High-T ech • Made in Switzerland
The µSERLED is a LED Panel used on various MPL network products. It converts the serial stream into signals
to control 16 dual color LEDs. Additional 2 Buttons are implemented which may be used as Reset and Default
Button.
This Manual is written for Users of an MPL Network Device as Open Frame, whereas the µSERLED is
optional.
Features:
●
Deserialization of 16 Dual color LEDs.
●
Up to 8 different mappings selectable with DIP
●
switch
Two push-Buttons
●
2022 by MPL AG
User Manual
µSERLED User Manual
Small footprint (24 x 56 x 8.6mm)
●
7 Pin Connector.
●
1
µSERLED
MEH-10203-001 Rev. C
Advertisement
Table of Contents
Related Manuals for MPL mSERLED
Summary of Contents for MPL mSERLED
- Page 1 µSERLED User Manual The µSERLED is a LED Panel used on various MPL network products. It converts the serial stream into signals to control 16 dual color LEDs. Additional 2 Buttons are implemented which may be used as Reset and Default Button.
-
Page 2: Table Of Contents
4.3.1 µMAXBES-A10OH (10 Port Open Frame µMAXBES)..........15 5 CONNECTORS......................16 5.1 J1 Factory use only......................16 5.2 J7 LED Panel Connector....................16 6 COPYRIGHT........................20 7 DISCLAIMER....................... 20 8 TRADEMARKS......................20 9 SUPPORT........................20 2022 by MPL AG MEH-10203-001 Rev. C... - Page 3 µSERLED User Manual High-T ech • Made in Switzerland 9.1 CONTACT MPL AG......................20 2022 by MPL AG MEH-10203-001 Rev. C...
- Page 4 µSERLED User Manual High-T ech • Made in Switzerland TABLE OF FIGURES Figure 1: µSERLED Top view Dimensions......................10 Figure 2: µSERLED Side view Dimensions......................10 Figure 3: µSERLED Parts Location........................11 2022 by MPL AG MEH-10203-001 Rev. C...
-
Page 5: Introduction
1.4 EQUIPMENT SAFETY Great care is taken by MPL AG that all its products are thoroughly and rigorously tested before leaving the factory to ensure that they are fully operational and conform to specification. However, no matter how reliable a product, there is always the remote possibility that a defect may occur. -
Page 6: Manual Revisions
• µSERLED-1 Rev. D or any Revision with TU MEW-10226-002-A 1.5.2 REVISION HISTORY Manual Date Description Revisions 2021-08-25 Initial release of this document. Moved from µMAGBES & µGUARD Manual 2022-04-13 Added configuration for µMAGBES-A8OH 2022-10-24 Added configuration for µMAGBES-A14OH (master & slave) 2022 by MPL AG MEH-10203-001 Rev. C... -
Page 7: Related Documentation
The following documents are related to this manual. For detailed Information about a specific xxx feature or setting please refer to this additional manuals. Reference Description Available from µMAGBES User Manual MPL AG: www.mpl.ch µGUARD User Manual MPL AG: www.mpl.ch µMAXBES User Manual MPL AG: www.mpl.ch 2022 by MPL AG MEH-10203-001 Rev. C... -
Page 8: Standards Compliance
1.7.4 TYPE APPROVAL EN 60945 Protected Equipment (Maritime navigation and radiocommunication equipment and systems - • General requirements - Methods of testing and required test results) E10 (Test Specification for Type Approval) • 2022 by MPL AG MEH-10203-001 Rev. C... -
Page 9: Ordering Information
The table below gives you an overview of the different xxx variants and its features. Product Name Product Features µSERLED-1 • µSERLED with 16 dual Color LEDs and 2 Push Button. Without Lightpipes • 2022 by MPL AG MEH-10203-001 Rev. C... -
Page 10: Dimensions
Figure 1: µSERLED Top view Dimensions 2.2 Side view Ø2.5 Ø3.0 Lightpipe, only one of 16 pcs shown Figure 2: µSERLED Side view Dimensions Recommended Panel Holes for Switches Ø 2.6mm for LEDs Ø 3.1mm 2022 by MPL AG MEH-10203-001 Rev. C... -
Page 11: Parts Location
4.1 µMAGBES 4.1.1 µMAGBES-A10OH / µMAGBES-A10OR (10 Port Open Frame µMAGBES) Configuration Switches: S4-1 S4-2 S3-1 S3-2 Buttons: S1: Reset S2: Default LED Mapping: LED with empty fields are not used (no Lightpipe installed) 2022 by MPL AG MEH-10203-001 Rev. C... -
Page 12: Μmagbes-X19Oh / Μmagbes-X19Or (19 Port Open Frame Μmagbes)
LED with empty fields are not used (no Lightpipe installed) 4.1.3 µMAGBES-x8OH Configuration Switches: S4-1 S4-2 S3-1 S3-2 Buttons: S1: Reset S2: Default LED Mapping: LED with empty fields are not used (no Lightpipe installed) 2022 by MPL AG MEH-10203-001 Rev. C... -
Page 13: Μmagbes-X14Oh
LED with empty fields are not used (no Lightpipe installed) 4.1.4.2 Slave µMAGBES-x14OH Configuration Switches: S4-1 S4-2 S3-1 S3-2 Buttons: S1: Not used S2: Not used LED Mapping: LED with empty fields are not used (no Lightpipe installed) 2022 by MPL AG MEH-10203-001 Rev. C... -
Page 14: Μguard
LED with empty fields are not used (no Lightpipe installed) 4.2.2.2 Slave µMAGBES Configuration Switches: S4-1 S4-2 S3-1 S3-2 Buttons: S1: Not used S2: Not used LED Mapping: LED with empty fields are not used (no Lightpipe installed) 2022 by MPL AG MEH-10203-001 Rev. C... -
Page 15: Μmaxbes
High-T ech • Made in Switzerland 4.3 µMAXBES 4.3.1 µMAXBES-A10OH (10 Port Open Frame µMAXBES) Configuration Switches: S4-1 S4-2 S3-1 S3-2 Buttons: S1: Reset S2: Default LED Mapping: LED with empty fields are not used (no Lightpipe installed) 2022 by MPL AG MEH-10203-001 Rev. C... -
Page 16: Connectors
5.1 J1 Factory use only. Do not connect anything to this connector. 5.2 J7 LED Panel Connector Connect this to the external LED Panel Connector of the MPL Network Product. The Connector J7 is a 7 pin 1mm shrouded with positive lock. Pin no. - Page 17 µSERLED User Manual High-T ech • Made in Switzerland This page intentionally left blank. 2022 by MPL AG MEH-10203-001 Rev. C...
- Page 18 µSERLED User Manual High-T ech • Made in Switzerland This page intentionally left blank. 2022 by MPL AG MEH-10203-001 Rev. C...
- Page 19 µSERLED User Manual High-T ech • Made in Switzerland This page intentionally left blank. 2022 by MPL AG MEH-10203-001 Rev. C...
-
Page 20: Copyright
Brand or product names are trademarks and registered trademarks of their respective holders. 9 SUPPORT 9.1 CONTACT MPL AG In case of general information questions please feel free to contact us at our homepage ( www.mpl.ch) or per email (info@mpl.ch). In case of sales information questions please send an email to sales@mpl.ch.
