- Page 1 KP4.6 Installation & User Guide...
- Page 2 The many different options and features of your new keypad will be a source of pleasure for you for many years to come. The KP4.6 can be used with any A-BUS* equipment or the Jamo AVD4.6 system which is a distributed, multi-room home entertainment system capable of delivering high quality audio and video** to multi- ple rooms and locations in your home.
-
Page 3: Table Of Contents
Content Important Pre-installation Installation 8-10 Operation 11-13 Specifications Limited warranty... -
Page 4: Important
Important When installing the KP4.6 in a J box all knock outs must be re- moved to provide ventilation. Do not install the KP4.6 in a double gang box that also has elec- trical installation in it. If installed next to electrical installation either a barrier-box or two single gang boxes must be used. -
Page 5: Pre-Installation
Source equipment KP4.6 Fig. 1 The KP4.6 connects to an A-BUS output with a Cat5e ca- ble. Standard speaker wires connects the KP4.6 to a pair of speakers. Speakers from 4 to 8 ohm with a sensitivity of min. 88dB should be used. All Jamo speakers match... - Page 6 Pre-installation Pin Color Code white/green green white/orange blue white/blue orange white/brown brown Fig. 2 The Cat5e should be terminated in the RJ45 plug as per T-568A standard. Fig. 2.
- Page 7 Jamo A-BUS mode. The A-BUS position is for use with other A-BUS equipment. The Jamo position is for use with Jamo AM4.6 and gives extra functions. The switch MUST be set in the correct position, or the KP4.6 will not work.
-
Page 8: Installation
Installation Screened audio cable KP4.6 Subwoofer Fig. 4 The KP4.6 has a preamp output for external equipment (powered subwoofer or amplifier). Use a screened audio cable for connection. - Page 9 Installation Cat5e Speakers Fig. 5 Connect the Cat5e cable to the screw terminals with a phillips screwdriver . Fig. 4. Next connect the speaker wires to the screw terminals with a phillips screwdriver. Fig. 4. Make sure to follow the color coding for both Cat5e ca- ble and speaker wires...
- Page 10 Installation Screw locations Fig. 6 Install the KP4.6 in a single-gang 2” or deeper J box or in a P ring with the 2 supplied screws. Fig. 5. Install any decora style faceplate on to the KP4.6 module (not included).
-
Page 11: Operation
Operation Volume adjustment The LED blinks orange when adjusting volume up and down. When reaching full volume the LED blinks red. When reaching minimum volume (Mute) the LED blinks green. Sound adjustments To enter Sound Adjustments push and hold Sound (4 sec.) to reach the desired function. - Page 12 Operation Select Standby Sound Down Status LED IR window...
- Page 13 Keypad in mute: Blinks green Adjusting volume or sound: Blinks or- ange End points on volume or sound: Blinks Change source: Blinks twice for each push Sound adjustment functions: Blinks red *Only in Jamo enhanced A-BUS mode. See page 7.
-
Page 14: Specifications
Specifications Input impedance 45k ohm Frequency response 20Hz - 20kHz +/- 1dB <0.2% @ 1W, 20Hz - 20kHz S/N ratio > 80dB ‘A’ weighted Volume control range - 80dB, 32 steps Bass control range +/- 16dB, 2dB steps Treble control range +/- 16dB, 2dB steps Balance control range +/- 40dB, 9 steps each way... -
Page 15: Limited Warranty
Limited Warranty The warranty period will come into force as from the purchase date stated on the invoice. The warranty will apply for 2 years. In case of warranty inquiries, please contact your dealer. In case of request for service under warranty, enclose the origi- nal receipt. - Page 16 www.jamo.com...
