  • Page 3 COOLMAY MX3G PLC HMI All in one Programming manual COOLMAY MX3G PLC HMI All in one Programming manual (PLC part: Difference comparing with Mitsubishi FX3GS) All right belongs to Shenzhen Coolmay Technology Co.,Ltd V21.121...

  • Page 4: Table Of Contents

    COOLMAY MX3G PLC HMI All in one Programming manual catalog 1. Overview........................1 1.1. MX3G PLC HMI All in one Main Advantage:..........1 1.2. Product parameters..................3 1.3. Hardware description..................5 1.3.1. MX3G-43C structure and size..............5 1.3.2. MX3G-70C structure and size..............6 1.3.3. Introduction of each interface and indicator......... 7 2.
  • Page 5 4.2.2. Save as HMI program................78 4.2.3. Update HMI OS..................79 4.3. Program upload..................... 81 4.3.1. Upload HMI program................81 4.4. For detailed usage of the HMI software, please refer to "Coolmay TP Series HMI User Manual"..................82 5. Appendix: Version Change Record..............83...

  • Page 6: Overview

    HMI comes with 1 RS232, which can be changed to 1 RS485; the PLC of the MX3G-43C all-in-one machine comes with 1 RS485; the HMI comes with 1 RS232. They are used for external HMI and inverters and other equipment.
  • Page 7 ◆MX3G-70C is up to 24DI/24DO (MR: 12 at most), digital output can be optional transistor MT (maximum load 500mA) or relay and transistor mixed output MRT. MX3G-43C is up to 12DI/10DO (MR: 8 at most), digital output optional transistor MT (Max load: 500mA) or relay and transistor mixed output MRT.

  • Page 8: Product Parameters

    COOLMAY MX3G PLC HMI All in one Programming manual 1.2. Product parameters Model MX3G-43C-22M MX3G-70C-48M Dimensions 134*102*34mm 210*146*36mm Cutout size 120*94mm 192*138mm Power 4-6W 6-7W consumption Feature 60K colors resistive touch screen, supports portrait display Type 4.3"TFT 7.0"TFT Display size...
  • Page 9 COOLMAY MX3G PLC HMI All in one Programming manual transmission cannot exceed 300KHz transmission cannot exceed 300KHz Input Comes with 2 channels of voltage 0-10V+2 channels of current 0-20mA+1 channel NTC10K Anal Comes with 1 voltage 0-10V + 1 current 0-20MA...

  • Page 10: Hardware Description

    COOLMAY MX3G PLC HMI All in one Programming manual 1.3. Hardware description 1.3.1. MX3G-43C structure and size PLC running indicator Communication indicator Power indicator Dimensions (mm): 134*102*34 Cutout size (mm): 120*94 Display size (mm): 97*56 Installation method: Clip installation...

  • Page 11: Mx3G-70C Structure And Size

    COOLMAY MX3G PLC HMI All in one Programming manual 1.3.2. MX3G-70C structure and size PLC running indicator Communication indicator Power indicator Dimensions (mm):210*146*36 Cutout size (mm): 192*138 Display size (mm): 154*87 Installation method: Clip installation...

  • Page 12: Introduction Of Each Interface And Indicator

    COOLMAY MX3G PLC HMI All in one Programming manual 1.3.3. Introduction of each interface and indicator POWER: Power indicator, connected to the power light RUN: PLC running status indicator. This light is on when the PLC is running. COM: touch screen and PLC communication status indicator, when the two...

  • Page 13: Plc

    COOLMAY MX3G PLC HMI All in one Programming manual 2. PLC 2.1. PLC Programming notice The PLC is compatible with GX Developer8.86/GX Works2 and below. If you use other versions of software, incompatibility may occur. When the PLC program is downloaded, there is a prompt error: Cannot specify the com port, GX 8.86 software: Online-Transfer settings change com port;...

  • Page 14: Soft Element Table

    COOLMAY MX3G PLC HMI All in one Programming manual 2.2. Soft element table Name Contents I/O relay Input relay X000～X027 24 points Soft element number is octal Output relay Y000～Y027 24 points Total 48 points for I/O Auxiliary relay General M0～M383...
  • Page 15 COOLMAY MX3G PLC HMI All in one Programming manual General bi-direction (32 -2,147,483,648 ～ +2,147,483,647 C200～C234 35 points bit) counter High-speed counter Single-phase single counter input -2,147,483,648～+2,147,483,647 counter C235～C245 Bi-direction (32 bit) Software counter (EEPROM hold) Single phase: up to 6 channels, maximum...

  • Page 16: Special Relay Number And Content

    COOLMAY MX3G PLC HMI All in one Programming manual 2.3. Special relay number and content Content Remarks Content Remarks C220 Increase/decrease M8000 In RUN,Normally closed M8220 counting action C221 Increase/decrease M8001 In RUN,Normally open M8221 counting action After RUN, Output a scan cycle...
  • Page 17 COOLMAY MX3G PLC HMI All in one Programming manual Content Remarks Content Remarks counting action C240 Increase/decrease M8037 Force STOP command M8240 counting action C241 Increase/decrease M8045 Prohibit reset of all outputs M8241 counting action C242 Increase/decrease M8046 STL state action...
  • Page 18 COOLMAY MX3G PLC HMI All in one Programming manual Content Remarks Content Remarks C219 Increase/decrease M8065 Grammatical error M8219 counting action Y000 clear signal output M8066 Loop error M8341 function is valid Y000 specify the origin return M8067 Operation error...
  • Page 19 COOLMAY MX3G PLC HMI All in one Programming manual Content Remarks Content Remarks Y002 near-point DOG signal M8175 Input X005 pulse capture M8365 logic inversion Y002 zero signal logic M8176 Input X006 pulse capture M8366 inversion Y002 interrupt signal logic...

  • Page 20: Special Register Number And Content

    COOLMAY MX3G PLC HMI All in one Programming manual Content Remarks Content Remarks action reception C213 Increase/decrease counting RS2 command data setting M8213 M8405 action ready C214 Increase/decrease counting RD3A/WR3A Receive M8214 M8408 action Completed C215 Increase/decrease counting RD3A/WR3A M8215...
  • Page 21 COOLMAY MX3G PLC HMI All in one Programming manual D8037 AD7 analog input value D8348 pulse acceleration time D8038 AD8 analog input value D8349 pulse deceleration time D8050 DA0 analog output value D8350 position pulse amount D8051 DA1 analog output value...

  • Page 22: Function Instructions (Contrast With Fx3Gs Plc Instruction)

    COOLMAY MX3G PLC HMI All in one Programming manual D8096 D8376 X4 pulse width / pulse period Y3 Origin return speed [10μs unit] Initial value:50000 D8097 High D8377 High D8101 PLC type and system version D8378 pulse acceleration time D8102...
  • Page 23 COOLMAY MX3G PLC HMI All in one Programming manual Mnemonic Name Features Available devices take Normally open contact logic operation starts X,Y,M,S,D□.b,T,C Negate Normally closed contact logic operation starts X,Y,M,S,D□.b,T,C Take the rising edge of the Start of operation to detect rising edge X,Y,M,S,D□.b,T,C...
  • Page 24 COOLMAY MX3G PLC HMI All in one Programming manual Arithmetic operation instructions Logical operation instructions Special function instructions Rotate instructions Shift instruction Data operation instructions Character string operation instructions Program flow control instructions I/O refresh instructions Real time clock control instructions...
  • Page 25 COOLMAY MX3G PLC HMI All in one Programming manual Conversion to Floating Point ★ Floating Point to Integer Conversion ★ Floating Point to Scientific Notation EBCD ★ Conversion Scientific Notation to Floating Point EBIN ★ Conversion Floating Point Degree to Radian ★...
  • Page 26 COOLMAY MX3G PLC HMI All in one Programming manual BKCMP Block compare (S1)>(S2) ★ > BKCMP Block compare (S1)<(S2) ★ < BKCMP< Block compare (S1)≠(S2) ★ > BKCMP< Block compare (S1)≦(S2) ★ BKCMP> Block compare (S1)≧(S2) ★ 4. Arithmetic operation instructions Mnemonic FNC No.
  • Page 27 COOLMAY MX3G PLC HMI All in one Programming manual Floating Point Sine ★ Floating Point Cosine ★ Floating Point Tangent ★ ASIN Floating Point Arc Sine ★ ACOS Floating Point Arc Cosine ★ ATAN Floating Point Arc Tangent ★ Random Number Generation ★...
  • Page 28 COOLMAY MX3G PLC HMI All in one Programming manual 4-bit Linking of Word Data ★ 4-bit Grouping of Word Data ★ Check Code ★ Cyclic Redundancy Check ★ LIMIT Limit Control ★ BAND Dead Band Control ★ ZONE Zone control ★...
  • Page 29 COOLMAY MX3G PLC HMI All in one Programming manual Mnemonic FNC No. Function Support Conditional Jump ★ CALL Call Subroutine ★ SRET Subroutine Return ★ IRET Interrupt Return ★ Enable Interrupt ★ Disable Interrupt ★ FEND Main Routine Program End ★...
  • Page 30 COOLMAY MX3G PLC HMI All in one Programming manual PLSY Pulse Y Output ★ Acceleration/Deceleration Setup PLSR ★ 15. Serial communication instructions Mnemonic FNC No. Function Support Serial Communication ★ R(S2) Serial Communication 2 ★ IVCK Inverter Status Check IVDR...

  • Page 31: Analog Input

    For detailed instruction usage, please refer to programming manual" 2.6. Analog input Input precision of coolmay MX3G HMI PLC All-in-one is 12-bit, directly read the corresponded register value of each analog while using. Environment temperature is only used in thermocouple.

  • Page 32: Analog Input Reading

    COOLMAY MX3G PLC HMI All in one Programming manual K-type Room Room thermocouple temperature～ temperature～ 0.1℃ 1100℃ 11000 K-type thermocouple -230～1370℃ -2300～13700 0.1℃ (Negative temp) T-type Room Room thermocouple temperature～ temperature～ 0.1℃ 400℃ 4000 T-type thermocouple -230～400℃ -2300～4000 0.1℃ (Negative temp)

  • Page 33: Analog Input Sampling

    COOLMAY MX3G PLC HMI All in one Programming manual D400 K8, read out 8 analog input, 0-10V. The register is directly read: D[8030]~D[8038] is the output value set for the corresponding type, the constant scan time is changed to D8059, and it is started by M8039 (version 26232 and above);...
  • Page 34 COOLMAY MX3G PLC HMI All in one Programming manual acquisition. The program reads the values as follows: Connect the signal terminal of the temperature sensor to the AD0 input of the PLC and the other end to the GND of the analog input port.

  • Page 35: Analog Output

    COOLMAY MX3G PLC HMI All in one Programming manual If the current temperature is 37.9℃,the actual test is 47.9 ° C, the error is 10 ° C, you need to modify the size correction register, show as below: In the above figure, when M0 is closed, the value -100 is transmitted to the...

  • Page 36: Pid Instruction

    COOLMAY MX3G PLC HMI All in one Programming manual D8050 0-4000 D8051 0-4000 Example： Below shows the 0-10V voltage analog output. At this point, use a multimeter to check the voltage of the DA0 terminal, that is, the multimeter's red pen is connected to the DA0 terminal, and the black pen is connected to the GND terminal.
  • Page 37 COOLMAY MX3G PLC HMI All in one Programming manual 16-bit operation (PID): After setting the target value S1., the measured value S2., and the parameters S3~S3+6 in the execution program, the operation result (MV) is saved to the output value D. every sampling time S3. .
  • Page 38 COOLMAY MX3G PLC HMI All in one Programming manual 1: reverse action. 0: No input change alarm; bit1 1: Input change amount alarm is valid. 0: No output change alarm; Do not turn ON bit2 and bit5 bit2 1: Output...
  • Page 39 COOLMAY MX3G PLC HMI All in one Programming manual S3.+1 Input change amount (increase (ACT): 0~32767 side) alarm set value Valid when S3.+1 bit1=1 Input change amount (decrease (ACT): 0~32767 side) alarm set value Valid when S3.+1 bit1=1 (ACT): Output change amount (increase 0~32767 Valid when S3.+1 bit2=1，...
  • Page 40 COOLMAY MX3G PLC HMI All in one Programming manual change amount (increase side) overflow. 0: The output change amount (reduction side) does not bit3 overflow; 1: Output change amount (reduction side) overflow. *1: When S3+1 action setting (ACT) bit1=1, bit2=1 or bit5=1, S3+20~24 is occupied.

  • Page 41: Application Of High Speed Counter

    COOLMAY MX3G PLC HMI All in one Programming manual 2.9. Application of high speed counter 2.9.1. Assignment table of built-in high speed counter MX3G PLC high-speed counting conventional 2 single-phase 60KHz + 4 10KHz or 1 AB (Z) phase 30KHz +1 AB (Z) phase 5KHz; among them, dual-phase double counting input, the default is 1 frequency.

  • Page 42: Related Device

    COOLMAY MX3G PLC HMI All in one Programming manual C239 C240 C241 C242 C243 C244 C245 C246 C247 Single phase double counter C248 input C249 C250 C251 AB phase double counter C252 input C253 U: up counter D: down counter...

  • Page 43: Application Of High Speed Pulse

    2.10. Application of high speed pulse 2.10.1. High speed pulse output Coolmay 3G PLC high-speed pulse output conventional 4 channels, 70C: Y0-Y1 is 100KHz, Y2-Y3 is 50KHz; 43C: Y0-Y1 is 100KHz, Y2-Y3 is 10KHz. Support variable speed, the initial/final speed of start/stop is 0, the chart is as...

  • Page 44: Pulse Width Modulation (Pwm)

    COOLMAY MX3G PLC HMI All in one Programming manual Acceleration/deceleration time T calculation= (target speed-current speed) * acceleration/deceleration time/maximum speed. For example, target speed = 50000, current speed = 20000, acceleration time 100 (ms), maximum speed = 100,000, T = 30 ms.
  • Page 45 COOLMAY MX3G PLC HMI All in one Programming manual Operand Data Word software Content Range type type component Word soft component numbers of KnX, KnY, KnM, KnS, 0~32767ms Pulse width (ms) data or saving data 16 bit T, C, D, R, V, Z, K, H...

  • Page 46: Plc Communication Port Instructions

    2.11.1.1. RD3A/WR3A command function and action description: Read slave data (RD3A)： For CoolMay PLC, the RD3A instruction corresponds to Modbus's No. 03 function. m1 represents the station number of the read slave device,range:1-247; m2 represents the first address number of the read data in the slave device;...

  • Page 47: Adprw Command Function And Action Description

    D-1 address value must be set to (=0: serial port 2; =1: serial port 3) Write data to the slave (WR3A): For CoolMay PLC, the WR3A instruction corresponds to Modbus's 06 and 10 functions. m1 represents the station number of the slave device to be written, range :1-247.
  • Page 48 COOLMAY MX3G PLC HMI All in one Programming manual logic coils, range 1-512 No. 02: Read the input status and get the current status (ON/OFF) of a group of switch inputs, range 1-512 No. 03: Read the retentive register and get the current binary value in one or more retentive registers, ranging from 1-125 No.

  • Page 49: Word Device Communication Address Number

    COOLMAY MX3G PLC HMI All in one Programming manual 2.11.1.3. Word device communication address number MODBUS device CX3G/FX3GC device Input register (readout Holding register (read/write) dedicated) 0x0000～0x1F3F D0～D7999 0x1F40～0x213F D8000～D8511 0x2140～0x7EFF R0～R23999 0x7F00～0xA13F Unused address 0xA140～0xA27F TN0～TN319 0xA280～0xA33F Unused address 0xA340～0xA407...

  • Page 50: Adprw Command Function Parameter

    COOLMAY MX3G PLC HMI All in one Programming manual 2.11.1.5. ADPRW Command function parameter Operand function Function MODBUS Access Data storage device start code address/subfunction code points/subfunction data MODBUS Address： Access points： Read object device Coil readout 0000H~FFFFH 1~2000 D.R.M.Y.S MODBUS Address：...

  • Page 51: Serial Port 2: Rs485(A B)

    COOLMAY MX3G PLC HMI All in one Programming manual 2.11.2. Serial port 2: RS485(A B) Support MITSUBISHI programming port protocol,Mitsubishi BD board protocol,Free port protocol and MODBUS RTU protocol; The special relays and registers related to this serial port are as below:...

  • Page 52: Mitsubishi Programming Port Protocol

    COOLMAY MX3G PLC HMI All in one Programming manual protocol . M8125: the activation flag of using MODBUS and the original Mitsubishi function. M8122: RS sending flag (this bit needs to be set 1 when using the RS instruction, and it will automatically reset after sending).

  • Page 53: Free Port Protocol Function And Example

    COOLMAY MX3G PLC HMI All in one Programming manual 2.11.2.2. Free port protocol function and example When used as Mitsubishi free port protocol: set M8196=1，M8125=0; the difference between Mitsubishi protocol 1 and protocol 4 is with end mark OA OD ( stored in D8124, D8125 separately) For Mitsubishi Freeport Protocol, RS instruction is supported, the D8120 only needs to set the value of the lower 8 bits.

  • Page 54: Modbus Rtu Protocol

    COOLMAY MX3G PLC HMI All in one Programming manual 2.11.2.3. Modbus RTU Protocol When used as MOdbus RTU： set M8196=1,M8125=1; set D8120 as communication parameters, D8121 sets the station number of the slave. For example: D8120=HE081,D8121=H1(communications parameter as 9600/8/n/1,station number is 1)
  • Page 55 COOLMAY MX3G PLC HMI All in one Programming manual Master program: Program explanation: D300 saves the numbers of registers read, which means that 10 data is read. When using serial port 2, D.-1, here D299 must be set to 0.
  • Page 56 COOLMAY MX3G PLC HMI All in one Programming manual WR3A Program example (refer to 2.11.1.1): Master program: Slave program: Program explanation: This program represents that 1 data of the register D301 in the master PLC is written to the PLC in Slave 1, and is stored in the register D100 of the slave...

  • Page 57: Modbus Rtu Adprw Command

    COOLMAY MX3G PLC HMI All in one Programming manual 2.11.2.4. MODBUS RTU ADPRW command 03 function code hold register output. (refer to 2.11.1.2): Master program: Slave program:...

  • Page 58: Modbus Ascii Protocol

    COOLMAY MX3G PLC HMI All in one Programming manual Use the serial port tool to monitor serial port 2 for below data: [2017:11:01:17:48:54][receive]01 03 00 00 00 06 C5 C8 [2017:11:01:17:48:54][receive]01 03 0C 00 0C 00 17 00 22 00 38 00 4E 00 63 C4 29 2.11.2.5.

  • Page 59: Serial Port 3:Rs485 (A1 B1)/Rs232

    COOLMAY MX3G PLC HMI All in one Programming manual Data of the Master D300~D303 before and after the program execution is showed as below. 2.11.3. Serial port 3:RS485 (A1 B1)/RS232 Support Mitsubishi programming port protocol,RS2 protocol and MODBUS protocol. The special relays and registers related to this serial port are as below.
  • Page 60 COOLMAY MX3G PLC HMI All in one Programming manual RS/RS2 receiving completion M8123 M8403 Need to reset manually mark RS/RS2 receiving process M8124 M8404 Data is receiving mark RS/RS2 command 8/16 bits M8161 M8161 differentiation mark RS2 command end operation...
  • Page 61 COOLMAY MX3G PLC HMI All in one Programming manual M8029: Communication completion mark (communication completion mark while using ADPRW instruction and needs manual reset). M8161: 8-bit/16-bit mode distinguishing mark for RS/RS2 command. D8400: Save the communication parameters of the Modbus RTU protocol D8401:Save the communication mode of serial port 3.

  • Page 62: Mitsubishi Programming Protocol

    COOLMAY MX3G PLC HMI All in one Programming manual Baud rate (b7 b6 b5 b4) 0100:600bps 0101:1200bps 0110:2400bps 0111:4800bps 1000:9600bps 1001:19200bps b8~b15 Unavailable, Set 0 D8401 Parameter set Select protocol 0: Other communication protocol 1: MODBUS protocol b1~b3 Unavailable, Set 0...

  • Page 63: Modbus Rtu Protocol Rd3A/Wr3A Command

    COOLMAY MX3G PLC HMI All in one Programming manual Use the serial port tool to monitor serial port 3 for data: [2017:11:01:11:49:16][receive]31 32 33 Last parameter of RS2 instruction =1: Serial port 3. 2.11.3.3. Modbus RTU protocol RD3A/WR3A command Used as MOdbus RTU： set M8192=1; set D8400 as communication parameters, set D8414 s as master slave station no.
  • Page 64 COOLMAY MX3G PLC HMI All in one Programming manual Use the serial port tool to monitor serial port 3 for below data: [2017:11:01:09:00:11][receive]01 03 00 64 00 0A 84 12 [2017:11:01:09:00:11][receive]01 03 14 00 42 00 4D 00 58 00 58 00 63 00 37 00 2C 00 21 00 16 00 0B 9F C7 WR3A Program Example (Refer to 2.11.1.1):...

  • Page 65: Modbus Rtu Adprw Command

    COOLMAY MX3G PLC HMI All in one Programming manual Slave program Use the serial port tool to monitor serial port 3 for below data: [2017:11:01:09:25:20][receive]01 10 00 64 00 08 10 00 0B 00 16 00 21 00 2C 00 37 00 42 00 4D 00 58 D1 6C...

  • Page 66: Modbus Ascii Function

    COOLMAY MX3G PLC HMI All in one Programming manual Slave program Use the serial port tool to monitor serial port 3 for below data: [2017:11:01:17:38:34][receive]01 04 00 00 00 06 70 08 [2017:11:01:17:38:34][receive]01 04 0C 00 15 00 20 00 2B 00 41 00 57 00 00 5F A7 2.11.3.5.
  • Page 67 COOLMAY MX3G PLC HMI All in one Programming manual Slave program： Data of the Slave D100~D109 before and after the program execution is showed as below:...

  • Page 68: Network N:n Communication

    COOLMAY MX3G PLC HMI All in one Programming manual 2.11.4. Network N:N communication 2.11.4.1. Related device content 1. N:N network setting device Soft name content element value Set the flag for communication parameters. It can also be used as a flag to confirm the presence of...
  • Page 69 COOLMAY MX3G PLC HMI All in one Programming manual Serial channel =2：Serial port 2 D8394 selection =3：Serial port 3 2. Components for judging N:N network errors M8184~M8190, M8496~M8503: The data transmission sequence error flag of the slave station. When a data transmission sequence error occurs in each slave station, the corresponding flag bit turns ON.

  • Page 70: Program Setting And Description

    COOLMAY MX3G PLC HMI All in one Programming manual Station Station Station Station Station Station Station Station Station No Bit device (32 M1512~ M1576~ M1640~ M1704~ M1768~ M1832~ M1896~ M1960~ points each) M1543 M1607 M1671 M1735 M1799 M1863 M1927 M1991...
  • Page 71 COOLMAY MX3G PLC HMI All in one Programming manual Master program: Slave program: 2. Serial port 3 Such as serial port 2, only need the master and slave program to set D8394=3...

  • Page 72: Hmi

    COOLMAY MX3G PLC HMI All in one Programming manual 3. HMI 3.1. How to install TPWorks software (Please go to the official website :WWW.COOLMAY.COM to download the latest version) This chapter will detaily introduce the installation process of TPWorks software.
  • Page 73 COOLMAY MX3G PLC HMI All in one Programming manual Set the storage path of the installation file, select the default, or enter the address, or click the [Browse ...] button to select the address, and then click the [Next] button;...
  • Page 74 COOLMAY MX3G PLC HMI All in one Programming manual Choose whether to create a desktop shortcut icon, and then click the [Next] button. Confirm the installation path and other installation information, and then click the [Install] button to install.
  • Page 75 COOLMAY MX3G PLC HMI All in one Programming manual The installation process is shown below: Click [Next] to install the driver wizard The driver installation is completed...

  • Page 76: How To Open The Tpworks Software

    COOLMAY MX3G PLC HMI All in one Programming manual Finally, click [Finish] to complete the installation. 3.2. How to open the TPWorks software After the installation of TPWorks software is completed, a shortcut will be...

  • Page 77: New Hmi File

    COOLMAY MX3G PLC HMI All in one Programming manual placed on the desktop . At the same time, the corresponding mView program group has been added to the Windows start menu: Choose either of the above two methods to open the mView programming software, and the startup window will pop up when the application is opened, as shown in the figure below.
  • Page 78 COOLMAY MX3G PLC HMI All in one Programming manual Project Title: Enter the name of the new project; Model Number: Select the model of the human machine interface (HMI); (MX3G-43C selects model TP6043C; MX3G-70C selects model TP6070C) Display Direction: Select whether the editing screen is displayed horizontally or vertically;...

  • Page 79: Tpworks Program Simulation

    COOLMAY MX3G PLC HMI All in one Programming manual 3.4. TPWorks Program simulation TPWorks editing interface layout: Title bar: Displays the currently opened project path and file name, window number, and window name. Menu bar: A menu that displays various commands of CoolMayView.
  • Page 80 COOLMAY MX3G PLC HMI All in one Programming manual variables to facilitate users to quickly find the corresponding variables. Status bar: Display the current operating status, human-machine interface parameters, and communication equipment.

  • Page 81: Hmi Program Simulation And Download

    COOLMAY MX3G PLC HMI All in one Programming manual 4. HMI program simulation and download 4.1. Program simulation TPWorks provides the function of simulating directly on the PC. You can use this function to simulate the actions performed on the HMI after planning HMI.

  • Page 82: Off-Line Run

    COOLMAY MX3G PLC HMI All in one Programming manual to the communication ports on HMI, and the setting on the right is the set of communication ports designated by the user on the PC side to simulate the sex-corresponding communication ports of HMI side ,As shown below: 4.1.2.

  • Page 83: Save As Hmi Program

    COOLMAY MX3G PLC HMI All in one Programming manual 4.2.2. Save as HMI program In addition to downloading the planned program directly to the HMI, TPWorks also provides the user to save the planned program as a specific file (*.tpo) for later download and use. Note that this file is only for download and use, and can no longer modify its content.

  • Page 84: Update Hmi Os

    COOLMAY MX3G PLC HMI All in one Programming manual 4.2.3. Update HMI OS Generally speaking, when the new version of mView software is updated, it will be matched with the corresponding version of the OS. This OS supports the old version of the planning software downwards, but if the user wants to use the functions provided by the new version of the planning software, the new version must be matched OS and HMI OS are updated as follows.
  • Page 85 COOLMAY MX3G PLC HMI All in one Programming manual with the planning software version used). Step 3: Start downloading. (Note: During the OS download process, the HMI must can not be powered off!) Step 4: After the download is complete, restart the power of the HMI.

  • Page 86: Program Upload

    COOLMAY MX3G PLC HMI All in one Programming manual 4.3. Program upload Use this function to upload the program in the man-machine back to the PC and save it as an HMI program for later downloading or editing by the user.

  • Page 87: For Detailed Usage Of The Hmi Software, Please Refer To "Coolmay Tp Series Hmi User Manual

    COOLMAY MX3G PLC HMI All in one Programming manual information before downloading the program, otherwise the uploaded program can only be used for downloading, and the user cannot edit it. Select [View]→[Option(H)]→[File], and tick [Add Decompiled Information]. As shown below: 4.4.

  • Page 88: Appendix: Version Change Record

    COOLMAY MX3G PLC HMI All in one Programming manual 5. Appendix: Version Change Record Date Changed version Changed content Nov. 2021 V21.111  First edition released Dec. 2021 V21.11  2.1 Soft element table, data register changed...
