- Page 1 CAT LITTER BOX ENCLOSURE Installation video Email: service@furpezoo.com...
- Page 2 Free user support Not sure how to get your Furpezoo product to work properly? —Contact our world-class, friendly support team for quick solutions.
- Page 3 CATS LITTER BOX ENCLOSURE --- WITH DRAWER INSTALLATION MANUAL ALL ACCESSORIES ×1 ×1 ×2 ×1 ×1 ×1 ×1 ×1 ×1 ×1 ×1 ×1...
- Page 4 Hardware list ×1 ×1 ×12 ×4 ×6 ×4 ×2 ×1 ×1 ×1 ×2 ×10 ×2 ×1 ×4...
- Page 6 Assembly instructions P1 SPEP 01 ×2 ×1 ×4 Screw ⑬ to the panel (A) as below shown Screw ⑨ to the panel (D) as below shown...
- Page 7 Assembly instructions P2 SPEP 02 The upward edge of Panel (A) & (D)& (E) have pre-drilleds. ×8 ×2 ×1 ×1 Connect the Panel (A) & (D)& (E) with Screw ③ as below shown Connect the Panel (A) & (B) with Screw ④ as below shown Panel (D) with the accessories side facing inward...
- Page 8 Assembly instructions P3 SPEP 03 ×10 ⑫ Install Panel (F) with Screw below shown SPEP 04 ×4 ×1 Install the Panel (C) with Screw ③ as below shown...
- Page 9 Assembly instructions P4 SPEP 05 ×2 ×1 ×1 ×1 ×2 Screw ⑩ & ⑧ & ⑦ & ⑪ to the panel (G) as below shown First connect Panel (G) and Panel (E) with the ⑪ screw. Push Panel (G) inward by pressing the ⑪...
- Page 10 Assembly instructions P5 SPEP 06 ×4 ×4 Screw ⑤ to the panel (K) as below shown Mounting Panel (I) and (H) with Screw ⑥ as below shown SPEP 07 Insert the panel (L) SPEP 08 ×4 ×1 Mounting Panel (J) with Screw③ as below shown...
- Page 11 Assembly instructions P6 SPEP 09 Put the drawer into the cat cabinet and you will get a perfect cat litter box. -10-...
