Important Safety Instruction 1. Read these instructions – All the safety and operating instructions should be read before this product is operated. 2. Keep these instructions – The safety and operating instructions should be retained for future reference. 3. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.
Page 3
filled with liquids, such as vases, shall not be placed on apparatus. 18. The use of the equipment in moderate climate. 19. WARNING: Please refer the information on exterior bottom enclosure for electrical and safety information before installing or operating the apparatus. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table- cloths, curtains etc.
Page 4
Precautions Safety Information-caution: 1. In order to shut off power to this product completely, unplug the power cord from the wall outlet. Be sure to unplug the unit if you do not intend to use it for an extended period of time, such as during a vacation. 2.
Page 5
Before Use 1. Choose unit installation location carefully. Avoid placing it in direct sunlight or close to a source of heat. Also avoid locations subject to vibrations and excessive dust, cold or moisture. Keep away from sources that hum, such as transformers or motors. 2.
Product Overview Top view ITEM DESCRIPTION Turntable Aluminum alloy turntable. Spindle Place a record onto the spindle to play. Counterweight Turn to adjust the needle pressure. Anti-skate control Turn to adjust the inward tracking forces that occur with certain pick-up when the stylus nears the center of the record.
Rear view ITEM DESCRIPTION Line out jack Plug the included RCA cable into this jack. Make sure red to red and white to white. PRE-AMP ON/OFF Ensure pre-amp switch is switched to “ON” for “LINE IN” switch connection. For “PHONO ON” connection pre-am switch would be switched to “OFF”.
Page 8
Installing the platter and turntable mat Note: The belt is preinstalled on the bottom of the metal platter. 1. Make sure that the belt is not twisted, then use your thumb to stretch the belt until it reaches the round hole in the platter. Note: Make sure that you place the belt on the metal track and not on be section with teeth.
Page 9
3. Align the round hole in the platter with the pulley and use your finger to hook the belt onto the pulley. 4. Place the turntable mat on the platter. Note: When you want to take out the platter from the turntable, remove the mat first, then grasp the platter and pull it upward.
Page 10
Attaching and adjusting the counterweight The counterweight on the tone arm adjusts the needle pressure. If the pressure is too much, sound is distorted. If the pressure is too little, track skipping happens more frequently. 1. Hold the counterweight with the black number ring on the counterweight towards you, and then slightly push the counterweight into the end of tone arm.
Page 11
3. Set the Anti-Skating control to 0 (zero). 4. Release the lock catch, push the tone arm lifter forward so that the tone arm leaves the base, then push the tone arm left to the position above the turntable. CAUTION: Make sure that the needle does not contact any part of your turntable.
Page 12
6. Hold the metal counterweight at the back of the tone arm. 7. Hold the metal counterweight to keep it from moving, and then carefully rotate the front black number ring so that 0 is in the 12 o'clock position. Note: Do not turn the metal counterweight.
1. Closing the top cover helps prevent dust from settling on the turntable. 2. Always relock the tone arm clip before transporting your turntable. Listening to music using Mitchell Acoustics uStream Bluetooth speakers 3. Do not place anything on top of the turntable cover, especially while playing a record.
Page 14
1. Turn the switch to your record type, 33 or 45. 2. Put your Bluetooth speaker in pairing mode by making sure no other device is connected via Bluetooth.. Note: Make sure that Bluetooth is off on any devices in the vicinity that will automatically connect to your speaker.
3. Toggle the PRE-AMP ON/OFF switch to select the output mode. Connected device Switch position Device with PHONO input Device without PHONE input Note: 1. Improper setting of PRE-AMP ON/OFF switch will lead to no sound or explosive sound. Adjust the volume of the external speaker when using the RCA cable. Replacing the stylus The stylus should last about 300 hours under normal use.
Page 16
CAUTIONS: 1. Do not remove or bend the stylus. 2. Do not touch the needle to avoid injury your hand. 3. Keep out of reach of children. Adjusting the anti-skating control When a record is playing, a small inward force (might cause skating) pull the tone arm towards the center of the record.
Specification: GENERAL Power Requirements ..……………………………………. AC 230 V ~ 50 Hz Power Consumption……………………………………….. 5 W Dimensions (W x H x D)…………………………………… 43.9cm x 35.5cm x 13.4cm (approx.) BLUETOOTH TRANSMIT Bluetooth Version…………………………………………… Bluetooth V4.2 Bluetooth Profiles…………………………………………… A2DP, AVRCP Bluetooth Frequency range…………………………….. 2.402GHz-2.480GHz Operating Distance………………………………………….
DECLARATION OF CONFORMITY Mitchell Acoustics as manufacturer certifies that the following designated product Mitchell Acoustics uStream TT1 Vinyl Turntable Is in full conformity with ErP Directive 2009/125/EC Commission Regulation: (EC) No. 1275/2008 (EU) No. 801/2013 Test Standard EN 50564:2011 RoHS directive 2011/65/EU and the amendment directive (EU) 2015/863 ETSI EN 301 489-1 V2.2.3 (2019-11) (Draft) ETSI EN 301 489-17 V3.2.4 (2020-09),...
Troubleshooting guide In case of trouble with the unit, please look through below and see if you can solve the problem by yourself before calling your dealer. Problem Solution My turntable doesn’t turn on • Make sure that the power cord is connected to your turntable and a working power outlet.
