- Page 1 C4 Cutting head Users Manual By Au3tech Research Pty Ltd...
-
Page 2: Introduction
By Au3tech Research Pty Ltd C4 Cutting head Users Manual Introduction Overview This document mainly describes the appearance, application scenarios, installation, debugging, operation, maintenance, etc of C4 fiber laser process head. Reader Objects This document mainly is applicable to the following personnel: •... -
Page 3: Table Of Contents
1.2 Products feature ......................... 5 1.3 Cutting head parameters ......................5 2 Structure Specifications ......................6 2.1 C4 Fiber laser cutting head brief ....................6 2.1.1 C4 flatbed cutting head ......................6 2.1.2 C4 3D cutting head ......................... 7 2.1.3 C4 fine cutting head ........................ 8 3 Installations .......................... -
Page 4: Overview
Overview 1.1 Product Overview C4 series flat-bed cutting head is a kind of fiber laser cutting head suitable for median to high power. It can cut stainless steel of maximum thickness 7 mm and carbon steel of maximum thickness 15 mm with best cutting quality. It features with water cooling and draw design for protective windows. -
Page 5: Products Feature
By Au3tech Research Pty Ltd C4 Cutting head Users Manual 1.2 Product Features Support multiple kinds of focal length (125mm, 150mm) Support multiple kinds of fire-optic link (QBH, QD) Focus module design with high-precision Centering control module design with precision Protection lens box can be quickly disassembled Optimized smooth gas circuit design;... -
Page 6: Structure Specifications
By Au3tech Research Pty Ltd C4 Cutting head Users Manual Structure Specifications 2.1 C4 Fiber laser cutting head brief C4 fiber laser cutting are designed for flatbed cutting, 3D cutting and fine cutting. 2.1.1 C4 flatbed cutting head Copyright © AU3TECH RESEARCH PTY LTD... -
Page 7: C4 3D Cutting Head
C4 Cutting head Users Manual 2.1.2 C4 3D cutting head C4 3D series is designed for 3D cutting. It comes with longer focus length than normal flat-bed cutting heads. In term of larger aperture and longer focus length, the depth of focus can achieve longer than usual, so the cutting curve can be better quality. -
Page 8: C4 Fine Cutting Head
C4 Cutting head Users Manual 2.1.3 C4 fine cutting head C4-FC series is designed for fine cutting. It comes with shorter focus length than normal flat-bed cutting heads or 3D cutting heads. In term of larger aperture and short focus length, the focus spot can achieve smaller and it is better for thin metal cutting. -
Page 9: Installations
By Au3tech Research Pty Ltd C4 Cutting head Users Manual Installations 3.1 Pre-installation preparation Before installing C4 cutting head, please ensure fiber-optic chuck is sealed and during installation, never remove sealing. Table 3-1 List of Tool Preparation Name of Tool... -
Page 10: C4-Qbh100-F125 And C4-Qbh100-F150
By Au3tech Research Pty Ltd C4 Cutting head Users Manual 3.2.1 C4-QBH100-F125 and C4-QBH100-F150 (Contact us for more details) Copyright © AU3TECH RESEARCH PTY LTD... -
Page 11: C4-3D-Qbh100-F125
By Au3tech Research Pty Ltd C4 Cutting head Users Manual 3.2.2 C4-3D-QBH100-F125 (Contact us for more details) Copyright © AU3TECH RESEARCH PTY LTD... -
Page 12: C4-Fc-Qbh100-F50
By Au3tech Research Pty Ltd C4 Cutting head Users Manual 3.2.3 C4-FC-QBH100-F50 (Contact us for more details) Copyright © AU3TECH RESEARCH PTY LTD... - Page 13 C4 Cutting head Users Manual 3.3 Tube connection of C4 Process Head C4 laser process head adopts the design of optical lens surrounded by water-cooling, which can reduce the chance of lens damage by heat effectively and restrain the deformation of lens caused by heat effect in the long operation.
-
Page 14: Qbh Connection
By Au3tech Research Pty Ltd C4 Cutting head Users Manual 3.4 QBH Connection Operation sequence: 1. Take down the plastic protective cap at the top of link block. 2. Align the small hole on the QBH to the small hole on the link block, red dot to red dot, insert QBH until the end. -
Page 15: Focus Adjustments
Focus Adjustments 4.1 Focus centering The centering of all C4 fiber cutting head series are finished by the two adjusting screws just as shown in the following figure. When centering, No. 2.5 socket head wrench is used. Clockwise adjustment makes focus move to the direction of backboard and counterclockwise adjustment makes focus move to the opposite direction. -
Page 16: Z Position Adjustments
By Au3tech Research Pty Ltd C4 Cutting head Users Manual 4.2 Z position adjustments The Z-axis position adjustment of all C5 fiber cutting head series are finished by the hand wheel unit just as shown in the following figure. Clockwise adjustment of hand wheel makes focus extend and counterclockwise adjustment of hand wheel makes focus shorten. -
Page 17: Operation &Maintenance
By Au3tech Research Pty Ltd C4 Cutting head Users Manual Operation &Maintenance 5.1 Maintenance of Protective windows Protective window is at the bottom of focusing module. When lens sticks to impurities or foreign matters, they cause damage to lens. Therefore, regular maintenance of window is needed. It is suggested to clean it once a week. - Page 18 By Au3tech Research Pty Ltd C4 Cutting head Users Manual 2. Gently squeeze the edge of the windows with right thumb from the top down (Note: be sure to squeeze the edge, since squeezing the center cannot make the windows fall off), place the index finger of right hand on the opposite direction of thumb so as to protect the lens from slipping.
-
Page 19: Collimator And Focus Lens Maintain
2. Refill into the bottom of lens module, and clockwise tighten the set screw by hand 5.2 Collimator and focus lens maintain C4 fiber laser process head has excellent leak tightness, so regular inspection of its population is unnecessary. But if the machine tool is frequently moved, the cleanness of the lens should be inspected in the dust-free room before pulling in or pulling out fiber and re-installation All collimators and focus lens come in holders, so it is much easier to get it replaced. - Page 20 By Au3tech Research Pty Ltd C4 Cutting head Users Manual After finishing cleaning the lens by the steps of cleaning protective lens, wear dust-proof gloves/finger stall, back-step by the steps of taking out lens and install the focusing lens well. Be sure the plane of the lens adown during installation.
-
Page 21: Technical Indexes
By Au3tech Research Pty Ltd C4 Cutting head Users Manual Technical Indexes Table6-1 Technical Indexes Parameter Class Name Descriptions Operating Cutting head：-10℃～+55℃ temperature Storage -20℃～+70℃(non-condensation) Environmental temperature conditions Relative humidity 5％RH～95％RH, Without condensation Atmosphere 70kPa～106kPa pressure Without conductive dust and corrosive gas, as well as...
