iBACheck AA2000 Series Operation Manual

Professional alcohol tester
AA2000 series
Description
Hand-held breathalyzer AA2000:- using stable and reliable measuring
technology based on the electrochemical reaction between platinum and
ethanol molecules.
Wait
Mouthpiece
ON/OFF
LED Inductors:-
"Wait" Green light flashes together with PH while sensor initializing; wait
until green light lit and then the device is ready to perform the test
Red light lit when the device is connected to USB charger
" ! " Red light lit when the result over the alert level
" " Green light lit when entering into the memory recall mode.
Operation Manual
! "Record"
Esc
2
CONTENT
Description
Condition for testing
Battery Power
On/Off
Alcohol Test
Test record
Systems Settings & Calibration
Important notes
Specifications/Precautions
Liability for proper function or damage/ Fuel Cell
Technology
How does alcohol testing work / Maintenance
Conditions for Testing
To begin, rinse your mouth with fresh water before using the device.
Abstain from smoking or drinking for at least 15 minutes. If preform a test
just after drinking, the reading will fluctuate from very high reading and
then drop gradually. It is due to the alcohol residues inside your mouth
enhance the measured values. This will also happen with aromatic drinks,
alcoholic mouthwashes or mouth sprays, medicines or drug, as well as by
burping and vomiting.
Also, w hen alcohol enters the blood through the alimentary canal (mouth,
stomach, and intestines), it is distributed through every part of the body,
including the lungs. This period will take about 15~30minutes before stable.
Our device detect human breathe and gives a digital read out of a person's
approximate Blood Alcohol Concentration (known from here on as BAC).
Battery Power
Read the User instructions carefully before use
Inserting the batteries
1. Open the battery cover on the back of the device.
Insert 1 x 3.7V rechargeable battery (AA) into the battery
2.
compartment.
3. When flash on the display, the power is not enough.
Connect the USB cable and charge the machine. "Wait" LED will
change to RED color and
2
3
3
4
4、5
6
6、7、8
8
9
10
11
.
will turn off when fully charged
