Iron logic Z-595 EHT User Manual

Z-595 EHT
Z-595 EHT RFID Electronic Furniture Lock
with EM-Marine & HID ProxCard II & Atmel (T5557) reader (125 kHz)
1. OVERVIEW
Z-595 EHT electronic lock is a reader for contactless keys with a controller powered by one 9V
PP3/E battery. One battery should suffice for 20,000 openings or 2.5 years in stand-by mode.
This lock has unique enclosure design and installation method, allowing it to be mounted on any
metal or wooden furniture, and get connected within 5 minutes.
Locking part of Z-595 EHT is fully identical in dimensions with a CAM LOCK mechanical lock,
which enables installation of Z-595 EHT into any opening made for that lock.
Compact in size, supporting both single-user and multi-user modes, easy in installation,
programming and servicing, this lock is a perfect Access Control solution for various storage
places like work clothes locker, mailboxes, office furniture, trade equipment.
Z-595 EHT can operate in five different modes:
- Gym Mode keys are not tied to locks. Any key can open and close any free locker.
- Logic Mode keys are not tied to locks. Any key can open and close any free locker. The
number of used locker and battery levels are stored into keys. This is convenient when the
client forgets which locker he used. Can limit the allowed number of lockers per client
(1 to 15). Computerized journaling of attendance times, reports, software administrators audit.
- General Mode a typical lock controller operation: only the key(s) stored in the lock's memory
(maximum 24) can open that lock.
- Safe Deposit Box Mode the lock emulates safe deposit box operation. To open the lock, all
the keys stored in controller database (maximum 24) must be presented to it, one after
another.
- Custom Mode can be designed for your specific needs. We will issue custom firmware, to be
downloaded into the lock via an Z-2 USB RF-1996 adapter.
Z-595 EHT Operational Modes Comparison Table.
Feature
Any key can open/close any locker
Limit on lockers number that can be taken
by one bracelet. The operator defines the
maximum lockers number for one bracelet
(1...15)
Logging of free/taken lockers through time
Logging the gym attendance times
Information Kiosk (tells the client their
locker number, if forgotten)
Battery charge level stored into bracelet
Encryption, protection against bracelet
-
cloning
Locks setup and further use without a PC
Note:Logic Mode requires special Atmel (T5557) keys and Lock Manager software.
and standalone controller
User Manual
Gym Logic*
+
+
www.ironlogic.me
Operational Modes
General Safe Deposit Box
+
+
+
+
+
+
+
+
Custom
+
+
+
+
+
+
+
+ +
page 1
