- Page 1 SYNCOLN 13100...
- Page 2 COMPACT SYSTEM GAS DETECTOR & SOLENOID VALVE...
-
Page 3: Table Of Contents
CONTENT; 1 About the Device: ..……..….……………………………………………..……………………... 4 1.1.1 Maintenance : …………………………………………………………………………………….. 4 1.1.2 Assembly: ….…….…………………………………………………………………….……...… 4/5 1.1.3 Gas Detector and Connecting to output elements: ……………………………………..5 1.1.4 Gas Detector and Connecting to Solenoid Valve: ……………...………………………... 5/6 1.1.5 Connection Table and Alerts: …...…………………………………….……………………… 6 1.1.6 Instruction: …………………………………….…………………………..…….……………….7 1.1.7 Gas Detector Technical Specifications: ……………………………..………….……...……8 1.1.8 Solenoid Valve Technical Specifications: ……………………………….…….….…………9... -
Page 4: About The Device
COMPACT SYSTEM 1. About Device NYS in weather that can detect explosive gases (natural gas and LPG) is a device. This type of dangerous gases are detected, the gas detector NYS buzzer (tone) and audio, with LED allows the light warning. The green LED lights, and stand-alone device, as long as electricity is fed to the burning of a dangerous situation as long as there is no middle. -
Page 5: Gas Detector And Connecting To Output Elements
Voltage of 220 VAC with standard city after mounting NYS gas detector chips are ready to work by attaching. NYS 'will be mounted on the need to consider are the issues. These points can be specified as follows: In LPG (tubes) are used, the device must be mounted near the place, and from the height should not exceed 30 cm and absolutely. -
Page 6: Connection Table And Alerts
COMPACT SYSTEM connected to a dangerous situation if the valve is engaged in NYS ' in addition solenoid and gas transmission cut off. This mechanism gives you a security effortless and flawless. To connect the gas valve solenoid valve to NYS detector Figure 2, follow these instructions to the benefit. The first phase of the network flow (R) end of the BLACK cable to connect the output cable NYS ' in contact. -
Page 7: Instruction
1.1.6 After the device needs to be done to give the alarm; All weather materials, including all the naked flame should be extinguished. All gas appliances should be shut down. Gas detectors, including the not open any electrical equipment and should not be closed. ... -
Page 8: Gas Detector Technical Specifications
COMPACT SYSTEM 1.1.7 TECNICAL SPECIFICATIONS / GAS DEDEKTÖR ; Power Consumption: 3W (maximum) Power Source: 220V +%10 (50-60 Hz) Buzzer 85 dB (minimum) Selenoid Valve Outlet: 250 VA (maximum) SENSOR Sensor: Warm up Period: 45 seconds Sensor Measurement/ EN 50194 Detection Range: (European Standard) Life of the Sensor:... -
Page 9: Solenoid Valve Technical Specifications
1.1.8 SOLENOİD VALVE / MANUAL RESET VALVES Technical Specifications; • Threaded Mounting : DN15, DN20, DN25 • Max. İnlet Pressure : 500 mbar • Working Voltage : 230 V AC/50 Hz - 12 V DC/ 18W - 24V • Working Temperature: -15 °C / 60 °C •... -
Page 10: Gaz Detector's With 2 Cable Output Installation To A Solenoid Valve
COMPACT SYSTEM 1.1.9 Gas Detector’s with 2 cable output installation to a Solenoid Valve: • POWER Connection: First join brown cables together and then blue cable together. On the brown cable connect it to positive source and the blue cable to neutral soruce. •... -
Page 11: Warranty Conditions
1.1.10 WARRANTY CONDITIONS 1.Warranty period starts from the date of delivery of goods, and two (2) years. 2. Goods, including all parts of our entire company is under warranty. 3. In the event of malfunction within the warranty period the goods in repair warranty period will be added to the elapsed time. -
Page 12: Qualified Service
COMPACT SYSTEM THANK YOU… GAS DETECTOR & SOLENOID VALVE...
