- Page 1 AUTOMATIC FRUNK MODEL X INSTALLATION GUIDE V. MX FNK20-MKIV About this guide...
-
Page 2: Table Of Contents
Table of contents Specifications Technical data of the lifting arms Technical data of the engine for automatic frunking Preparations List of tools needed for the installation List about the scope of delivery Installation guide Remove cladding Replace lifting arms Modify clamping unit Wiring System test and system settings Checklist... - Page 3 In any case, the safety instructions marked "��CAUTION:..." in these instructions must be observed. In case of disregard of the safety instructions and resulting damages to the AMPTech components or even vehicle parts, the warranty claim as well as any liability for damages or consequential damages expires due to own fault (see GTC's on www.amptech.store/agb/, V.
-
Page 4: Specifications
Specifications Below you will find more detailed information about the supplied components. Technical data of the lifting arms Lifting arms Maximum lift arm length 360 mm Minimum lifting arm length 112 mm Highest diameter 32 mm Maximum operating force 700 N Operating voltage 12 V DC voltage Operating current... -
Page 5: Preparations
Transmission ratio 26,4 Acoustic emission ≤ 60 dB Preparations To ensure that the installation can be carried out quickly, tools required for the installation should be provided before starting. The required tools are listed below. List of tools needed for the installation Tool list Position Designation... -
Page 6: List About The Scope Of Delivery
Preparations Please check the scope of delivery of the order before starting the installation. List about the scope of delivery Scope of delivery Position Designation 2 lifting arms Softclose motor with emergency release tab Control unit Cable tie Power adapter plug with fuse 2 cable harnesses 2 adapter plates with ball joints 2 screws (hexagon socket) -
Page 7: Installation Guide
Installation guide Before proceeding to the removal of the inner lining, it is advisable to expose storage areas for the parts removed in the course of the installation. In addition, it is helpful to keep the clamps and screws that are removed sorted. -
Page 8: Replace Lifting Arms
Installation guide Figure 2: Screwing of the plastic tray ● Lift out the plastic tray Replace lifting arms ● Remove the lift arms by levering the locking cotter pin with the slotted screwdriver and pulling on the respective end of the lift arm by hand until the lift arm releases at the attachment point (Figure 3) Figure 3: Loosening the lifting arms ●... - Page 9 Installation guide Figure 4: Lower attachment point ● Use the adapter plates included in the scope of delivery and screw them to the lower attachment points of the lift arms using the screws included in the scope of delivery. The adapter plates are marked with "L"...
-
Page 10: Modify Clamping Unit
Installation guide Loosen one lift arm and attach the new lift arm to �� Tip the lower attachment point first. After the second lift arm has been loosened, press both lift arms against the joint at the upper attachment point so that the lift arms engage. - Page 11 Installation guide Figure 7: Pin clamps ● Carefully remove the front plastic cover by hand ● Disconnect the plug on the left side of the clamping unit in the direction of travel. To do this, hold down the safety catch and pull out the plug at the same time (Figure 8) ●...
- Page 12 Installation guide ● There is a nut and locknut at the motor end of the Bowden cable. Tighten these two nuts so that no coils are visible at the end of the motor. ● There is also a nut and a lock nut at the bowden cable head end. Tighten the nuts so that 4 turns are visible Figure 9: Attaching the hook-in device ��...
-
Page 13: Wiring
Installation guide ● Connect the brown colored plug from the main harness to the softclose motor ● Thread the bowden cable of the motor unit to the left side of the front trunk in the direction of travel and attach the motor to a flat surface with 3M double-sided tape ��... - Page 14 Installation guide ● Two cables lead from the catch hook of the clamping unit to its motor. Follow the cable and disconnect the motor plug. The motor connector is located near the red-colored emergency release tabs of the frunk. Connect the plug to the blue-black Y-connector of the cable harness. Connect the other end of the Y connector to the connector on the motor.
- Page 15 Installation guide Abbildung 13: Stromversorgung ��ATTENTION Be careful not to cause a short circuit (e.g. by tools or other current-conducting materials)! ● The ground is tapped from the negative terminal of the battery using the free forked cable lug on the main harness ●...
- Page 16 Installation guide ● Connect the pushbutton and the cable that you previously disconnected from the pushbutton to the free Y-connector �� Tip You can glue a piece of alubutyl over the acoustic signal generator to reduce noise. Before you start dismantling the removed components, you should first initialize the system and perform a system test.
-
Page 17: System Test And System Settings
System test and system settings Before you start dismantling, a function check with subsequent system initialization should be performed. For the function check, manually lock the lock on the locking unit using a plastic mounting lever or a screwdriver. Then connect the push button plug or use your keyfob to unlock the lock. The function check is completed. - Page 18 System test and system settings also whether the closing lug on the front hood meets the lock during closing. The clamping unit can be adjusted horizontally so that the closing lug hits the lock vertically. In addition, the position of the front hood latch can be checked and, if necessary, adjusted accordingly by means of spacers.
-
Page 19: Checklist
Checklist The following checklist will help you to check all the steps again in a quick run-through and to improve them if necessary. Assembly of the components: ● Soft Close motor and control unit are securely fastened with 3M adhesive tape and, if necessary, cable ties ●... - Page 20 Checkliste Excess cable lengths and exposed cables are tied into cable bundles with cable ties and attached to the sides (preferably OEM cables) of the front trunk ● The plugs of the clamping unit motor and the signal of the clamping unit are connected ●...
-
Page 21: Deconstruction
Deconstruction After you have performed the system test and made your desired settings, you can start dismantling the components. ● The control unit can be attached to the left side of the battery in the direction of travel using double-sided 3M adhesive tape ●...
