M-22 3 BAG MIXING STATION
OPERATING MANUAL
TO PREVENT SERIOUS INJURY DO NOT OPERATE SAW WITHOUTPROPER TRAINING AND.
Copyright 2020, by U.S.SAWS . All rights reserved. This work may not be reproduced or disseminated in whole or in part by any
Notice of Copyright Protection
UNDERSTANDING OF THE OWNERS MANUAL
WHEN OPERATING THIS MACHINE
means without the prior written permission of U.S.SAWS
Surface Prep
ALWAYS WEAR SAFETY APPROVED
Division
HEARING PROTECTION
P: 877-817- 6687 F: 813-621-7125
Visit us at www.ussaws.com
sales@ussaws.com
U.S. English
02-22-2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-22 and is the answer not in the manual?

Questions and answers

Related Manuals for U.S.SAWS M-22

Summary of Contents for U.S.SAWS M-22

  • Page 1 Notice of Copyright Protection UNDERSTANDING OF THE OWNERS MANUAL Copyright 2020, by U.S.SAWS . All rights reserved. This work may not be reproduced or disseminated in whole or in part by any WHEN OPERATING THIS MACHINE means without the prior written permission of U.S.SAWS...

  • Page 2: Introduction And Specifications

    ALWAYS WEAR SAFETY APPROVED 300-650 rpm Empty weight 90 lbs The M-22 3 Bag Mixing Station is a compact, robust mixing station with HEARING PROTECTION Container size 22 gallons good balance when pouring the self levelling compound, even with larger EYE OR FACE PROTECTION mixing volumes.

  • Page 3: Symbols And Decals

    For Safe Operation explanations do not by themselves eliminate any danger. The instructions You must be qualified for safe operation of the U.S.SAWS M-22 3 Bag or warnings they give are not substitutes for proper accident prevention Mixing Station machine. You must clearly understand the written instruc- measures.

  • Page 4: Safety Instructions

    U.S. SAWS representative or from an autho- areas where exhaust fumes could accumulate without wearing appropriate rized distributor for U.S.SAWS. respiratory protection. Consult your employer and OSHA regarding use of appropriate respirator for dangerous carbon monoxide gases.

  • Page 5: Dust Warning

    S A F E T Y I N S T R U C T I O N S 4.20 REMOVE ADJUSTING TOOLS. Form a habit of checking to see that tools such as adjusting wrenches are removed from the machine and properly stored before starting the engine. 4.21 STAY ALERT.

  • Page 6: Product Information

    P R O D U C T I N F O R M AT I O N 5. PRODUCT INFORMATION 5.4 CONTROL ELEMENTS 5.1 SPECIFICATIONS 5.2 APPLICATION Compact, robust mixing station with good balance when pouring the self levelling compound, even with larger mixing volumes. *Suitable mixing materials Mainly for cement self-leveling, and materials with good liquidity.

  • Page 7: Wheel Mounting

    P R O D U C T I N F O R M AT I O N 6. PREPARATION STEP 1 WHEEL MOUNTING As shown in FIG 1, 2 x wheels with brake at th back 2 x wheels with no brake at the front Use locking nuts to mount and fix the wheels STEP 4 As shown in figure IV...

  • Page 8: Operation

    O P E R AT I O N 7. OPERATION MATERIAL 7.1 INSTRUCTIONS FOR SAFE USE • Follow the instructions and warnings for the material to be mixed. Safe work with the instrument is only possible after you read thoroughly Material to be mixed can be harmful.
  • Page 9 O P E R AT I O N 7.2 STARTING OPERATION AND USE 7.3 ELECTRONIC MOTOR CONTROL Improper use may damage the device. 7.3.1 Starting current limiting: Observe therefore these instructions: The electronically controlled smooth start takes care that the machine •...
  • Page 10 O P E R AT I O N 7.5 POUR OUT MIXTURE 7.4 MIXING PROCESS BEFORE MIXING PROCESS DISCONNECT THE PLUG BEFORE POURING OUT • Lock the lifting arm firmly on the chassis. • Secure the transport rollers using the parking brake. Lock the cable on the cover in the cable holder.
  • Page 11 O P E R AT I O N 8 TRANSPORT The device can be moved effortlessly thanks to the four stable transport rollers. To prevent unintentional rolling away, two castors can be secured with a brake. 9 STORAGE The unit should be stored in a dry place where it is protected against freezing. 10 DISPOSAL Do not open worn out machines and return to the collection facilities for recycling.

  • Page 12: Warranty And Service

    Warranty This document is to be used as a guide in determining warranty policies and procedures for U.S.SAWS and its U.S.SAWS products. It is to be used in determining whether a warranty is justified and as a procedural guide in completing a U.S.SAWS warranty claim form.
  • Page 13 FILL OUT THE ATTACHED CARD COMPLETELY AND ACCURATELY. WARRANTY REGISTRATION CARD IMPORTANT! To ensure that your U.S.SAWS machine is covered under warranty, please fill in the following information and mail or fax it to U.S.SAWS, 8004B E. Broadway Ave. Tampa, FL 33619, Fax No. (813) 621-7125...
