Rosko RO-GCE Series Installation Manual

Electric countertop griddle
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RO-GCE
Electric Countertop Griddle
INSTALLATION GUIDE
EN
Operation, Maintenance, and Service Parts
RO-GCE-18-1
RO-GCE-18-2
955 Lachance Street
Quebec, QC G1P 2H3
Canada
RO-GCE-24-1
RO-GCE-24-2
RO-GCE-24-1-CP
RO-GCE-24-2-CP
1-866-901-5624
www.rosko-julien.ca
RO-GCE-36-1
RO-GCE-36-2
RO-GCE-36-1-CP
RO-GCE-36-2-CP
RO-GCE-36
RO-GCE_GUIDE (01/22)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RO-GCE Series and is the answer not in the manual?

Questions and answers

Related Manuals for Rosko RO-GCE Series

Summary of Contents for Rosko RO-GCE Series

  • Page 1 RO-GCE Electric Countertop Griddle RO-GCE-36 INSTALLATION GUIDE Operation, Maintenance, and Service Parts RO-GCE-18-1 RO-GCE-24-1 RO-GCE-36-1 RO-GCE-18-2 RO-GCE-24-2 RO-GCE-36-2 RO-GCE-24-1-CP RO-GCE-36-1-CP RO-GCE-24-2-CP RO-GCE-36-2-CP 955 Lachance Street Quebec, QC G1P 2H3 1-866-901-5624 Canada www.rosko-julien.ca RO-GCE_GUIDE (01/22)

  • Page 2: Warnings And Cautions

    Any installation, adjustment, modification, repair, or maintenance not in accordance with applicable standards may cause injury, death, or property damage. To ensure a safe installation and proper operation of your Rosko equipment, please read this entire manual and keep it for future reference. • This unit is intended for commercial use only.

  • Page 3: Table Of Contents

    TABLE OF CONTENT 1. WARNINGS AND CAUTIONS ....................2 2.

  • Page 4: Planning And Installation

    2. PLANNING AND INSTALLATION Congratulations on the purchase of your new Rosko electric countertop griddle! To maximize the use and durability of your unit, we recommend that you follow the instructions in this guide. Installation, operation, and maintenance procedures must be followed for warranty protection to apply.

  • Page 5: Level

    2.3. LEVEL WARNING The griddle must be supported by a heatproof countertop or stand. Once the unit is in its final position, level the griddle by adjusting the leveling feet. Make sure the griddle is level in the front-to-back and side-to-side axis. It is recommended to level the unit each time it is moved. Proper leveling prevents accidents and ensures optimal cooking performance.

  • Page 6: Connection

    2.5. CONNECTION The wire entry for the connection is a 1" knockout hole located at the back of the griddle. Use a 1" commercial electrical connector (not included) to insert the electrical supply wire into the unit. The connection must be made by a certified technician or electrician. WARNING Installation must meet the requirements of the codes below, where applicable.
  • Page 7 4. To reach the terminal block, remove the grease drawer, unscrew the four (4) bolts in front of the unit and remove the two (2) front panels. (Figure 3) 5. Insert and secure the correct length of unsheathed wire in the connector to direct it to the terminal block located on the front of the unit.

  • Page 8: Operation

    3. OPERATION WARNING Never leave the thermostat knob(s) in the maximum position when the plate is not used. This could cause the plate to overheat, turn black, and could cause damage 3.1. FIRST USE Factory plate protection 1. Before using the unit, heat the plate to 300° F for five (5) minutes to burn off the protective coating. 2.

  • Page 9: Maintenance

    4. MAINTENANCE 4.1. CONDITION It is essential to coat the plate with oil immediately after use and to keep it oiled at all times to prevent rust. NOTE: This step does not apply to griddles with a polished chrome finish. After cleaning the griddle, follow these steps to ensure optimal long-term performance: 1.
  • Page 10 RO-GCE_GUIDE (12/21)

  • Page 11: Electrical Diagram

    5. ELECTRICAL DIAGRAM 5.1. RO-GCE-18 GCE-18 Figure 6 RO-GCE_GUIDE (12/21)

  • Page 12: Gce-24

    5.2. RO-GCE-24 GCE-24 Figure 7 RO-GCE_GUIDE (12/21)

  • Page 13: Gce-36

    5.3. RO-GCE-36 GCE-36 Figure 8 RO-GCE_GUIDE (12/21)

  • Page 14: Service Parts

    6. SERVICE PARTS 6.1. RO-GCE-18 See figure 9 for identification of service parts Code Description 202101007 Grease Pan Drawer for Gas Griddle 913900238 Knob Ring for Control OFF/100-450° F 913900220 Control Knob for Commutable Ring 910300014 Red Square Indicator Light 250 V 913200028 Thermostat OFF/100-450°...
  • Page 15 DÉTAIL A ÉCHELLE 1 : 4 Figure 9 RO-GCE_GUIDE (12/21)

  • Page 16: Gce-24

    6.2. RO-GCE-24 See figure 10 for identification of service parts Code Description 202101007 Grease Pan Drawer for Gas Griddle 913900238 Knob Ring for Control OFF/100-450° F 913900220 Control Knob for Commutable Ring 910300014 Red Square Indicator Light 250 V 913200028 Thermostat OFF/100-450°...
  • Page 17 Figure 10 RO-GCE_GUIDE (12/21)

  • Page 18: Gce-36

    6.3. RO-GCE-36 See figure 11 for identification of service parts Code Description 202101007 Grease Pan Drawer for Gas Griddle 913900238 Knob Ring for Control OFF/100-450° F 913900220 Control Knob for Commutable Ring 910300014 Red Square Indicator Light 250 V 913200028 Thermostat OFF/100-450°...
  • Page 19 DÉTAIL A ÉCHELLE 1 : 4 Figure 11 RO-GCE_GUIDE (12/21)
  • Page 20 RO-GCE_GUIDE (12/21)

  • Page 21: Specifications

    7. SPECIFICATIONS This guide is dedicated to the Rosko electric countertop griddles listed below. Shipping dimensions Models Width (W) Depth Total height Cooking surface Weight (W x D x H) RO-GCE-18-1 171/ 2 x 19'' 30 x 20 x 27'' 18'' –...

  • Page 22: Contact Us

    WARNING Keep this guide for future reference. CONTACT US customerservice@rosko-julien.ca 955 Lachance Street Quebec, QC G1P 2H3 1-866-901-5624 Canada www.rosko-julien.ca RO-GCE_GUIDE (12/21)
