- Page 1 3000 In-Wall Subwoofer PRE-CONSTRUCTION KIT Installation Guide...
- Page 2 Pre-Construction Kit Hardware Pre-Construction Frame Frame Wings Wing Screws Pre-Construction Frame and Wing Assembly The Pre-Construction Frame is assembled by snapping together all 6 plastic frame parts, as shown below. Join the frame parts together by inserting the tabs into the corresponding slots.
- Page 3 firmly into place. The 3000 In-Wall Subwoofer Pre-Construction kit comes with 4 wings. These 4 wings can be installed in any of 6 locations on the frame as needed for installation.
- Page 4 Attach Pre-Construction Kit to Studs Hold the frame with the “SVS” logo facing out into the room and position the bracket in the desired installation location. Using the included screws, or your own hardware, attach one wing to the stud. While making sure the frame is level, attach the second wing to the next stud.
