with the panel will be established after
the reader has completed its start-up sequence. The panel
can query the reader for status using OSDP commands.
NOTE: At this point, the access panel controls the reader beeper
and LED functionality.
