Animex AMX P40 Quick Start Manual

SUPPORT POST
HEIGHT REDUCTION
IF TOP LIP FOLDED
(24in / 610mm)
REFER TO ELEVATION VIEW
WIRE & FIXING SPACINGS
(ADJUST & ADD MORE AS REQUIRED)
ABOVE GRADE
SIDE TO BE ENCOUNTERED BY ANIMALS
BELOW GRADE
12in / 300mm
SECTION VIEW
NOT TO SCALE
WEATHER PROOF ZIP-TIE OR WIRE & WASHER
12in / 300mm (min.)
HORIZONTAL STRAINING WIRE
0.75in / 20mm ø
ATTACHING & JOINING SECTIONS
SCALE 1:4
4in / 100mm
12in / 300mm
OVERLAP ANIMEX®
DRILL HOLE
OVERLAP ANIMEX® & CUT TO FIT TERRAIN
DESERT TORTOISE FENCING - PERMANENT
- AMX P40 / 1015 - BELOW GROUND INSTALLATION -
www.animexfencing.com
6ft / 1.8m
(ADJUST AS REQUIRED)
SUPPORT POST
TOP LIP FOLDED OVER
40in / 1000mm
HORIZONTAL WIRE
8in /200mm (Approx.)
FIXINGS
AMX P40/ 1015
(BOTTOM LIP SCORE LINE NOT FOLDED)
ELEVATION VIEW
NOT TO SCALE
3ft / 900mm
USE FIXINGS AS REQUIRED TO ENSURE
UP & DOWNHILL
NOT TO SCALE
info@animexfencing.com
ON A3 SIZED ORIGINAL (MM) 0
WIRE CLIP WASHER & TIE
BACK FRONT
BACK FRONT
(OR)
FASTEN TOP LIP IF REQUIRED MATERIAL IF REQUIRED
ANIMEX® BARRIER
(PERFORATIONS OPTIONAL)
SECURE JOIN & NO GAPS
NOTES:
This specification should be used to
aid installation. Measurements are
accurate but may need to be adjusted
dependent on location, conditions
and local authority recommendations.
10 20 30 40 50
REMOVE EXTRA POST
ABOVE GRADE
BELOW GRADE
12in / 300mm
SAFETY CAP
(OPTIONAL)
CORNERS & TURN-AROUNDS
NOT TO SCALE
PRODUCT NO.
AMX P40
AMX P1015
