  • Page 1 User’s manual Jogger...
  • Page 2 The child should be clear of moving parts while making adjustments. • IMPORTANT - DANGER: It is important that care is taken to ensure that children are kept clear of the Jogger when folding or unfolding. Pinch points and scissoring actions are unavoidable during these operations •...
  • Page 3 1. FRAME Unpack Jogger from box and set wheels aside. Push foot plate of Jogger away from handle by pushing curved crossbar up and out. Audible click will be heard when Jogger frame is completely unfolded. Flip Jogger to upright position.

  • Page 4: Front Wheel In-Line Locking

    2. FRONT WHEEL To install front wheel, lay jogger on it’s back so handle and rear axles are touching the floor. Engage safety lock on both sides of the fork. Check before each use. NOTE: Safety Lock both sides of fork.

  • Page 5: Rear Wheel

    3. REAR WHEEL To install, gently slide the rear wheel’s axle into the frames supporting axle hole until you hear it click onto place. To remove, simply push down the spring lock tab while pulling out on the wheel. 3A. RAER WHEEL PARKING BREAKE To apply the parking brake: Press down on the foot bar..

  • Page 6: Reclining Seat

    Unthread harness straps from fleece lining. Adjust shoulder straps to desired height using the loops on the seat back. Slide the plastic guide up and down to adjust strap length. Once fitting is complete reassemble the fleece lining. Clip shoulder strap buckle to chest harness. To adjust the length of the center strap, move the plastic guide up and down.

  • Page 7: Removing Seat Fabric

    6. REMOVING SEAT FABRIC Using a phillips head screw driver unscrew hardware from the frame. Unsnap fasteners on both sides of jogger. Unlock seat strap from frame, buckle is suspended across the back of the jogger. Unloop Velcro Strap through the D-ring, under neath the foot well.

  • Page 8: Handle Height

    8. CANOPY Fasten the canopy to the portion of the upper frame that is not covered by fabric. Small holes in the crest of the frame tubing accept the canopy. Be sure there are NO obstructions (fabric or brake lines) between the canopy clip and the frame.
  • Page 9 Squeeze mechanism located below the handle. (Mechanism located on Both Sides) Fold jogger back. Secure Jogger in folded position with recline strap. 11. ATTENDANT STRAP Make sure safety wrist strap is secured properly around your wrist whenever your child is in the jogger.
  • Page 10 The Seat Liner Straps will go through the lowest slots. Clip the straps for both the Seat & Back Liners to each other on the back side of the jogger and tighten until secure. NOTE: The Jogger Chest Harness should lay over the top of the Back Liner for correct positioning.
  • Page 11 Use the strap provided with the Optional Head Rest to secure it to the Jogger. Thread the straps through the slots on the Jogger. Clip the straps together on the back side of the Jogger and tighten to secure it.

  • Page 12: Limited Warranty

    LIMITED WARRANTY Bergeron by Design warrants to the original retail purchaser of the Special Tomato® product, that if any part or component proves defective in material or workmanship within two years of the purchase date, the defective part will be repaired or replaced (at Bergeron by Design’s discretion) free of charge.
  • Page 13 IMPORTANT- WARRANTY WILL BE VOID IF DEFACED OR REMOVED Your stroller is guaranteed to be free from any manufacturing defects for a period of 2 years from the date of purchase under normal use and provided it is used in compliance with the operating instructions. This warranty extends only to the original retail purchaser and is only valid when supplied with proof of purchase.
