- Page 1 GVF 10,000 Sonic Spray Owners Manual Gillison’s V ariety Fabrication, Inc. Manual Part Number: GTS 11125 Model Number: GVF 10,000 3033 B , Mi 49616 231-882-5921 enzie enzonia email: info@gillisons.com 231-882-5637 800-392-6059 online: www.gillisons.com INDEX PREVIOUS NEXT LAST...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION ELECTRICAL About Sonic Spray’s Zones Battery to Controller OPERATOR INTERFACE DISPLAY Harness Display to Controller Overview of Sonic Spray’s Operator Interface HARNESS, VALVE 6 ZONE FOR AIR-O-FAN ENGINE DR INITIAL SET-UP HARNESS, VALVE 8 ZONE FOR AIR-O-FAN ENGINE DR OPERATION Power Supply 25 MAINTENANCE... -
Page 3: Introduction
INTRODUCTION INTRODUCTION The information in this publication describes the parts of the GVF Sonic Spray, Model GVF 10,000. Every effort has been made to provide correct and concise information, as available at the date of publication. Your GVF dealer is available should items in this book or details of your machine not be understood. -
Page 4: Operator Interface Display
GVF Sonic Spray Owners Manual OPERATOR INTERFACE DISPLAY OPERATOR INTERFACE DISPLAY OVERVIEW OF SONIC SPRAY’S OPERATOR INTERFACE The Operator Interface is the display screen where all of the settings and adjustments are made concerning the operation of the GVF Sonic Spray. Flip the power switch up on the Operator Interface to turn on and operate the GVF Sonic Spray. - Page 5 GVF Sonic Spray Owners Manual OPERATOR INTERFACE DISPLAY Main Screen PUSH BUTTON CONTROLS STATUS OF ZONE, AUTO/ ON/OFF ULTRASONIC TARGET DISTANCE VALVE STATUS STATUS SPEED IN MPH TRIM KEYS UP/DOWN INCREASES START POINT AND END POINT OF SPRAY 0=NO INCREASE 100= ABOUT 3' BEFORE AND AFTER TREE WINDOW TRIM +/- A setting of 100 is equal...
- Page 6 GVF Sonic Spray Owners Manual OPERATOR INTERFACE DISPLAY Ultrasonic Set-Up STATUS ON= VALVE ON ALL THE TIME ZONE SPRAYS ALL THE TIME STATUS OFF= ZONE IS OFF ALL VALVE IS OFF ALLTHE TIME THE TIME INDEX PREVIOUS NEXT LAST...
- Page 7 GVF Sonic Spray Owners Manual OPERATOR INTERFACE DISPLAY Ultrasonic Set-Up continued Adjust the maximum distance that the ultrasonic eye will detect. PUSH KEY THEN USE UP/DOWN KEYS TO ADJUST DISTANCE INDEX PREVIOUS NEXT LAST...
- Page 8 GVF Sonic Spray Owners Manual OPERATOR INTERFACE DISPLAY Valve Set-Up Screen Push the corresponding button to test a valve. PUSH KEY AND HOLD TO TURN VALVE ON PRESS KEY TO TURN ALL VALVES ON INDEX PREVIOUS NEXT LAST...
- Page 9 GVF Sonic Spray Owners Manual OPERATOR INTERFACE DISPLAY Set-Up Screen RH SIDE DIAMETER OF LH SIDE PUSH KEY AND NUMBER OF HOLES IN WHEEL ON SPRAYER DISTANCE FROM DISTANCE FROM USE UP/DOWN HUB METERING PLATE ULTRASONICS ULTRASONICS KEYS TO ADJUST TO NOZZLES TO NOZZLES ON=SPEED SENSOR INPUT...
- Page 10 GVF Sonic Spray Owners Manual OPERATOR INTERFACE DISPLAY Diagnostics Screen FOR TESTING ADJUSTS THE SELECTS SPANISH OR ENGLISH TURNS ON ZONES 7-10 SPIN WHEEL CONTRAST OF TO CHECK THE SCREEN INDEX PREVIOUS NEXT LAST...
- Page 11 GVF Sonic Spray Owners Manual OPERATOR INTERFACE DISPLAY Zone Savings Screen AMOUNT OF TIME THAT ZONE WAS ON TOTAL TIME ON PERCENT ON 58S/88S = 65% PERCENT OFF 30S/88S=35% PRESS TO RESET INDEX PREVIOUS NEXT LAST...
-
Page 12: Initial Set-Up
GVF Sonic Spray Owners Manual INITIAL SET-UP INITIAL SET-UP 1) Pulses / Rev.: Number of holes in metering plate on wheel. 2) Nozzle Spacing: This is a distance setting, in inches, from the sprayer’s nozzles to the ultrasonic eyes. This distance can be adjusted to accommodate different sprayer lengths. -
Page 13: Operation
GVF Sonic Spray Owners Manual OPERATION OPERATION 1) Turn on sprayer. 2) Turn on sprayer valves. 3) Select the zones in Sonic Spray’s Operator Interface Main Screen that are desired to run. Enable Master, enable RH zone + LH zone. Each zone 1-10 defaults to auto. -
Page 14: Maintenance
GVF Sonic Spray Owners Manual MAINTENANCE MAINTENANCE BASIC 1) Eyes: Do not power wash tip of ultrasonic eyes/ sensors. Wash with soft, damp cloth only. 2) Valves: Partially fill tank with clean water. Run sprayer and operate valves on/off to clean out at the end of each day of use. -
Page 15: Maintenance Of Solenoid Valves
diaphragm spring seats in cup of diaphragm assembly. fluid conditions are such that corrosion, elastomer degradation, then torque bonnet screws in a crisscross manner to 95 ± 10 interval between exercise cycles. 5. For standard construction, position core assembly with core fluid contamination build up, or other conditions that could in-lbs [10,7 ±... -
Page 16: Installation On Tractor
GVF Sonic Spray Owners Manual INSTALLATION ON TRACTOR INSTALLATION ON TRACTOR 1) Route power supply harness to battery on tractor. Connect red wire to 12V post on battery. Connect black wire to ground post. 2) Route display harness into tractor cab and plug in corresponding connections. -
Page 17: Kit Installation On Sprayer
GVF Sonic Spray Owners Manual KIT INSTALLATION ON SPRAYER KIT INSTALLATION ON SPRAYER ZONE DIAGRAM 12 PIN CONNECTION FOR DISPLAY ZONE 1 ZONE 4 ZONE 2 ZONE 5 ZONE 3 ZONE 6 INDEX PREVIOUS NEXT LAST... -
Page 18: Ultrasonic Electrical Connections
GVF Sonic Spray Owners Manual KIT INSTALLATION ON SPRAYER ULTRASONIC ELECTRICAL CONNECTIONS ROUTE CORD THROUGH HOLE AND INSTALL NUT, PLUG IN CONNECTOR TO THE CORRESPONDING ZONE ZONE 1 AT TOP LOCATION THEN TIGHTEN SEAL TIGHT NUT ZONE IDENTIFIER NUMBER INDEX PREVIOUS NEXT LAST... -
Page 19: Valve Mounting Reference
GVF Sonic Spray Owners Manual KIT INSTALLATION ON SPRAYER VALVE MOUNTING REFERENCE NOZZLES ARE SPLIT TO MATCH ULTRASONIC ZONES VALVE INSTALLATION FOLLOW DIRECTION OF FLOW INDICATED ON THE VALVE MAKE SURE COIL IS NOT POINTED DOWN VALVE IS ON WHEN PIN 1 = 12V PIN 2 = GROUND VALVE IS NORMALLY CLOSED... -
Page 20: Valve Installation
GVF Sonic Spray Owners Manual KIT INSTALLATION ON SPRAYER VALVE INSTALLATION VALVE COIL MOUNTING NEEDS TO BE ON TOP LIGHT COMES ON WHEN ENERGIZED ON DIRECTION OF FLOW MARKED ON VALVE TO MANIFOLD SUPPLY FROM PUMP INDEX PREVIOUS NEXT LAST... -
Page 21: Display Controller Can Tool
GVF Sonic Spray Owners Manual KIT INSTALLATION ON SPRAYER DISPLAY CONTROLLER CAN TOOL CONNECTION NEXT TO DISPLAY TERMINATING RESISTOR UNPLUG THEN RECONNECT CAN TOOL CAN TOOL CONNECTION INDEX PREVIOUS NEXT LAST... -
Page 22: Speed Sensor And Parts
GVF Sonic Spray Owners Manual KIT INSTALLATION ON SPRAYER SPEED SENSOR AND PARTS GL 12156 GTS 11015 CLAMP, 2" SWITCH, PROXIMITY GTS 11020A HARNESS, PROXIMITY LIGHT ILLUMINATES WHEN OVER PLATE SPEED SENSOR PLATE TYPICAL 36 HOLES WHEN ORDERING SPECIFY SPEED SENSOR DIAMETER, PILOT, AND BOLT MOUNTING PLATE FOR PATTERN OR SPRAYER INFO... -
Page 23: Speed Sensor Harness To Main Connection
GVF Sonic Spray Owners Manual KIT INSTALLATION ON SPRAYER SPEED SENSOR HARNESS TO MAIN CONNECTION SPEED SENSOR HARNESS TO MAIN HARNESS CONNECTION INDEX PREVIOUS NEXT LAST... -
Page 24: Front Of Sprayer Electrical Connections
GVF Sonic Spray Owners Manual KIT INSTALLATION ON SPRAYER FRONT OF SPRAYER ELECTRICAL CONNECTIONS DISPLAY HARNESS CONNECTION AT FRONT OF SPRAYER CONSTANT 12V POWER AND GRD. CONNECTION CONNECTION FRONT FOR POWER OF SPAYER SWITCH FRONT OF SPRAYER INDEX PREVIOUS NEXT LAST... -
Page 25: Troubleshooting
GVF Sonic Spray Owners Manual TROUBLESHOOTING TROUBLESHOOTING 3) Check 12V power on brown wire. SONIC SPRAY WILL NOT POWER UP Check for ground on blue wire. 1) Check 50 & 20 amp fuse in PRM located at Check 0-10V output on violet wire. battery. -
Page 26: No Sync Warning
TROUBLESHOOTING GVF Sonic Spray Owners Manual Troubleshooting Continued NO SYNC WARNING The SYNC feature is used and a slave sensor does not detect a master SYNC input, the slave will stop measuring and the Target Status indicator will slowly alternate between RED and GREEN until SYNC is restored. -
Page 27: Electrical
ELECTRICAL GVF Sonic Spray Owners Manual ELECTRICAL POWER SUPPLY INDEX PREVIOUS NEXT LAST... -
Page 28: Ultrasonics
ELECTRICAL GVF Sonic Spray Owners Manual ULTRASONICS INDEX PREVIOUS NEXT LAST... -
Page 29: Valves
ELECTRICAL GVF Sonic Spray Owners Manual VALVES INDEX PREVIOUS NEXT LAST... -
Page 30: Speed Sensor
ELECTRICAL GVF Sonic Spray Owners Manual SPEED SENSOR INDEX PREVIOUS NEXT LAST... -
Page 31: Harness Display To Controller
ELECTRICAL GVF Sonic Spray Owners Manual HARNESS DISPLAY TO CONTROLLER GTS 10050A INDEX PREVIOUS NEXT LAST... -
Page 32: Harness, Valve 6 Zone For Air-O-Fan Engine Dr
ELECTRICAL GVF Sonic Spray Owners Manual HARNESS, VALVE 6 ZONE FOR AIR-O-FAN ENGINE GTS 10055 INDEX PREVIOUS NEXT LAST... -
Page 33: Harness, Valve 8 Zone For Air-O-Fan Engine Dr
ELECTRICAL GVF Sonic Spray Owners Manual HARNESS, VALVE 8 ZONE FOR AIR-O-FAN ENGINE DR GTS 10056 INDEX PREVIOUS NEXT LAST... -
Page 34: Battery To Controller
ELECTRICAL GVF Sonic Spray Owners Manual BATTERY TO CONTROLLER GTS 10051A INDEX PREVIOUS NEXT LAST... -
Page 35: Valve Harness Sprayer, 6 Zone
ELECTRICAL GVF Sonic Spray Owners Manual VALVE HARNESS SPRAYER, 6 ZONE GTS 10052 INDEX PREVIOUS NEXT LAST... -
Page 36: Valve Harness Sprayer, 8 Zone
ELECTRICAL GVF Sonic Spray Owners Manual VALVE HARNESS SPRAYER, 8 ZONE GTS 10052-8 INDEX PREVIOUS NEXT LAST... -
Page 37: Valve Harness Sprayer To Control
ELECTRICAL GVF Sonic Spray Owners Manual VALVE HARNESS SPRAYER TO CONTROL GTS 10053 INDEX PREVIOUS NEXT LAST... -
Page 38: Parts
PARTS GVF Sonic Spray Owners Manual PARTS CLAMPS E 568-228BN70 N 2012A ORING, SHCS, 10-24 X 1 SS 2.25 X 2.5 X 1/8 N 2012A E 568-225BN70 SHCS, 10-24 X 1SS ORING, 1.875 X 2.125 X 1/8 GTS 10013 CLAMP, FOR 15S GTS 11090 ULTRASONIC CLAMP,FOR 21S... -
Page 39: Sensors For Standard Range Sonic Spray
GVF Sonic Spray Owners Manual PARTS SENSORS FOR STANDARD RANGE SONIC SPRAY GTS 11001 SENSOR, ULTRASONIC SLAVE USED ON ZONES 2-10 GTS 11002 SENSOR, ULTRASONIC MASTER SENSOR IS ABOUT 1.875" DIAMETER USED ON ZONE 1 ZONE NUMBER IDENTIFIED HERE INDEX PREVIOUS NEXT LAST... -
Page 40: Sensors For 50 Ft Long Range Sonic Spray
PARTS GVF Sonic Spray Owners Manual SENSORS FOR 50 FT LONG RANGE SONIC SPRAY GTS 11008 SENSOR, ULTRASONIC 21S SLAVE USED ON ZONES 2-10 GTS 11009 SENSOR, ULTRASONIC 21S MASTER USED ON ZONE 1 ZONE NUMBER IDENTIFIED HERE SENSOR IS ABOUT 2.25" DIAMETER INDEX PREVIOUS NEXT... -
Page 41: Asco Valves & Repair Kit Gts 11006
GVF Sonic Spray Owners Manual PARTS ASCO VALVES & REPAIR KIT GTS 11006 GTS 11006 can be replaced with GTS 11350 Tork Valve & GTS 11321 DIN Harness GTS 11006 VALVE, 12V ACSO GTS 11006 REPAIR KIT IS GTS 11110 & IT INCLUDES WHEN ASSEMBLING LOCATE ORFICE IN... -
Page 42: Tork Valve & Din Harness Gts 11350
PARTS GVF Sonic Spray Owners Manual TORK VALVE & DIN HARNESS GTS 11350 GTS 11350 VALVE, TORK 1/2 NPT GTS 11321 HARNESS, DIN TERMINATED INDEX PREVIOUS NEXT LAST... -
Page 43: Tork Valve Repair Kit
GVF Sonic Spray Owners Manual PARTS TORK VALVE REPAIR KIT GTS 11350, valve, 1/2” Tork GTS 11325, Valve 1” Tork (ARG Sonic sprays) GTS 11350 VALVE, TORK 1/2IN GTS 11325 VALVE, TORK 1IN BOTH USE THE SAME COMPONENTS GTS 11329 REPAIR KIT, FOR 1/2 IN &... -
Page 44: Harnesses
PARTS GVF Sonic Spray Owners Manual HARNESSES INDEX PREVIOUS NEXT LAST... -
Page 45: Harness, Proximity & Parts
GVF Sonic Spray Owners Manual PARTS HARNESS, PROXIMITY & PARTS GTS 11020A HARNESS, PROXIMITY BOM GTS 11015 SWITCH, PROXIMITY GL 11517 CONNECTOR, 4-WIRE GL 11550 TERMINAL, FEMALE GL 11560 PLUG, CAVITY INDEX PREVIOUS NEXT LAST... -
Page 46: Display Controller And Parts
PARTS GVF Sonic Spray Owners Manual DISPLAY CONTROLLER AND PARTS GL 11510 GTS 11215 CONNECTOR, 2 WIRE FEM RAM UBOLT BASE GL 11550 TERMINAL, FEM MOUNT, SWITCH GSS 10485 SWITCH, TOGGLE GTS 11220 GTS 11310 RAM MT W VESA PLATE DISPLAY, COLOR INCLUDES 4 BOLT MUST BE PROGRAMED, NEED S/N OF SONIC SPRAY... -
Page 47: Mount For Display Controller And Parts
GVF Sonic Spray Owners Manual PARTS MOUNT FOR DISPLAY CONTROLLER AND PARTS GTS 11215 RAM UBOLT GSS 10485 SWITCH, TOGGLE GTS 11220 RAM, MOUNT W/ GTS 11220 VESA PLATE RAM, MOUNT W/ VESA PLATE N 3095 N 3105 FLATWASHER, 5MM HHCS,4-.7MM X 14MM INDEX PREVIOUS... -
Page 48: Battery Connection Parts
PARTS GVF Sonic Spray Owners Manual BATTERY CONNECTION PARTS GROUND WIRE GL 12210 GL 11960 FUSE, 50 AMP MODULE, POWER RELAY 12V SWITCHED 12V SWITCHED POWER FOR SYSTEM BATTERY CONNECTION 12V POWER TO GL 12205 ON/OFF SWITCH FUSE, 20 AMP 12V SUPPLY INDEX PREVIOUS... -
Page 49: Sonic Spray Main Enclosure
GVF Sonic Spray Owners Manual PARTS SONIC SPRAY MAIN ENCLOSURE GVF 10019 INDEX PREVIOUS NEXT LAST... -
Page 50: Wheel Speed Assembly
PARTS GVF Sonic Spray Owners Manual WHEEL SPEED ASSEMBLY GTS 10000 INDEX PREVIOUS NEXT LAST... -
Page 51: Speed Sensor And Parts
GVF Sonic Spray Owners Manual PARTS SPEED SENSOR AND PARTS GL 12156 GTS 11015 CLAMP, 2" SWITCH, PROXIMITY GTS 11020A HARNESS, PROXIMITY LIGHT ILLUMINATES WHEN OVER PLATE SPEED SENSOR PLATE TYPICAL 36 HOLES WHEN ORDERING SPECIFY SPEED SENSOR DIAMETER, PILOT, AND BOLT MOUNTING PLATE FOR PATTERN OR SPRAYER INFO REAR'S SPINDLE... -
Page 52: Rears Front Panel And Parts Reference
PARTS GVF Sonic Spray Owners Manual REARS FRONT PANEL AND PARTS REFERENCE N 1060 GTS 11030 GTS 11035 N 1270 HHCS, 1/4-20 X 3 TERMINAL STUD, HEX NUT, 3/8-16 TERMINAL STUD, N 1005 POSITIVE NEGATIVE LOCKNUT, 1/4-20 N 1140 HEX NUT, 5/16-18 4PC OF EACH N 9505 MACHINE SCREW, 10-24 X 1/2... -
Page 53: Rears Front Panel And Parts Reference Continued
GVF Sonic Spray Owners Manual PARTS REARS FRONT PANEL AND PARTS REFERENCE CONTINUED GTS 11105 CONNECTOR ASSEMBLY, ULTRA SONIC IF REPLACING USE SP 8030 TERMINAL, SHRINK GTS 11075 ENCLOSURE, HOFFMAN 6X6X4 GTS 10053 HARNESS, VALVE TO CONTROL GTS 11070 STRAIN RELIEF INDEX PREVIOUS NEXT... -
Page 54: Gvf Warranty
WARRANTY GVF Sonic Spray Owners Manual GVF WARRANTY Gillison’s Variety Fabrication, Inc. will replace or repair at GVF option, any GVF manufactured item that is, in the opinion of GVF, defective in material or workmanship for a period of 1 year from the date of purchase, and is returned to the GVF plant or service center at the expense of the customer.
