USER MANUAL
GP 1 - GP 2
Wottan Motor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP 1 and is the answer not in the manual?

Questions and answers

Related Manuals for Wottan motor GP 1

Summary of Contents for Wottan motor GP 1

  • Page 1 USER MANUAL GP 1 - GP 2 Wottan Motor...
  • Page 2 Welcome to Wottan Motor Dear owner: Congratulations on your choice of a GP 1 e GP 2 model and thank you for your trust in us. In order to operate your vehicle safely and to keep it in perfect condition at all times, we recommend that you carefully read the instructions in this manual and follow the stipulated maintenance procedures.

  • Page 3: Table Of Contents

    CONTACT LOCK GP 1 trasmission and chassis ......44 Operation ............18 GP 2 trasmission and chassis ......45 GP 1 lubricants and operating fluids ....46 DASHBOARD GP 1 electrical equipment ......... 46 GP 1 elements ........... 20 GP 2 lubricants and operating fluids ....47 GP 2 elements ...........

  • Page 4: Introduction

    INTRODUCTION WOTTAN MOTOR has designed, tested and produced this motorbike using the most advanced technology in order to offer you a safe and enjoyable ride. to provide you with a pleasant and safe ride. Your WOTTAN will provide you great moments of fun while being a practical, safe and economical means of transport.

  • Page 5: Security Check

    Before driving, perform a safety check using the enclosed checklist. Take the safety check seriously. Perform proper maintenance before you start your journey. A technically fault- free motorbike is a basic requirement for your safety and that of other road users. Wottan Motor Page...
  • Page 6 - Total weight - Brake fluid level. In the event of problems or difficulties, contact an authorised service point. WARNING Do not touch the ignition system while the engine is running. Wottan GP 1 - GP 2 User Manual 2023 Page...
  • Page 7 WARNING For your safety, only use original accessories or products approved and certified by Wottan Motor. NOTE Our approved products and accessories are available at all authorised points of sale and in our website www.
  • Page 8 On wet roads or in the presence of loose gravel, be aware that your stability and braking power are limited by the grip of the wheels on the road surface and the distance may be greater. Drive economically and be environmentally friendly. Wottan GP 1 - GP 2 User Manual 2023 Page...
  • Page 9 Hard acceleration and braking cause high fuel consumption and increased pollution levels. Wet brakes Washing the scooter or driving through water or rain can delay the braking effect due to wet or (in winter) icy brake discs or pads. Wottan Motor Page...
  • Page 10 Also, during the first 500 km of the unit as well as when changing discs or pads there is an adaptation period during which the components adjust and gradually increase their efficiency. Wottan GP 1 - GP 2 User Manual 2023 Page / 10...
  • Page 11 - High traffic density, especially in large cities with many stops and traffic lights. - Short, frequent journeys with constant starting and stopping of the engine. - Driving in traffic jams with slow and dense traffic. Plan journeys in advance to avoid heavy traffic. Wottan Motor Page / 11...
  • Page 12 - Check the engine oil level frequently, it is recommended to check the oil level every 500km maximum. On journeys of more than 50km it is recommended to check the oil level before setting off. Wottan GP 1 - GP 2 User Manual 2023 Page...

  • Page 13: Transported Cargo

    Be especially careful in side winds and when overtaking large vehicles such as trucks and buses. Do not place any material outside the spaces designed for transport. Wottan Motor Page / 13...

  • Page 14: Running-In

    The first inspection should be carried out immediately at 1.000 km or 4 months (whichever comes first). You can save delays by making an appointment with an authorised service agent in advance. Wottan GP 1 - GP 2 User Manual 2023 Page...
  • Page 15 New brake pads must be used and will not have their full frictional power until after 500 km of use. The effect of reduced braking power can be compensated by increased brake lever pressure. During this period, avoid unnecessary heavy braking actions. Wottan Motor Page / 15...

  • Page 16: Vehicle Identification

    The engine number (3) is accessible from the left-hand side of the vehicle. Place your vehicle on the centre stand and note the engine serial number on the front of the right-hand crankcase. Wottan GP 1 - GP 2 User Manual 2023 Page / 16...
  • Page 17 Wottan Motor Page / 17...

  • Page 18: Contact Lock Operation

    All circuits are OFF and the key can be removed. 3. Engine off and steering locked To lock the steering, turn the handlebar to the left, then insert the key. Wottan GP 1 - GP 2 User Manual 2023 Page / 18...
  • Page 19 Wottan Motor Page / 19...

  • Page 20: Dashboard Gp 1 Elements

    The fuel gauge indicates the amount of fuel in the tank. When the last segment of the fuel gauge starts flashing, refuel as soon as possible. 5. Neutral indicator light This warning light illuminates when in neutral. Wottan GP 1 - GP 2 User Manual 2023 Page / 20...
  • Page 21 Shows the engine speed in revolutions per minute. 8. Speedometer Shows the driving speed in kilometres per hour 9. Temperature warning light If the warning light comes on, stop the vehicle immediately and contact technical support. Wottan Motor Page / 21...

  • Page 22: Gp 2 Elements

    The fuel gauge indicates the amount of fuel in the tank. When the last segment of the fuel gauge starts flashing, refuel as soon as possible. 5. Neutral indicator light This warning light illuminates when in neutral. Wottan GP 1 - GP 2 User Manual 2023 Page / 22...
  • Page 23 Shows the engine speed in revolutions per minute. 8. Speedometer Shows the driving speed in kilometres per hour 9. Temperature warning light If the warning light comes on, stop the vehicle immediately and contact technical support. Wottan Motor Page / 23...

  • Page 24: General View

    Conversely, when it is turned to the “ “ (low beam) position, the low Wottan GP 1 - GP 2 User Manual 2023 Page / 24...
  • Page 25 Do not set the switch in this position while driving 2. Front brake lever To engage the front wheel brake, slowly press the brake handle on the right hand handlebar. When the motorbike engages the hydraulic brake, do not press Wottan Motor Page / 25...

  • Page 26: Fuel Tank Cap

    Ensure that the fuel tank cap is correctly installed before driving. Fuel leaks pose a fire hazard. WARNING Do not overfill the tank. Never spray fuel on a hot Wottan GP 1 - GP 2 User Manual 2023 Page / 26...

  • Page 27: Exhaust System

    - Park the vehicle in a place where pedestrians or children will not touch the hot exhaust system. - Ensure that the exhaust system has cooled down Wottan Motor Page / 27...
  • Page 28 Due to the ratchet mechanism, it is not possible to shift two or more gears up or down in a single operation. Wottan GP 1 - GP 2 User Manual 2023 Page / 28...

  • Page 29: Rear Brake Pedal

    DRIVING INSTRUCTIONS > REAR BRAKE PEDAL Press this pedal to apply the rear wheel brake and the brake light will illuminate. Wottan Motor Page / 29...
  • Page 30 Once the side stand is removed, the motorbike can be started normally. Wottan GP 1 - GP 2 User Manual 2023 Page / 30...
  • Page 31 Wottan Motor Page / 31...

  • Page 32: Maintenance Instructions Maintenance And Cleaning

    - To clean the motorbike, use a soft sponge and clean WARNING water Always perform a brake test after cleaning and before - Then dry with a cloth or chamois. starting a journey! Wottan GP 1 - GP 2 User Manual 2023 Page / 32...
  • Page 33 As a precaution, (especially in winter), care for parts Care for parts susceptible to corrosion with an susceptible to corrosion with anti-rust products. anticorrosion agent. CAUTION Never use paint polish on plastic parts. Wottan Motor Page / 33...

  • Page 34: Tyres And Storage

    For your safety, it is advisable to change tyres when they show signs of wear and/ or when the tyre compound becomes harder as it has lost grip properties. Wottan GP 1 - GP 2 User Manual 2023 Page / 34...
  • Page 35 - Clean the motorbike. - Fit the charged battery. - Preserve the battery terminals with terminal grease. - Check/adjust tyre pressure. - Check brakes. - Perform activities according to inspection plan. - Perform safety checks. Wottan Motor Page / 35...

  • Page 36: Technical Changes, Accessories And Spare Parts

    Although we monitor the market, we cannot evaluate or be responsible for the quality of unapproved Wottan GP 1 - GP 2 User Manual 2023 Page / 36...
  • Page 37 Change the engine oil according to the maintenance period indicated in the maintenance schedule. When driving in a dusty area, the engine oil should be changed more often than is indicated in the maintenance schedule. Explanation: Wottan Motor Page / 37...
  • Page 38 Measure the tread depth in the centre (2) of the tyre. Wottan GP 1 - GP 2 User Manual 2023 Page / 38...
  • Page 39 The use Rear: 140/70-16 of non-approved tyres or rims increases the risk of an accident. Wottan Motor S.L. accepts no responsibility Incorrect tyre pressure will have a significant effect for any damage to tyres and rims that may appear as...
  • Page 40 Never install a fuse with a higher rating, as this could Do not tilt the battery as acid may leak from destroy the entire electrical system. ventilation openings. Wottan GP 1 - GP 2 User Manual 2023 Page / 40...
  • Page 41 Although the battery does not require maintenance, battery. never leave the battery discharged. Keep the battery clean and dry and make sure that the connection terminals are firmly in place. Wottan Motor Page / 41...
  • Page 42 Spark plug: NGK CPR8EA-9 Fuel system: Idle: 1.450 ± 100 rpm (with the motorbike warm once stabilised after start-up) Air filter: Air filter with element Starter system: Electric Wottan GP 1 - GP 2 User Manual 2023 Page / 42...
  • Page 43 Transistorised ignition system with electronic ignition control (ECU) Spark plug: NGK CPR8EA-9 Fuel system: Idle: 1.450 ± 100 rpm (with the motorbike warm once stabilised after start-up) Air filter: Air filter with element Starter system: Electric Wottan Motor Page / 43...
  • Page 44 Light metal (ALU) 150/70-17 passenger: Front: 2.1Kg/cm' Rear: 2.4Kg/cm' Tyre pressures: passengers: Front: 2.2Kg/cm' Rear: 2.6Kg/cm' Front brake: 300 mm double piston disc Rear brake: 240 mm single piston disc Wottan GP 1 - GP 2 User Manual 2023 Page / 44...
  • Page 45 Light metal (ALU) 110/70-16 Rear wheel: Light metal (ALU) 140/70-16 One passenger: Front: 2.1Kg/cm' Rear: 2.4Kg/cm' Tyre pressures: Two passengers: Front: 2.2Kg/cm' Rear: 2.6Kg/cm' Front brake: 300 mm double piston disc Rear brake: 240 mm single piston disc Wottan Motor Page / 45...

  • Page 46: Engine Oil

    LED 12V 0.1W Indicator of control lights and high beam: LED 12V 0.01W Rear position/brake light: LED 12V 12W Front/rear turn signal light: LED FR: 12V 6W 12V 1.3W Wottan GP 1 - GP 2 User Manual 2023 Page / 46...

  • Page 47: Fuses

    Position light: LED 12V 4.4W/3W Speedometer lights: LED 12V 0.1W Indicator of control lights and high beam: LED 12V 0.01W Rear position/brake light: LED 12V 12W Front/rear turn signal light: LED FR: 12V 6W 12V 1.3W Wottan Motor Page / 47...
  • Page 48 DIMENSIONS AND WEIGHTS Overall length: 2.050 mm Handlebar width: 720 mm Maximum height: 1.155 mm Wheelbase: 1.420 mm Wet weight: 167 kg Wottan GP 1 - GP 2 User Manual 2023 Page / 48...
  • Page 49 DIMENSIONS AND WEIGHTS Overall length: 1.961 mm Handlebar width: 738 mm Maximum height: 1.077 mm Wheelbase: 1.313 mm Wet weight: 155 kg Wottan Motor Page / 49...

  • Page 50: Book Maintenance

    BOOK MAINTENANCE * We inform you that your data will form part of a file owned by WOTTAN MOTOR S.L. and the Dealer and/ or the Official Service, for opinion polls and statistical purposes, as well as to inform you periodically of new products and services, both by written and electronic means, and such information may be appropriate to your particular profile.
  • Page 51 Wottan Motor Page / 51...

  • Page 52: Warranty

    WARRANTY Warranty conditions In the event of a malfunction occurring, Wottan Motor will provide the customer with warranty service through the authorised service agent within the scope of its statutory warranty obligations: 1. Within a period of 36 months after the date of registration of the scooter, the company will rectify any...
  • Page 53 Repairs carried out in workshops not authorised by Wottan Motor and failure to comply with the maintenance intervals in the workshop at an authorised Service Point shall also result in the warranty being voided.

  • Page 54: Wear Parts List

    Depending on load and care after 1500 km, check with every maintenance. Wires Depending on load and care after 1500 km, check with every maintenance. Coatings Plastic parts will be damaged by caustic cleaning agents, penetrants or solvents. Wottan GP 1 - GP 2 User Manual 2023 Page / 54...
  • Page 55 Spark plug With every second service interval. Depending on use and care from the sixth month. In winter and short distance operation, even earlier. Rust is a lack of Exhaust system, inspection of assemblies maintenance! Wottan Motor Page / 55...

  • Page 56: Exclusions

    Authorised Service network. 1.2 Failure to have passed the inspections in accordance with the Wottan Motor Scheduled Maintenance Plan. 1.3 Defect caused by abnormal driving, participation in any type of competition or use outside traffic lanes, roads in poor condition or hostile areas.
  • Page 57 2. The Wottan Motor Official Warranty does not assume or cover the following: 2.1 Expenses resulting from periodic maintenance. 2.2 Costs of cleaning, inspection and/or pre-delivery assembly. 2.3 Expenses for the preparation of estimates for repairs that are not covered by the Wottan Motor Official Warranty. Wottan Motor...
  • Page 58 2.5 Financial compensation for the period of maintenance and repair, whether or not they are covered by the Wottan Motor Official Warranty: loss of time, loss of business, loss of working days, expenses for rental vehicles, etc.
  • Page 59 Al fine di avere una maggiore conoscenza del vostro veicolo, quando possibile, eseguire operazioni di manutenzione o riparazione presso Wottan Agent dove il veicolo è stato acquistato. Wottan Motor Page / 59...
  • Page 60 If a vehicle failure occurs within the warranty period, please contact the Wottan Dealer or Agent where the vehicle was purchased, or the nearest one if this is not possible, and arrange a visit to carry out the necessary work. Wottan GP 1 - GP 2 User Manual 2023 Page / 60...
  • Page 61 If you need any clarification regarding the information contained in this manual, please consult your Wottan Motor dealer or, if you prefer, contact Wottan Motor, S.L. Customer Service.

  • Page 62: Inspection Plan

    Every 4.000 km or after 12 months since the last service. After the warranty period, the inspection intervals specified in this manual must be applied as follows: Every 4.000 km or 12 months. Wottan GP 1 - GP 2 User Manual 2023 Page / 62...
  • Page 63 Altering safety-related parts could threaten the safety of yourself and others. This applies especially to the exhaust system, carburettor, ignition system, fork column, brake system and lights. Before working on the electrical system, disconnect the negative terminal of the battery. Wottan Motor Page / 63...
  • Page 64 MAINTENANCE TABLE WOTTAN MODELS: GP 1 & GP 2 R = Replace I = Inspection, cleaning and adjustment (replacement if necessary) L = Lubrication MAINTENANCE INTERVALS ARE PERFORMED ON A MILEAGE OR TIME BASIS, WHICHEVER COMES FIRST 500 km 3.000 km 6.000 km...
  • Page 65 MAINTENANCE TABLE WOTTAN MODELS: GP 1 & GP 2 R = Replace I = Inspection, cleaning and adjustment (replacement if necessary) L = Lubrication MAINTENANCE INTERVALS ARE PERFORMED ON A MILEAGE OR TIME BASIS, WHICHEVER COMES FIRST 500 km 3.000 km 6.000 km...

  • Page 66: Revision Table

    From the third service onwards, the service intervals will be every 3.000 km or 1 year, with the engine oil level to be checked every 500 km by the owner. If deemed necessary, WOTTAN MOTOR may reduce the interval between service intervals if it considers that the vehicle should be serviced.
  • Page 67 Wottan Motor Wottan Motor Page / 67...
