tecanno Vent Three 100 Quick Start Manual

COVER INSTALLATION

Vent Three 100/125, FIVE 100, FRAME 100
1.
slots
fl exible tabs
Vent housing and vent cover
1. Vent THREE 100/125 with four slots
2. Vent cover with four fl exible tabs
Cover installation shown on the example of vent THREE 100/125.
Cover installation of vent FIVE 100 and vent FRAME 100 in the same way.
ATTENTION: To avoid contamination on the vent, it is recommended
to wear fabric gloves!
3
Lean the cover onto the vent.
2.
1
Hold the cover fi rmly on the right and left side. With your index
and middle fi ngers, guide the top vent cover tabs to the top slots
and insert them. Hold the cover at a slight angle.
4
Insert the two fl exible tabs into the free slots.
2
Keeping the cover at a slight angle and the tabs inserted, pull the
cover toward the other two fl exible tabs.
FIVE 100
FRAME 100
5
Now the cover is fi rmly in position.
